Dreamtilt VoIP Setup Guide
LINKSYS PAP2
CONFIGURATION GUIDE
Minimum Requirements
 Active Dreamtilt Wireless and VoIP account
 Broadband Modem/Router
o Must have an Ethernet port to connect to the PAP2.
 Analogue Telephone with RJ-11 line (Desktop or Cordless)

Advertisement

loading
Need help?

Need help?

Do you have a question about the PAP2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Linksys PAP2

Summary of Contents for Linksys PAP2

  • Page 1 Dreamtilt VoIP Setup Guide LINKSYS PAP2 CONFIGURATION GUIDE Minimum Requirements  Active Dreamtilt Wireless and VoIP account  Broadband Modem/Router o Must have an Ethernet port to connect to the PAP2.  Analogue Telephone with RJ-11 line (Desktop or Cordless)
  • Page 2 Open a browser window and enter the PAP2’s IP address in your browser’s address bar to access the PAP2’s configuration menu. If you are experiencing difficulty trying to connect to the device at this point, please refer to the PAP2 user guide or contact Linksys Technical Support for further assistance.
  • Page 3 Dreamtilt VoIP Setup Guide VoIP Configuration Once you have logged into the PAP2 Configuration Center, log in as the Administrator by clicking the ADMIN LOGIN on the top right hand side of the page. For more information regarding each property and option, please refer to the PAP2 user manual.
  • Page 4 Dreamtilt VoIP Setup Guide Subscriber Information DISPLAY NAME: Enter your Dreamtilt VoIP Number USER ID: Enter your Dreamtilt VoIP Number PASSWORD: Enter your Dreamtilt VoIP Password Audio Configuration PREFERRED CODEC: G.729a Dial Plan Copy into the DIAL PLAN the following - (*xx|13[1-9]xxxS0|1[38]00xxxxxxS0|190xxxxxxx!|000S0|0011xxxxx.|[2-9]xxxxxxxS0|0[2- 9]xxxxxxxxS0) Now click on SAVE SETTINGS...
  • Page 5 Dreamtilt VoIP Setup Guide NAT Support Parameters SUBSTITUTE VIA Address: Yes STUN ENABLE: Yes STUN TEST ENABLE: Yes STUN SERVER: stun1.dreamtilt.com.au Click on SAVE SETTINGS Click on the REGIONAL tab Call Progress Tones DIAL TONE: 400@-19,425@-19,450@-19;10(*/0/1+2+3) BUSY TONE: 425@-19;10(.375/.375/1) REORDER TONE: 425@-19, 425@-29;60(.375/.375/1,.375/.375/2) RING BACK TONE: 400@-19,425@-19,450@-19;*(.4/.2/1+2+3,.4/2/1+2+3)
  • Page 6 Dreamtilt VoIP Setup Guide MWI DIAL TONE 400@-19,425@-19,450@-19;2(.1/.1/1+2);10(*/0/1+2) Control Timer Values HOOK FLASH TIMER MIN: 0.07 HOOK FLASH TIMER MAX: 0.13 Distinctive Call Waiting Tone Patterns CWT8 CADENCE: 30(.2/.2,.2/4.4) Distinctive Ring Patterns RING 1 CADENCE: 60(.4/.2,.4/2) Miscellaneous TIME ZONE: GMT+10:00 FXS PORT IMPEDANCE 220+820||115nF Click on SAVE SETTINGS.
  • Page 7 Dreamtilt VoIP Setup Guide Internet Connection Type and Optional Network Configuration DHCP: Yes DNS Server Order: DHCP, Manual Click on SAVE SETTINGS. You should now be able to make calls on your phone. Extra Information To reset the device to its factory defaults, perform the following with your handset: 1.
