- Page 1 User Manual 60 cm Hybrid Cooktop, Model Code: TRCI603 Please read this manual carefully before using, and keep it for future reference.
- Page 2 P a g e INSTRUCTION MANUAL 60cm Hybrid Cooktop MODEL TRCI603 Congratulations on the purchase of your new Hybrid Hob! We recommend that you spend some time to read this Instruction / Installation Manual in order to fully understand how to install and operate it correctly. For installation, please read the installation section.
-
Page 3: Table Of Contents
P a g e CONTENTS 1. PACKAGE.................................4 IMPORTANT - CHECK FOR ANY DAMAGE OR MARKS.................4 BEFORE USING YOUR NEW HYBRID HOB....................4 2. SAFETY WARNINGS..............................5 IMPORTANT INFORMATION.........................5 WARNING! ............................... 5 USAGE CONDITIONS AND RESTRICTIONS....................5 3. PRODUCT OVERVIEW ............................8 TOP VIEW................................. 8 CONTROL PANEL/USER INTERFACE......................9 A WORD ON HYBRID COOKING......................10 4. -
Page 4: Package
P a g e 1. PACKAGE When unpacking the appliance, please check that the following items are contained within the package: • 1 Hob • 1 Instruction manual • 4 Fixing screws • 4 Fixing brackets • 1 Sealing strip IMPORTANT - CHECK FOR ANY DAMAGE OR MARKS Please thoroughly inspect your goods at the delivery time, if you notice any damage to your goods:... -
Page 5: Safety Warnings
P a g e 2. SAFETY WARNINGS IMPORTANT INFORMATION Your safety is important to us. Please read this manual thoroughly before you start using the Hybrid Cooktop. The safety precautions instructions reduce the risk of fire, electric shock and injury when correctly complied to. Please follow all instructions and take notice of all warnings. - Page 6 P a g e • Only for indoor domestic use only. It is not to be used for industrial or commercial use. • Do not use this product for anything other than its intended purpose, and only use it as described in this manual. Do not attempt to alter or modify this appliance.
- Page 7 P a g e • Be careful when using this cooktop, as the cooktop complies with all safety regulations, we do not wish for customers to burn themselves as the surface will become extremely hot during use and will retain heat after use. •...
-
Page 8: Product Overview
P a g e 3. PRODUCT OVERVIEW TOP VIEW Heating Zone Power Heating Zone Max. Power (220V~) 2000/2300W(Booster) 1500/2000W(Booster) 2300/1150W(Inner ring) Total Rating Power 5800W ONLINE: TRINITYAPPLIANCES.COM.AU... -
Page 9: Control Panel/User Interface
P a g e CONTROL PANEL/USER INTERFACE Reference Description ON/OFF key Child lock key Pause key Timer control keys &Timer setting indicator Power slider regulating key Boost control key Cooking functions key Dual circuit control key Timer setting indicator Power level indicator Timer Indicator Cooking functions indicator ONLINE: TRINITYAPPLIANCES.COM.AU... -
Page 10: A Word On Hybrid Cooking
P a g e A WORD ON HYBRID COOKING Hybrid cooking is a safe, advanced, efficient, and economical cooking technology. It works by electromagnetic vibrations generating heat directly in the pan, rather than indirectly through heating the glass surface. The glass becomes hot only because the pan eventually warms it up. -
Page 11: Installation
P a g e 4. INSTALLATION SELECTION OF INSTALLATION EQUIPMENT Cut out the work surface according to the sizes shown in the drawing. For the purpose of installation and use, a minimum of 5 cm space shall be preserved around the hole. Be sure the thickness of the work surface is at least 30 mm. - Page 12 P a g e A (mm) B (mm) C (mm) 50 minimum 20 minimum Air intake Air exit 5 mm Before you install the hob, make sure that: the work surface is square and level , and no structural members interfere with the space requirements;...
-
Page 13: Installation
P a g e When you have installed the hob, make sure that: the power supply cable is not accessible through cupboard doors or drawers; there is adequate flow of fresh air from outside the cabinetry to the base of the hob;... -
Page 14: Cautions
P a g e fig.3 fig.4 Do not use adhesive to fix the hob into the worktop.Once the seal is fitted position the hob into the cutout in the worktop. Spply gentle downwards pressure onto the hob to push it into the worktop ensuring a good seal around the outer edge(fig.4) CAUTIONS 1. -
Page 15: Connecting The Hob To The Main Power Supply
P a g e CONNECTING THE HOB TO THE MAIN POWER SUPPLY This hob must be connected to the mains power supply only by a suitably qualified person. Before connecting the hob to the mains power supply, check that: 1. The domestic wiring system is suitable for the power drawn by the hob. 2. -
Page 16: Using Your Cooktop
P a g e 5. USING YOUR COOKTOP Before using your new Hybrid Hob • Read this guide taking special note of the “Safety Warnings” section. • Remove any protective film that may still be on your Hybrid Hob. CHOOSING THE RIGHT COOKWARE •... -
Page 17: Using Touch Controls
P a g e USING TOUCH CONTROLS • The controls respond to touch, so you don’t need to apply any pressure. • Use the ball of your finger, not the tip. • You will hear a “beep” buzzer sound each time a touch is registered. •... -
Page 18: When You Have Finished Cooking
P a g e • If you do not choose a heat setting within 20 seconds, Hybrid hob will automatically switch off. You will need to start again at step 1. • You can modify the heat setting at any time during cooking. If the display flashes alternately with the heat setting This means that:... -
Page 19: Using The Timer
P a g e USING THE TIMER You can use the timer in two different ways: • You can use it as a minute minder. In this case, the timer will not turn any cooking zone off when the set time is up. •... -
Page 20: Using The Cooking And Pause Function
P a g e 5. When cooking timer expires, the corresponding cooking zone will be switch off automatically. Other cooking zone will keep operating if they are turned on previously. 6. When using “the timer as an alarm” and “the timer to switch off the zones ” together ,the timer setting indicator will show the remaining time of alarm as first priority. -
Page 21: Using The Boost Function
P a g e • Important: Make sure to place the cookwares centered on the single cooking zone. The ideal recipe is an oval or rectangular saucepan, or a saucepan. Examples of good pot placement and bad pot placement. 1. To activate the flexible area as a single big zone, press the power slider regulating key of front right and rear right zones at the same time. -
Page 22: Troubleshooting
P a g e 6. TROUBLESHOOTING Before calling the customer services, please check that the appliance is correctly connected, any of the following cases are not covered by the warranty: Damage caused by improper use, storage or maintenance Damage caused by unauthorised disassembly and repair ... -
Page 23: Technical Specifications
P a g e 7. TECHNICAL SPECIFICATIONS Cooktop model TRCI603 Cooking Zones 3 Zones Supply Voltage 220-240V~ Installed Electric Power 5800W(230V~) Product Size L×W×H (mm) 590X520X58 Building-in Dimensions A×B (mm) 565X495 Weight and Dimensions are approximate. Because we continually strive to improve our products, we may change specifications and designs without prior notice. -
Page 24: Customer Care
P a g e 9. CUSTOMER CARE • Please be advised that without the proof of purchase, your warranty may not be valid, keep the receipt. For your convenience, please record: STORE NAME/CONTACT DETAILS: ..........… PURCHASE DATE: ................PRODUCT MODEL N: …...............…. PRODUCT SERIAL N: ...............
