- Page 1 SA 125 CD Mixer Amplifier...
- Page 2 Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 Internet: www.thomann.de 24.09.2024, ID: 277370 (V2)
- Page 3 Table of contents Table of contents General information..........................5 1.1 Symbols and signal words....................... 5 Safety instructions............................. 7 Features............................... 10 Installation and starting up........................ 11 4.1 Screw terminal strip........................11 Connections and controls........................13 Technical specifications........................17 Plug and connection assignment....................20 Cleaning...............................
- Page 4 SA 125 CD Mixer Amplifier...
- Page 5 Our products and documentation are subject to a process of continuous development. They are therefore subject to change. Please refer to the latest version of the documentation, which is ready for download under www.thomann.de. 1.1 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this document.
- Page 6 General information Signal word Meaning DANGER! This combination of symbol and signal word indicates an immediate dangerous situation that will result in death or serious injury if it is not avoided. WARNING! This combination of symbol and signal word indicates a pos‐ sible dangerous situation that can result in death or serious injury if it is not avoided.
- Page 7 Safety instructions Safety instructions Intended use This device is intended to be used for amplification, mixing and playback of signals from musical instruments and microphones. Use the device only as described in this user manual. Any other use or use under other operating conditions is considered to be improper and may result in personal injury or property damage.
- Page 8 Safety instructions DANGER! Risk of death from electrical current! The output voltages of modern high-performance amplifiers may result in death or serious injury. Never touch the bare ends of loud‐ speaker cables when the amplifier is on. DANGER! Danger to life due to electric current! A short circuit could lead to a fire hazard and risk of death.
- Page 9 Safety instructions NOTICE! Damage to the device if operated in unsuitable ambient conditions! The device can be damaged if it is operated in unsuitable ambient conditions. Only operate the device indoors within the ambient conditions specified in the “Technical specifications” chapter of this user manual. Avoid operating it in environments with direct sun‐ light, heavy dirt and strong vibrations.
- Page 10 Features Features Special features of this mixer amplifier: 4 microphone/line inputs 24 V phantom power Priority control CD/AUX input Input for external pre-amplifier Output for external power amplifier Screw terminals for speakers and mains-independent 24-V power supply SA 125 CD Mixer Amplifier...
- Page 11 Installation and starting up Installation and starting up Unpack and check carefully there is no transportation damage before using the unit. Keep the equipment packaging. To fully protect the product against vibration, dust and moisture during transportation or storage use the original packaging or your own packaging material suitable for transport or storage, respectively.
- Page 12 Installation and starting up DC 24V 8Ω 70V 100V – 24 V Finally check all cable connections for tightness and reattach the terminal screw strip cover to the device. SA 125 CD Mixer Amplifier...
- Page 13 Connections and controls Connections and controls Front ö & OUTPUT SA 125 MASTER INPUT 1 INPUT 2 INPUT 3 INPUT 4 BASS TREBLE +10 -10 POWER SA 125 CD Mixer Amplifier...
- Page 14 Connections and controls 1 [OUTPUT] | LED chain: The bottom LED lights up permanently as soon as the device is switched on. The upper LEDs indicate the strength of the output signal, depending on the position of the MASTER control. 2 [INPUT 1 –...
- Page 15 Connections and controls Back ö & 115V~ 230V~ "WARNING" TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE RISK OF ELECTRIC SHOCK THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT DO NOT OPEN LINE LINE...
- Page 16 Connections and controls 1 [MUTE ADJ] | Priority control for INPUT 1. This setting controls to which extent the volume levels of the other channels are decreased when an audio or microphone signal is output via channel 1. Use a suitable screwdriver to turn the control knob to the required position.
- Page 17 Technical specifications Technical specifications Amplifier class Input connections Power supply Rubber panel plug C14 Terminal block 24 V 12 A MIC/LINE 4 × XLR / 6.35-mm jack combo socket, balanced CD/AUX Cinch input socket (L/R) AMP IN Cinch input socket Input sensitivity AUX: –15 dBV/1 kHz (unbalanced) CD: –6 dBV/1 kHz (unbalanced)
- Page 18 Technical specifications Signal-to-noise ratio MIC/LINE: ³ 65 dB AUX: ³ 75 dB Total harmonic distortion (THD) £0.5%, at 50% of maximum output power Crosstalk 60 dB Gain MIC: 76 dB LINE/AUX: 41 dB Tone control Treble: ± 10 dB, 10 kHz Bass: ±...
- Page 19 Technical specifications Block diagram PHANTOM Mic1 LINE Mic1 volume JUMP Mic1 sampling PRE OUT AMP IN PHANTOM LED display Mic2 LINE Mic2 volume Low control PHANTOM priority control 100V Mic3 LINE Mic3 volume Master 8ohm High control PHANTOM Mic4 LINE Mic4 volume AUX volume DC 24V...
- Page 20 Plug and connection assignment Plug and connection assignment Introduction This chapter will help you select the right cables and plugs to connect your valuable equip‐ ment in such a way that a perfect sound experience is ensured. Please note these advices, because especially in ‘Sound & Light’ caution is indicated: Even if a plug fits into the socket, an incorrect connection may result in a destroyed power amp, a short circuit or ‘just’...
- Page 21 Plug and connection assignment 1/4" TS phone plug (mono, unbalanced) Signal Ground, shielding 1/4" TRS phone plug (mono, bal‐ anced) Signal (in phase, +) Signal (out of phase, –) Ground RCA connection Drawing and table indicate the pin assignment of an RCA plug. Signal Ground, shielding SA 125 CD...
- Page 22 Cleaning Cleaning Fan grids The fan grids of the device must be cleaned of any contamination, such as dust, etc. on a reg‐ ular basis. Before cleaning, switch off the device and disconnect mains-operated devices from the mains. Only use pH-neutral, solvent-free and non-abrasive cleaning agents. Clean the unit with a slightly damp lint-free cloth.
- Page 23 Protecting the environment Protecting the environment Disposal of the packing material Environmentally friendly materials have been chosen for the packaging. These materials can be sent for normal recycling. Ensure that plastic bags, packaging, etc. are disposed of in the proper manner. Do not dispose of these materials with your normal household waste, but make sure that they are collected for recycling.
- Page 24 When disposing of the device, comply with the rules and regulations that apply in your country. You can also return your old device to Thomann GmbH at no charge. Check the current conditions on www.thomann.de.
- Page 25 Notes SA 125 CD Mixer Amplifier...
- Page 26 Notes SA 125 CD Mixer Amplifier...
- Page 28 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
