- Page 1 User Manual 90 cm Induction Cooktop, Model Code: TRI905 Please read this manual carefully before using, and keep it for future reference.
- Page 2 P a g e INSTRUCTION MANUAL 90cm Induction Cooktop MODEL TRI905 Congratulations on the purchase of your new Induction Hob! We recommend that you spend some time to read this Instruction / Installation Manual in order to fully understand how to install and operate it correctly. For installation, please read the installation section.
-
Page 3: Table Of Contents
P a g e CONTENTS 1. PACKAGE.................................4 IMPORTANT - CHECK FOR ANY DAMAGE OR MARKS.................4 BEFORE USING YOUR NEW INDUCTION HOB..................4 2. SAFETY WARNINGS..............................5 IMPORTANT INFORMATION.........................5 WARNING! ............................... 5 USAGE CONDITIONS AND RESTRICTIONS....................5 3. PRODUCT OVERVIEW ............................8 TOP VIEW................................. 8 CONTROL PANEL/USER INTERFACE......................9 A WORD ON INDUCTION COOKING...... -
Page 4: Package
P a g e 1. PACKAGE When unpacking the appliance, please check that the following items are contained within the package: • 1 Hob • 1 Instruction manual • 4 Fixing screws • 4 Fixing brackets • 1 Sealing strip IMPORTANT - CHECK FOR ANY DAMAGE OR MARKS Please thoroughly inspect your goods at the delivery time, if you notice any damage to your goods:... -
Page 5: Safety Warnings
P a g e 2. SAFETY WARNINGS IMPORTANT INFORMATION Your safety is important to us. Please read this manual thoroughly before you start using the Induction Cooktop. The safety precautions instructions reduce the risk of fire, electric shock and injury when correctly complied to. Please follow all instructions and take notice of all warnings. - Page 6 P a g e • Only for indoor domestic use only. It is not to be used for industrial or commercial use. • Do not use this product for anything other than its intended purpose, and only use it as described in this manual. Do not attempt to alter or modify this appliance.
- Page 7 P a g e • Be careful when using this cooktop, as the cooktop complies with all safety regulations, we do not wish for customers to burn themselves as the surface will become extremely hot during use and will retain heat after use. •...
-
Page 8: Product Overview
P a g e 3. PRODUCT OVERVIEW TOP VIEW Heating Zone Power Max. Power Heating Zone (220-240V~50/60Hz) 2000/2800W 1500/2000W 2300/3000W 1500/2000W 2000/2800W 9000W Total Rating Power ONLINE: TRINITYAPPLIANCES.COM.AU... -
Page 9: Control Panel/User Interface
P a g e CONTROL PANEL/USER INTERFACE Reference Description Zone select key Child lock key ON/OFF key Power/Timer slider regulating key Flexible area key Boost control key/Keep warm key Timer key/Pause key ONLINE: TRINITYAPPLIANCES.COM.AU... -
Page 10: A Word On Induction Cooking
P a g e A WORD ON INDUCTION COOKING Induction cooking is a safe, advanced, efficient, and economical cooking technology. It works by electromagnetic vibrations generating heat directly in the pan, rather than indirectly through heating the glass surface. The glass becomes hot only because the pan eventually warms it up. -
Page 11: Installation
P a g e 4. INSTALLATION SELECTION OF INSTALLATION EQUIPMENT Cut out the work surface according to the sizes shown in the drawing. For the purpose of installation and use, a minimum of 5 cm space shall be preserved around the hole. Be sure the thickness of the work surface is at least 30 mm. - Page 12 P a g e A (mm) B (mm) C (mm) 50 minimum 20 minimum Air intake Air exit 5 mm Before you install the hob, make sure that: the work surface is square and level , and no structural members interfere with the space requirements;...
-
Page 13: Installation
P a g e When you have installed the hob, make sure that: the power supply cable is not accessible through cupboard doors or drawers; there is adequate flow of fresh air from outside the cabinetry to the base of the hob;... -
Page 14: Cautions
P a g e fig.3 fig.4 Do not use adhesive to fix the hob into the worktop.Once the seal is fitted position the hob into the cutout in the worktop. Spply gentle downwards pressure onto the hob to push it into the worktop ensuring a good seal around the outer edge(fig.4) CAUTIONS 1. -
Page 15: Using Your Cooktop
P a g e The power supply cable must not touch any hot parts and must be positioned so that its temperature will not exceed 75°C at any point. Check with an electrician whether the domestic wiring system is suitable without alterations. Any alterations must only be made by a qualified electrician. -
Page 16: Using Touch Controls
P a g e 1. Put some water in the pan you want to check. 2. If does not flash in the display and the water is heating, the pan is suitable. • Cookware made from the following materials is not suitable: pure stainless steel, aluminum or copper without a magnetic base, glass, wood, porcelain, ceramic, and earthenware. -
Page 17: When You Have Finished Cooking
P a g e 1. Touch the ON/OFF control for 3 secnds. After power on, the buzzer beeps once, all displays show “ – “, indicating that the induction hob has entered the state of standby mode. 2. Place a suitable pan on the cooking zone that you wish to use. -
Page 18: Child Lock Function
P a g e CHILD LOCK FUNCTION • You can lock the controls to prevent unintended use (for example children accidentally turning the cooking zones on). • When the controls are locked, all the controls except the ON/OFF control are disabled. - Page 19 P a g e 3. Set the time by touching the “-“ or ”+” control of the timer Hint: Touch the “-“ or ”+” control of the timer once to decrease or increase by 1 minute. Touch and hold the “-“or ”+” control of the timer to decrease or increase by 10 minutes.
-
Page 20: Using The Keep Warm And Pause Function
P a g e Using the Keep warm and Pause Function 1.Tou ch th e cookin g zon e selectio n butto n that yo u wish t o u se kee p warm, an indicator nex t t o th e ke y will flash. 2.Touch the button and hold for 3 seconds, the cooking zone indicator will display . -
Page 21: Using The Boost Function
P a g e 2. Adjust heat setting by touching the slider regulating key(D) control. If the pot is moved from the front to the rear part (or viceversa),the flexible area detects automatically the new position, keeping the same power. You can cancel the flexible area in two different way: 1.Press the zone select key(A). -
Page 22: Using Cooking Functions
P a g e 5.11 Using Cooking Functions You can choose 3 handy cooking functions by pressing the cooking functions each time moves from one function to the other. - Melt or defrost (about 50℃) - Heating or keeping warm (about 70℃) - Simmering, temperature close to boiling, useful for slow cooking 6. -
Page 23: Technical Specifications
The above are the judgment and inspection of common failures. Please do not disassemble the unit by yourself to avoid any dangers and damages to the induction hob and please contact the supplier. 7. TECHNICAL SPECIFICATIONS Cooktop model TRI905 Cooking Zones 5 Zones Supply Voltage 220-240V~... -
Page 24: Customer Care
P a g e 9. CUSTOMER CARE • Please be advised that without the proof of purchase, your warranty may not be valid, keep the receipt. For your convenience, please record: STORE NAME/CONTACT DETAILS: ..........… PURCHASE DATE: ................PRODUCT MODEL N: …...............…. PRODUCT SERIAL N: ...............
