- Page 1 User Manual 90 cm Ceramic Cooktop, Model Code: TRC900CT Please read this manual carefully before using, and keep it for future reference.
- Page 2 P a g e INSTRUCTION MANUAL 90cm Ceramic Cooktop MODEL TRC900CT Congratulations on the purchase of your new Ceramic Hob! We recommend that you spend some time to read this Instruction / Installation Manual in order to fully understand how to install and operate it correctly. For installation, please read the installation section.
- Page 3 P a g e CONTENTS PACKAGE.................................4 IMPORTANT - CHECK FOR ANY DAMAGE OR MARKS................. 4 BEFORE USING YOUR NEW CERAMIC HOB.....................4 SAFETY WARNINGS..............................5 IMPORTANT INFORMATION......................... 5 WARNING! ............................... 5 USAGE CONDITIONS AND RESTRICTIONS....................5 PRODUCT OVERVIEW ............................8 TOP VIEW................................. 8 CONTROL PANEL/USER INTERFACE......................9 PRODUCT FUNCTIONS..........................10 INSTALLATION...............................
- Page 4 P a g e 1. PACKAGE When unpacking the appliance, please check that the following items are contained within the package: 1 Hob 1 Instruction manual 4 Fixing screws 4 Fixing brackets 1 Sealing strip 1.1 IMPORTANT - CHECK FOR ANY DAMAGE OR MARKS Please thoroughly inspect your goods at the delivery time, if you notice any damage to your goods:...
- Page 5 P a g e 2. SAFETY WARNINGS IMPORTANT INFORMATION Your safety is important to us. Please read this manual thoroughly before you start using the Ceramic Cooktop. The safety precautions instructions reduce the risk of fire, electric shock and injury when correctly complied to.
- Page 6 P a g e Only for indoor domestic use only. It is not to be used for industrial or commercial use. Do not use this product for anything other than its intended purpose, and only use it as described in this manual.
- Page 7 P a g e Be careful when using this cooktop, as the cooktop complies with all safety regulations, we do not wish for customers to burn themselves as the surface will become extremely hot during use and will retain heat after use. ...
- Page 8 P a g e 3. PRODUCT OVERVIEW TOP VIEW Heating Zone Power Heating Zone Power 1200W 1000/2000W 950/1750/2700W 1200W 1800W ONLINE: TRINITYAPPLIANCES.COM.AU...
- Page 9 P a g e CONTROL PANEL/USER INTERFACE Reference Description Zone select key ON/OFF key Power Regulating Key(Level 0~9) Timer regulating key (reduce) Timer regulating key (increase) Triple ring control key Stop & Go function Timer key Child lock key Keep warm key ONLINE: TRINITYAPPLIANCES.COM.AU...
- Page 10 P a g e | 10 PRODUCT FUNCTIONS The ceramic hob caters for all kinds of cooking with its radiant heat cooking zones, electronic touch controls, and multiple functions making it the ideal choice for the modern family. The ceramic hob is extremely user-friendly, durable and safe. Special Functions ...
- Page 11 P a g e | 11 4. INSTALLATION SELECTION OF INSTALLATION EQUIPMENT Cut out the work surface according to the sizes shown in the drawing. For the purpose of installation and use, a minimum of 5 cm space shall be preserved around the hole.
- Page 12 P a g e | 12 A (mm) B (mm) C (mm) 50 minimum 20 minimum Air intake Air exit 5 mm Before you install the hob, make sure that: the work surface is square and level and no structural members interfere with the space requirements;...
- Page 13 P a g e | 13 When you have installed the hob, make sure that: the power supply cable is not accessible through cupboard doors or drawers; there is adequate flow of fresh air from outside the cabinetry to the base of the hob; ...
- Page 14 P a g e | 14 CAUTIONS 1. The ceramic cooker hob must be installed by qualified personnel or technicians. We have professionals at your service. Please never conduct the operation by yourself. 2. The ceramic cooker hob must not be mounted to cooling equipment, dishwashers and rotary dryers.
