Introduction
The T33881 is 63" wide, 30" deep, and 61
has three load levels, and has a maximum load
capacity of 2200 lbs. (top level 300 lbs., middle
level 500 lbs., bottom level 1400 lbs.). Use locking
swivel casters to lock cart in place, or unlock them
to transport your stock around the shop.
Figure 1. Model T33881.
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
COPYRIGHT © JULY, 2023 BY GRIZZLY INDUSTRIAL, INC.
NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
(FOR MODELS MFD. SINCE 06/23) #CS22798 PRINTED IN CHINA
***Keep for Future Reference***
CANTILEVER PIPE CART
" tall,
1
2
• To reduce risk of crushing injuries from
cart tipping over on you:
— Do not stand or climb on any part of
cart.
— Push cart only. Do not pull it.
— Always lock swivel casters before load-
ing or unloading stock.
• Do not exceed weight capacities:
— Top level 300 lbs.
— Middle level 500 lbs.
— Bottom level 1400 lbs.
— Entire cart: 2200 lbs.
• Always install removable pegs to secure
stock and keep it from falling and striking
operator or bystanders.
• Always lock swivel casters when cart is
not being used to transport stock.
• Do not allow children unsupervised
access to cart.
MODEL T33881
INSTRUCTIONS
To reduce your risk of
serious injury, read this
entire
manual
assembling or using cart.
BEFORE
V1.07.23
