Trinity TRC600-EK User Manual

60 cm ceramic cooktop
Hide thumbs
Table of Contents

Advertisement

Quick Links

User Manual
60 cm Ceramic Cooktop, Model Code: TRC600-EK
Please read this manual carefully before using, and keep it for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TRC600-EK and is the answer not in the manual?

Questions and answers

Related Manuals for Trinity TRC600-EK

Summary of Contents for Trinity TRC600-EK

  • Page 1 User Manual 60 cm Ceramic Cooktop, Model Code: TRC600-EK Please read this manual carefully before using, and keep it for future reference.
  • Page 2 P a g e INSTRUCTION MANUAL 60cm Ceramic Cooktop MODEL: TRC600-EK ONLINE: TRINITYAPPLIANCES.COM.AU...

  • Page 3: Table Of Contents

    P a g e CONTENTS PACKAGE ............................4 IMPORTANT - CHECK FOR ANY DAMAGE OR MARKS ............. 4 HANDLING..........................4 BEFORE USING YOUR NEW APPLIANCE ................4 SAFETY WARNINGS........................6 IMPORTANT INFORMATION ....................6 WARNING! ..........................6 USAGE CONDITIONS AND RESTRICTIONS................6 PRODUCT OVERVIEW ........................

  • Page 4: Package

    P a g e Congratulations on the purchase of your new Ceramic Hob! We recommend that you read this Instruction and Installation Manual in order to fully understand how to install and operate it correctly. For installation, please read the installation section. Read all the safety instructions carefully before use and keep this Instruction Manual for future reference.
  • Page 5 P a g e NOTE: This instruction manual has been prepared jointly for multiple models. Some of the specifications explained in the manual, may be slightly different or not be included in your appliance. Pay attention to the explanations with illustrations while reading the manual.

  • Page 6: Safety Warnings

    P a g e 2 SAFETY WARNINGS 2.1 IMPORTANT INFORMATION Your safety is important to us. Please read this manual thoroughly before you start using the Ceramic Cooktop. The safety precautions instructions reduce the risk of fire, electric shock and injury when correctly complied to.
  • Page 7 P a g e possible situation or condition as with any appliance. Use extreme caution when installing, operating and maintaining this appliance.  Never leave the cooktop unattended while in use.  For indoor domestic use only. It is not to be used for industrial or commercial use. ...
  • Page 8 P a g e  Please remember to let the cooktop cool down before attempting to clean.  Young children should be kept away from this appliance at all times! Take extreme caution when using the appliance that they do not come anywhere near the cooktop.

  • Page 9: Product Overview

    P a g e 3 PRODUCT OVERVIEW 3.1 TOP VIEW LAYOUT TOUCH CONTROLS 1- 1.20 kW zone Ø 155mm 3- 1.20 kW zone Ø 155mm 2- 1.80 kW zone Ø 190mm 4- 1.80 kW zone Ø 190mm Heating Zone Power Heating Zone Power 1800W...

  • Page 10: Control Panel

    P a g e | 10 3.2 CONTROL PANEL TOUCH CONTROLS Reference Description Zone select key Reduce power regulating key Increase power regulating key Child Lock function key 3.3 PRODUCT FUNCTIONS The ceramic hob caters for all kinds of cooking with its radiant heat cooking zones, electronic touch controls, and multiple functions making it the ideal choice for the modern family.

  • Page 11: Installation

    P a g e | 11 4 INSTALLATION 4.1 POSITIONING The adjacent cabinetry and wall materials must be able to withstand a minimum temperature rise of 85°C above the ambient temperature of the room. For the purpose of installation and use, a minimum of 50 mm space shall be preserved around the hole and 55mm from side or back wall Be sure the thickness of the work surface is at least 30 mm.
  • Page 12 P a g e | 12 A (mm) B (mm) C (mm) Air intake Min 650 Min 50 Min 20 Air exit 5 mm min 20mm Before you install the hob, make sure that:  the work surface is square and level, and no structural members interfere with the space requirements;...