- Page 15 P a g e | 15 1. The domestic wiring system is suitable for the power drawn by the hob. 2. The voltage corresponds to the value given in the rating plate. 3. The power supply cable sections can withstand the load specified on the rating plate. To connect the hob to the mains power supply, do not use adapters, reducers, or branching devices, as they can cause overheating and fire.
- Page 16 P a g e | 16 5. USING YOUR COOKTOP Before using your new Ceramic Hob Read this guide taking special note of the “Safety Warnings” section. Remove any protective film that may still be on your Ceramic Hob. CHOOSING THE RIGHT COOKWARE Do not use cookware with jagged edges or a curved base.
- Page 17 P a g e | 17 USING TOUCH CONTROLS The controls respond to touch, so you don’t need to apply any pressure. Use the ball of your finger, not the tip. You will hear a “beep” buzzer sound each time a touch is registered. ...
- Page 18 P a g e | 18 START OPERATION To start cooking 1. Place a suitable pan on the cooking zone that you wish to use. Make sure the bottom of the pan and the surface of the cooking zone is clean and dry. 2.
- Page 19 P a g e | 19 USING THE TIMER You can set it to turn one cooking zone off after the set time is up. You can set the timer for up to 99 minutes. 1. Select the relevant cooking zone by touching the zone selection key (A). 2.
- Page 20 P a g e | 20 USING THE TRIPPLE RING ZONE You can set the triple zone after the zone is turned on and started working. You can set the zone working at triple rings, double rings, or single ring. 1.
- Page 21 P a g e | 21 3. To cancel the pause, press the Stop & Go button . The cooking zo will return to the power level you previously set. POWER LIMITATION 1. Switch on power and keep the hob on. together 2.
- Page 22 P a g e | 22 To unlock the controls 1. Touch and hold the child lock key for a while. 2. You can now start using your ceramic hob. When the hob is in the lock mode, all the controls are disabled, except the ON/OFF.
- Page 23 P a g e | 23 5.10 Using the Keep Warm Function > When using keep warm function, all previous multi-ring setting will be recognized automatically. > Touch the cooking zone selection button that you wish to use keep warm. >...
- Page 24 P a g e | 24 6. CARE AND MAINTENANCE Warning! Always switch off the electricity supply before performing maintenance work. In the event of a fault, contact customer service. CARE AMAGED POWER CABLES SHOULD BE REPLACED BY A COMPETENT PERSON OR QUALIFIED ELECTRICIAN OR DOMESTIC USE ONLY EVER PLACE AN EMPTY PAN ON THE HOB AS THIS WILL CAUSE AN ERROR MESSAGE TO APPEAR...
- Page 25 P a g e | 25 APPLIANCE CLEANLINESS Caution Avoid rubbing with any abrasive or with the base of the pans, etc., as this will wear the markings on the top of the ceramic hob over time. Clean the ceramic hob on a regular basis to prevent the build-up of food residue. The appliance should be cleaned after use.
- Page 26 P a g e | 26 7. TROUBLESHOOTING Before calling the customer services, please check that the appliance is correctly connected, any of the following cases are not covered by the warranty: Damage caused by improper use, storage or maintenance ...
- Page 27 P a g e | 27 8. TECHNICAL SPECIFICATIONS Cooktop model TRC900CT Cooking Zones 5 Zones Supply Voltage 220-240V~ Installed Electric Power 8900W(230V~) Product Size L×W×H (mm) 900X510X47 Building-in Dimensions A×B (mm) 880X490 Weight and Dimensions are approximate. Because we continually strive to improve our products, we may change specifications and designs without prior notice.
- Page 28 P a g e | 28 CUSTOMER CARE Please be advised that without the proof of purchase, your warranty may not be valid, keep the receipt. For your convenience, please record: STORE NAME/CONTACT DETAILS: ..........… PURCHASE DATE: ................PRODUCT MODEL N: …...............…. PRODUCT SERIAL N: ...............
