Summary of Contents for Haier HCE604P
- Page 1 Installation instructions Solid hotplate cooktops User guide HCE604P models NZ AU...
-
Page 3: Table Of Contents
The models shown in this user guide may not be available in all markets and are subject to change at any time. For current details about model and specification availability in your country, please visit our local website listed on the back cover or contact your local Haier dealer. -
Page 4: Safety And Warnings
Safety and warnings Important safety instructions Installation WARNING! Cut Hazard Beware of sharp edges when handling appliances. Failure to use caution could result in injury or cuts. WARNING! Electrical Shock Hazard Before carrying out any work on the electrical section of the appliance, it must be disconnected from the mains electricity supply. - Page 5 Safety and warnings Important safety instructions Operation WARNING! Hot Surface Hazard Accessible parts of this appliance will become hot during use. Care should be taken to avoid touching the hotplates. Keep children away. Failure to do so could result in burns and scalds. WARNING! Electrical Shock Hazard Switch the cooktop off at the wall before cleaning or maintenance.
-
Page 6: Installation Instructions
Installation instructions Important! Read these instructions carefully before installing or using this product. Please make this information available to the person responsible for installing the product as it could reduce your installation costs. In order to avoid a hazard, this appliance must be installed according to these instructions for installation. - Page 7 Installation instructions Product dimensions and clearances The installation shall comply with the dimensions in Fig. 1, bearing in mind the following requirements: A minimum clearance of 30 mm has to be kept between the bottom of the cooktop and the top of an underbench appliance or a thermal protection barrier (see Figs.
- Page 8 Installation instructions Fig. 2 Product and cutout dimensions...
- Page 9 Installation instructions Installing a thermal protection barrier Important! If the cooktop is installed over drawers or cupboards and its underside surface thus becomes accessible after installation, a thermal protection barrier must be fitted at least 30 mm beneath the base of the cooktop (see Fig.
- Page 10 Installation instructions Fastening the installation brackets Each cooktop is provided with two R type brackets (for the rear of the cooktop), two F type brackets (for the front of the cooktop) and four screws for fastening the cooktop to benches from 20 to 40 mm thick.
- Page 11 Installation instructions Electrical requirements The appliance must be connected to the mains electricity supply checking that the voltage corresponds to the value given in the rating plate and that the power supply cable sections can withstand the load specified on the plate. A power supply cable is NOT supplied with the appliance.
- Page 12 Installation instructions Connecting the power supply cable Turn the cooktop over and place it on a soft surface. Unhook the terminal board cover by inserting a screwdriver into the two hooks C (fig. 8). Unscrew the screw D and open completely the cable clamp E (fig. 10). Check the bridging links F are inserted into terminal block A as shown (Figs.
- Page 13 Installation instructions Wiring diagram - CE604 models Fig. 11 Wiring diagram F1/2/3/4 Hotplate switches Regular hotplate 1500 W - 230 V Line pilot lamp Regular hotplate 1000 W - 230 V Rapid hotplate 2000 W - 230 V Terminal block F1/2/3/4 Hotplate switches Regular hotplate 1500 W - 230 V...
-
Page 14: Introduction
About your new cooktop Thank you for buying a Haier cooktop. Once it is installed and ready to use, you will want to know everything about it to make sure you get excellent results right from the start. This guide introduces you to all its special features. - Page 15 Introduction Fig.12 Cooktop layout 1000 W regular hotplate 1500 W rapid hotplate 1500 W regular hotplate 2000 W rapid hotplate Rear right hotplate control knob Rear left hotplate control knob Front left hotplate control knob Front right hotplate control knob Hotplate ON indicator light...
-
Page 16: Using Your Cooktop
Using your cooktop First use Before using the cooktop for the first time, you need to remove any protective coating that may still be on the hotplates. After you’ve removed the protective coating, boil a saucepan of water on each plate for about 10 minutes. There will be a distinctive smell and some light smoke visible while this is happening. - Page 17 Using your cooktop Cookware and cooking tips Use pans with thick flat bases, as they are the most effective. It is worth buying good quality pans to get the best results from your cooktop. Use a pan with a base that matches the diameter of the hotplate. Ensure that the bottom of the pan you are using is dry.
- Page 18 Using your cooktop The following tables contain guidelines to show recommended heat settings for cooking different types of food with your cooktop. Exact settings will depend on the type of pan and quantity of food being cooked. Electric hotplate usage table Temperature control knob Temperature control knob Knob...
-
Page 19: Care And Cleaning
Care and cleaning General advice Before you begin cleaning, you must ensure that the cooktop is switched off. Allow the cooktop to cool down before cleaning. Avoid leaving acidic substances (lemon juice, vinegar etc.) on the surfaces. Enamelled parts Wash all of the enamelled parts only with a sponge or soft cloth, and soapy water or non- abrasive cleaners. -
Page 20: Warranty And Service
Warranty and service Before you call for service or assistance ... Check the things you can do yourself. Refer to the installation instructions and your user guide and check that: your product is correctly installed. you are familiar with its normal operation. If after checking these points you still need assistance or parts, please refer to the Service &... - Page 22 Copyright © Fisher & Paykel/Haier 2015. All rights reserved. The product specifications in this booklet apply to the specific products and models described at the date of issue. Under our policy of continuous product improvement, these specifications may change at any time. You should therefore check with your Dealer to ensure this booklet correctly describes the product currently available.
