- Page 1 User Manual 77 cm Ceramic Cooktop, Model Code: TRC775 Please read this manual carefully before using, and keep it for future reference.
- Page 2 P a g e INSTRUCTION MANUAL 77cm Ceramic Cooktop MODEL TRC775 Congratulations on the purchase of your new Ceramic Hob! We recommend that you spend some time to read this Instruction / Installation Manual in order to fully understand how to install and operate it correctly. For installation, please read the installation section.
-
Page 3: Table Of Contents
P a g e CONTENTS 1. PACKAGE.................................4 IMPORTANT - CHECK FOR ANY DAMAGE OR MARKS.................4 BEFORE USING YOUR NEW CERAMIC HOB.....................4 2. SAFETY WARNINGS..............................5 IMPORTANT INFORMATION.........................5 WARNING! ............................... 5 USAGE CONDITIONS AND RESTRICTIONS....................5 3. PRODUCT OVERVIEW ............................8 TOP VIEW................................. 8 CONTROL PANEL/USER INTERFACE......................9 PRODUCT FUNCTIONS..........................10 4. -
Page 4: Package
P a g e 1. PACKAGE When unpacking the appliance, please check that the following items are contained within the package: • 1 Hob • 1 Instruction manual • 4 Fixing screws • 4 Fixing brackets • 1 Sealing strip IMPORTANT - CHECK FOR ANY DAMAGE OR MARKS Please thoroughly inspect your goods at the delivery time, if you notice any damage to your goods:... -
Page 5: Safety Warnings
P a g e 2. SAFETY WARNINGS IMPORTANT INFORMATION Your safety is important to us. Please read this manual thoroughly before you start using the Ceramic Cooktop. The safety precautions instructions reduce the risk of fire, electric shock and injury when correctly complied to. Please follow all instructions and take notice of all warnings. - Page 6 P a g e • Only for indoor domestic use only. It is not to be used for industrial or commercial use. • Do not use this product for anything other than its intended purpose, and only use it as described in this manual. Do not attempt to alter or modify this appliance.
- Page 7 P a g e • Be careful when using this cooktop, as the cooktop complies with all safety regulations, we do not wish for customers to burn themselves as the surface will become extremely hot during use and will retain heat after use. •...
-
Page 8: Product Overview
P a g e 3. PRODUCT OVERVIEW TOP VIEW Heating Zone Power Max. Power Heating Zone (220-240V~50/60Hz) 2200W/1100W(230V~) (Double Ring) 1200W(230V~) 2000W/1100W(230V~) (Double Ring) 1800W(230V~) Total Rating Power 7200W(230V~) ONLINE: TRINITYAPPLIANCES.COM.AU... -
Page 9: Control Panel/User Interface
P a g e CONTROL PANEL/USER INTERFACE Reference Description Zone select key ON/OFF key Power Regulating Key(Level 0~9) Timer regulating key (reduce) Timer regulating key (increase) Double ring control key Child lock key Timer key Keep warm key pause key ONLINE: TRINITYAPPLIANCES.COM.AU... -
Page 10: Product Functions
P a g e PRODUCT FUNCTIONS The ceramic hob caters for all kinds of cooking with its radiant heat cooking zones, electronic touch controls, and multiple functions making it the ideal choice for the modern family. The ceramic hob is extremely user- friendly, durable and safe. -
Page 11: Installation
P a g e 4. INSTALLATION SELECTION OF INSTALLATION EQUIPMENT Cut out the work surface according to the sizes shown in the drawing. For the purpose of installation and use, a minimum of 5 cm space shall be preserved around the hole. Be sure the thickness of the work surface is at least 30 mm. - Page 12 P a g e A (mm) B (mm) C (mm) 50 minimum 20 minimum Air intake Air exit 5 mm Before you install the hob, make sure that: the work surface is square and level and no structural members interfere with the space requirements;...