  • Page 13: Installing The Cooktop

    P a g e | 13  you use heat-resistant and easy-to-clean finishes (such as ceramic tiles) for the wall surfaces surrounding the hob. When you have installed the hob, make sure that:  the power supply cable is not accessible through cupboard doors or drawers; ...
  • Page 14 P a g e | 14 The cooktop might come fitted with the sealing strip attached to the underside of the cooktop. This should not be removed as it will prevent liquid or spillages from penetrating the underside of the cooktop. Note: Do not use a silicon sealant to seal the appliance to the benchtop.

  • Page 15: Cautions

    P a g e | 15 4.3 CAUTIONS 1. The ceramic cooktop must be installed by qualified licensed personnel or technicians. 2. The ceramic cooktop must not be mounted to cooling equipment, dishwashers and rotary dryers. 3. The ceramic cooktop must be installed in a way that the better heat radiation can be ensured to enhance its reliability.

  • Page 16: Connecting The Mains Supply Cable

    P a g e | 16 If the appliance is being connected directly to the mains supply, an omnipolar circuit breaker must be installed with a minimum gap of 3 mm between the contacts. The installer must ensure that the correct electrical connection has been made and that it complies with safety regulations.
  • Page 17 P a g e | 17  The spur outlet must still be accessible even when your cooktop is located in its operating position.  Cable type: H05 VVF 3 core x 4mm2 The cable can be looped if necessary, but make sure that is not kinked or trapped when the cooktop is in position.

  • Page 18: Using Your Cooktop

    P a g e | 18 5 USING YOUR COOKTOP Before using your new Ceramic Hob  Read this guide taking special note of the “Safety Warnings” section.  Remove any protective film that may still be on your Ceramic Hob. 5.1 CHOOSING THE RIGHT COOKWARE Do not use cookware with jagged edges or a curved base.

  • Page 19: Using Touch Controls

    P a g e | 19 5.2 USING TOUCH CONTROLS  The controls respond to touch, so you don’t need to apply any pressure.  Use the ball of your finger, not its tip.  You will hear a beep each time a touch is registered. ...
  • Page 20 P a g e | 20  TURN ON Select the cooking zone by touching the zone indicator symbol.  SELECT TEMPERATURE Use the +/- buttons to increase or decrease heating level, indicated by the LED display. When you have finished cooking, double pressing selected zone indicator will turn it off.

  • Page 21: Cooktop Quick Guides

    P a g e | 21 When the hob is in the lock mode, all the controls are disabled. To turn the ceramic hob off you shall unlock the hob first for the next function. RESIDUAL HEAT INDICATORS After a zone is switched off, the corresponding cooking zone will show an “H” in the control panel.
  • Page 22 P a g e | 22  If these rules are not followed, then there will be a great loss of heat and energy. Heat not absorbed by the saucepan, will spread to the cooktop, frame and surrounding cabinets.  Preferably cover pans with a lid to permit cooking at a lower heat. ...

  • Page 23: Care And Maintenance

    P a g e | 23 6 CARE AND MAINTENANCE Warning! Always switch off the electricity supply before performing maintenance work. In the event of a fault, contact customer service. 6.1 CARE Damaged power cables should be replaced by a qualified electrician For domestic use only Never place an empty pan on the hob as this will cause an error message to appear on the control panel...

  • Page 24: Appliance Cleanliness

    P a g e | 24 6.2 CLEANING APPLIANCE WARNING! Do not start cleaning the cooktop until it has completely cooled. Caution:  Avoid rubbing with any abrasive or with the base of the pans, etc., as this will wear the markings on the top of the ceramic hob over time and may cause the crack of the glass surface.

  • Page 25: Troubleshooting

    P a g e | 25 7 TROUBLESHOOTING Before calling the customer services, please check that the appliance is correctly connected, any of the following cases are not covered by the warranty:  Damage caused by improper use, storage or maintenance ...

  • Page 26: Technical Specifications

    P a g e | 26 will be caused to the appliance or your kitchen, then they will not complete a repair. This includes situations where appliances have been tiled in or sealed in with sealant. Please do not disassemble the unit by yourself to avoid any dangers and damages to the ceramic hob and please contact the supplier.

  • Page 27: Customer Care

    P a g e | 27 10 CUSTOMER CARE  Please be advised that without the proof of purchase, your warranty may not be valid, keep the receipt. For your convenience, please record: STORE NAME/CONTACT DETAILS: ..........PURCHASE DATE: ................PRODUCT MODEL N: …..............
