- Page 1 User Manual 60 cm Induction Cooktop, Model Code: TRI603 Please read this manual carefully before using, and keep it for future reference.
- Page 2 P a g e INSTRUCTION MANUAL 60cm Induction Cooktop MODEL TRI603 Congratulations on the purchase of your new Induction Hob! We recommend that you spend some time to read this Instruction / Installation Manual in order to fully understand how to install and operate it correctly. For installation, please read the installation section.
- Page 3 P a g e CONTENTS 1. PACKAGE.................................4 IMPORTANT - CHECK FOR ANY DAMAGE OR MARKS.................4 BEFORE USING YOUR NEW INDUCTION HOB..................4 2. SAFETY WARNINGS..............................5 IMPORTANT INFORMATION.........................5 WARNING! ............................... 5 USAGE CONDITIONS AND RESTRICTIONS....................5 3. PRODUCT OVERVIEW ............................8 TOP VIEW................................. 8 CONTROL PANEL/USER INTERFACE......................9 A WORD ON INDUCTION COOKING......
- Page 4 P a g e 1. PACKAGE When unpacking the appliance, please check that the following items are contained within the package: • 1 Hob • 1 Instruction manual • 4 Fixing screws • 4 Fixing brackets • 1 Sealing strip IMPORTANT - CHECK FOR ANY DAMAGE OR MARKS Please thoroughly inspect your goods at the delivery time, if you notice any damage to your goods:...
- Page 5 P a g e 2. SAFETY WARNINGS IMPORTANT INFORMATION Your safety is important to us. Please read this manual thoroughly before you start using the Induction Cooktop. The safety precautions instructions reduce the risk of fire, electric shock and injury when correctly complied to. Please follow all instructions and take notice of all warnings.
- Page 6 P a g e • Only for indoor domestic use only. It is not to be used for industrial or commercial use. • Do not use this product for anything other than its intended purpose, and only use it as described in this manual. Do not attempt to alter or modify this appliance.
- Page 7 P a g e • Be careful when using this cooktop, as the cooktop complies with all safety regulations, we do not wish for customers to burn themselves as the surface will become extremely hot during use and will retain heat after use. •...
- Page 8 P a g e 3. PRODUCT OVERVIEW TOP VIEW Heating Zone Power Max. Power Heating Zone (220-240V~50/60Hz) 2300/2600W 1200/1500W 3000/3600W Total Rating Power 6600-7400W ONLINE: TRINITYAPPLIANCES.COM.AU...
- Page 9 P a g e CONTROL PANEL/USER INTERFACE Reference Description Zone select key ON/OFF key Power Regulating Key(Level 0~9) Timer regulating key (reduce) Timer regulating key (increase) Boost control key Child lock key Timer key Cooking Function pause key ONLINE: TRINITYAPPLIANCES.COM.AU...
- Page 10 P a g e A WORD ON INDUCTION COOKING Induction cooking is a safe, advanced, efficient, and economical cooking technology. It works by electromagnetic vibrations generating heat directly in the pan, rather than indirectly through heating the glass surface. The glass becomes hot only because the pan eventually warms it up.
- Page 11 P a g e 4. INSTALLATION SELECTION OF INSTALLATION EQUIPMENT Cut out the work surface according to the sizes shown in the drawing. For the purpose of installation and use, a minimum of 5 cm space shall be preserved around the hole. Be sure the thickness of the work surface is at least 30 mm.
- Page 12 P a g e A (mm) B (mm) C (mm) 50 minimum 20 minimum Air intake Air exit 5 mm Before you install the hob, make sure that: the work surface is square and level , and no structural members interfere with the space requirements;...
- Page 13 P a g e When you have installed the hob, make sure that: the power supply cable is not accessible through cupboard doors or drawers; there is adequate flow of fresh air from outside the cabinetry to the base of the hob;...
- Page 14 P a g e fig.3 fig. Do not use adhesive to fix the hob into the worktop.Once the seal is fitted position the hob into the cutout in the worktop. Spply gentle downwards pressure onto the hob to push it into the worktop ensuring a good seal around the outer edge(fig.4) CAUTIONS 1.
- Page 15 P a g e The power supply cable must not touch any hot parts and must be positioned so that its temperature will not exceed 75°C at any point. Check with an electrician whether the domestic wiring system is suitable without alterations. Any alterations must only be made by a qualified electrician.
- Page 16 P a g e 5. USING YOUR COOKTOP Before using your new Induction Hob • Read this guide taking special note of the “Safety Warnings” section. • Remove any protective film that may still be on your Induction Hob. CHOOSING THE RIGHT COOKWARE •...
- Page 17 P a g e • The controls respond to touch, so you don’t need to apply any pressure. • Use the ball of your finger, not the tip. • You will hear a “beep” buzzer sound each time a touch is registered. •...
- Page 18 P a g e 4. Select the power level by pressing the key or key 5. The power level will start at 0.Pressing the “+”will count up the power levels from 0 to 9 in numerical order.Pressing the “-”key will take the power straight from 9 to 0.
- Page 19 P a g e 1.Make sure the Induction hob is turned on. 2.Touch and hold the keylock control for a while 3.You can now start using your Induction hob. When the hob is in the lock mode, all the controls are disabled, except the ON/OFF.
- Page 20 P a g e Setting the timer to turn one or more cooking zones off If the timer is set on one zone: 1. Select the relevant cooking zone which is working by touching the zone select key (A). 2. Press the Timer key , the timing indicator flashes, and you can set the timer at this point.
- Page 21 P a g e 2. Touching the boost control key ,the zone indicator show “P.” and the power reach Max. Cancel the Boost function 1. Touching the relevant zone select key(A) that you wish to cancel. 1a. Touching the “ ”key to cancel the Boost function, then the cooking zone will revert to level 9.
- Page 22 P a g e 6. TROUBLESHOOTING Before calling the customer services, please check that the appliance is correctly connected, any of the following cases are not covered by the warranty: Damage caused by improper use, storage or maintenance Damage caused by unauthorised disassembly and repair ...
- Page 23 P a g e 7. TECHNICAL SPECIFICATIONS Cooktop model TRI603 Cooking Zones 3 Zones Supply Voltage 220-240V~ Installed Electric Power 7400W(230V~) Product Size L×W×H (mm) 590X520X58 Building-in Dimensions A×B (mm) 565X495 Weight and Dimensions are approximate. Because we continually strive to improve our products, we may change specifications and designs without prior notice.
- Page 24 P a g e 9. CUSTOMER CARE • Please be advised that without the proof of purchase, your warranty may not be valid, keep the receipt. For your convenience, please record: STORE NAME/CONTACT DETAILS: ..........… PURCHASE DATE: ................PRODUCT MODEL N: …...............…. PRODUCT SERIAL N: ...............
