HB-300B
bass combo
user manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Harley Benton HB-300B and is the answer not in the manual?

Questions and answers

Summary of Contents for thomann Harley Benton HB-300B

  • Page 1 HB-300B bass combo user manual...
  • Page 2 Musikhaus Thomann e.K. Treppendorf 30 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 E-mail: info@thomann.de Internet: www.thomann.de 09.04.2014, ID: 301901...
  • Page 3: Table Of Contents

    Table of contents Table of contents General notes............................... 4 Safety instructions............................. 6 Features............................... 11 Installation and starting up........................ 12 Connections and operating elements................... 14 Technical specifications........................20 Plug and connection assignment....................21 Protecting the environment......................24 HB-300B...
  • Page 4: General Notes

    General notes General notes This user manual contains important information on safe operation of the device. Read and follow all safety notes and all instructions. Save this manual for future reference. Make sure that it is available to all persons using this device. If you sell the device, include the manual for the next owner.
  • Page 5 General notes Signal word Meaning DANGER! This combination of symbol and signal word indicates an immediate dangerous situation that will result in death or serious injury if it is not avoided. CAUTION! This combination of symbol and signal word indicates a pos‐ sible dangerous situation that can result in minor injury if it is not avoided.
  • Page 6: Safety Instructions

    Safety instructions Safety instructions Intended use This device is intended to be used for amplification and playback of signals from musical instruments with electromagnetic pickups. Any other use or use under other operating condi‐ tions is considered to be improper and may result in personal injury or property damage. No liability will be assumed for damages resulting from improper use.
  • Page 7 Safety instructions DANGER! Electric shock caused by high voltages inside Within the device there are areas where high voltages may be present. Never remove any covers. There are no user-serviceable parts inside. DANGER! Electric shock caused by short-circuit Always use proper ready-made insulated mains cabling (power cord) with a pro‐ tective contact plug.
  • Page 8 Safety instructions CAUTION! Possible hearing damage The device can produce volume levels that may cause temporary or permanent hearing impairment. Over an extended period of time, even levels that seem to be uncritical can cause hearing damage. Decrease the volume level immediately if you experience ringing in your ears or hearing impairment.
  • Page 9 Safety instructions NOTICE! Risk of fire Do not cover the device nor any ventilation slots. Do not place the device near any direct heat source. Keep the device away from naked flames. NOTICE! Operating conditions This device has been designed for indoor use only. To prevent damage, never expose the device to any liquid or moisture.
  • Page 10 Safety instructions NOTICE! Power supply Before connecting the device, ensure that the input voltage (AC outlet) matches the voltage rating of the device and that the AC outlet is protected by a residual current circuit breaker. Failure to do so could result in damage to the device and possibly injure the user.
  • Page 11: Features

    Features Features Special features of the device Output power 300 watt (4 Ω) 1 × 15" Celestion speaker Switchable horn Graphic 7-band equalizer Compressor Effects loop Inputs – – Footswitch Outputs – DI (balanced) – Tuner – Line Standby function HB-300B...
  • Page 12: Installation And Starting Up

    Installation and starting up Installation and starting up Unpack and carefully check that there is no transportation damage before using the unit. Keep the equipment packaging. To fully protect the device against vibration, dust and moisture during transportation or storage use the original packaging or your own packaging material suitable for transport or storage, respectively.
  • Page 13 Installation and starting up NOTICE! Possible property damage by magnetic fields Loudspeakers produce a static magnetic field. Therefore, maintain an appropriate distance to devices that can be adversely affected or damaged by an external magnetic field. HB-300B...
  • Page 14: Connections And Operating Elements

    Connections and operating elements Connections and operating elements Front panel bass combo...
  • Page 15 Connections and operating elements 1 [INPUT] 1/4" phone socket to connect your instrument. You can also connect other active signal sources like CD or MP3 players, keyboards, mixers etc. to this input. 2 [GAIN] Control to adjust the preamp gain of the signal (volume) in channel 1. 3 [VOICE] Control to adjust the tone colour of the signal in channel 1.
  • Page 16 Connections and operating elements 7 [COMPRESSOR] Pushbutton for enabling the built-in compressor. The LED [ACTIVE] lights permanently during operation, when the compressor is enabled. The LED [ON] indicates that the compressor circuit is active and processes the signal. The signal level at which the compressor processes the signal is affected by the gain controls (the higher the gain, the more the signal is compressed).
  • Page 17 Connections and operating elements 11 [CD / LINE IN] RCA input for connecting a CD player, cassette deck or the like. 12 [D.I. OUT] Balanced XLR output for connecting the amplifier to a mixer. The amplifier signal is supplied unchanged to the connected mixer. 13 [TUNER OUT] Output for connecting a tuner (6.35 mm phone socket).
  • Page 18 Connections and operating elements Rear panel bass combo...
  • Page 19 Connections and operating elements 16 [AC INPUT | FUSE] IEC chassis plug with fuse holder. Find technical data on spare fuses and power supply below or next to the fuse holder. 17 Fan. 18 [FX SEND | RETURN] In and output jacks for looping in an effects unit (6.35 mm jack sockets). 19 [Horn On | Off] Toggle switch for enabling or disabling the built-in horn.
  • Page 20: Technical Specifications

    Technical specifications Technical specifications Output power 300 W (RMS) @ 4 Ω 145 W (RMS) @ 8 Ω Frequency range 45 Hz…20 kHz Input impedance 220 kΩ Power consumption max. 450 W Operating supply voltage AC 220 – 240 V , 50/60 Hz Fuse 2 A / 250 V Dimensions (W ×...
  • Page 21: Plug And Connection Assignment

    Plug and connection assignment Plug and connection assignment Introduction This chapter will help you select the right cables and plugs to connect your valuable equip‐ ment in such a way that a perfect sound experience is ensured. Please note these advices, because especially in ‘Sound & Light’ caution is indicated: Even if a plug fits into the socket, an incorrect connection may result in a destroyed power amp, a short circuit or ‘just’...
  • Page 22 Plug and connection assignment Since the interference affects both cores equally, by subtracting the phase-shifted signals, the interfering signal is completely neutralized. The result is a pure signal without any noise inter‐ ference. 1/4" TS phone plug (mono, unbalanced) Signal Ground, shielding XLR plug (balanced) Ground, shielding...
  • Page 23 Plug and connection assignment RCA connection Drawing and table indicate the pin assignment of an RCA plug. Signal Ground, shielding HB-300B...
  • Page 24: Protecting The Environment

    Protecting the environment Protecting the environment Disposal of the packaging mate‐ rial For the transport and protective packaging, environmentally friendly materials have been chosen that can be supplied to normal recycling. Ensure that plastic bags, packaging, etc. are properly disposed of. Do not just dispose of these materials with your normal household waste, but make sure that they are collected for recycling.
  • Page 25 Notes HB-300B...
  • Page 26 Notes bass combo...
  • Page 28 Musikhaus Thomann e.K. · Treppendorf 30 · 96138 Burgebrach · Germany · www.thomann.de...