-
Page 13: Installation
P a g e When you have installed the hob, make sure that: the power supply cable is not accessible through cupboard doors or drawers; there is adequate flow of fresh air from outside the cabinetry to the base of the hob;... -
Page 14: Cautions
P a g e fig.3 fig.4 Do not use adhesive to fix the hob into the worktop.Once the seal is fitted position the hob into the cutout in the worktop. Spply gentle downwards pressure onto the hob to push it into the worktop ensuring a good seal around the outer edge(fig.4) CAUTIONS 1. -
Page 15: Connecting The Hob To The Main Power Supply
P a g e Warning: THIS APPLIANCE MUST BE EARTHED. This hob must be connected to the mains power supply only by a suitably qualified person. Before connecting the hob to the mains power supply, check that: 1. The domestic wiring system is suitable for the power drawn by the hob. 2. -
Page 16: Choosing The Right Cookware
P a g e • Read this guide taking special note of the “Safety Warnings” section. • Remove any protective film that may still be on your Ceramic Hob. CHOOSING THE RIGHT COOKWARE Do not use cookware with jagged edges or a curved base. Make sure that the base of your pan is smooth,sits flat against the glass,and is the same size as the cooking zone.Use pans whose diameter is as large as the graphic of the zone selected.Using a pot a slightly wider energy will be used at... -
Page 17: Start Operation
P a g e 1. Place a suitable pan on the cooking zone that you wish to use.Make sure the bottom of the pan and the surface of the cooking zone is clean and dry. 2. Touch the ON/OFF key for 1 seconds.After power is on, the buzzer beeps once, all displays show “0”indicating that the ceramic hob has entered the state of standby mode. -
Page 18: Using The Timer
P a g e To unlock the controls Touch and hold the child lock key for a while. You can now start using your ceramic hob. When the hob is in the lock mode, all the controls are disabled, except the ON/OFF. You can always turn the ceramic hob off with the ON/OFF control in an emergency, but you shall unlock the hob first in the next operation USING THE TIMER... -
Page 19: Using The Double Ring Zone
P a g e 5.6 USING THE DOUBLE RING ZONE You can set the double ring zone after the zone is working. You can set the zone working by double ring or single ring. 1.Turn on,the double ring work by default,the double ring indicator light on. 2.Press the double ring control key ,the double ring indicator light off,then on inner ring works. -
Page 20: Care And Maintenance
P a g e 6. CARE AND MAINTENANCE Warning! Always switch off the electricity supply before performing maintenance work. In the event of a fault, contact customer service. CARE DAMAGED POWER CABLES SHOULD BE REPLACED BY A COMPETENT PERSON OR QUALIFIED ELECTRICIAN. FOR DOMESTIC USE ONLY. -
Page 21: Appliance Cleanliness
P a g e APPLIANCE CLEANLINESS Caution • Avoid rubbing with any abrasive or with the base of the pans, etc., as this will wear the markings on the top of the ceramic hob over time. • Clean the ceramic hob on a regular basis to prevent the build-up of food residue. -
Page 22: Troubleshooting
P a g e 7. TROUBLESHOOTING Before calling the customer services, please check that the appliance is correctly connected, any of the following cases are not covered by the warranty: Damage caused by improper use, storage or maintenance Damage caused by unauthorised disassembly and repair ... -
Page 23: Technical Specifications
P a g e 8. TECHNICAL SPECIFICATIONS Cooktop model TRC775 Cooking Zones 4 Zones Supply Voltage 220-240V~ Installed Electric Power 7200W(230V~) Product Size L×W×H (mm) 770X520X50 Building-in Dimensions A×B (mm) 740X490 Weight and Dimensions are approximate. Because we continually strive to improve our products, we may change specifications and designs without prior notice. -
Page 24: Customer Care
P a g e CUSTOMER CARE • Please be advised that without the proof of purchase, your warranty may not be valid, keep the receipt. For your convenience, please record: STORE NAME/CONTACT DETAILS: ..........… PURCHASE DATE: ................PRODUCT MODEL N: …...............…. PRODUCT SERIAL N: ...............
