Owner's Manual
Original Instructions
Floor Ceiling Type Air Conditioner
9,000Btu-24,00Btu
Thank you for choosing our product.
Please read this Owner's Manual carefully before operation and
retain it for future reference.
If you have lost the Owner's Manual, please contact the local agent
or visit www.gree.com or send an email to global@cn.gree.com for
the electronic version.

Advertisement

loading
Need help?

Need help?

Do you have a question about the GTHCA-D6DNA1B/I and is the answer not in the manual?

Questions and answers

Related Manuals for Gree GTHCA-D6DNA1B/I

Summary of Contents for Gree GTHCA-D6DNA1B/I

  • Page 1 Thank you for choosing our product. Please read this Owner’s Manual carefully before operation and retain it for future reference. If you have lost the Owner's Manual, please contact the local agent or visit www.gree.com or send an email to global@cn.gree.com for the electronic version.
  • Page 2 Indoor Unit Indoor Unit FLR09HP230V1R32AH GTH(09)CA-D6DNA1B/I FLR09HP230V1R32AH GTH(12)CA-D6DNA1B/I GTH(18)CA-D6DNA1B/I FLR18HP230V1R32AH FLR24HP230V1R32AH GTH(24)CB-D6DNA1B/I...
  • Page 3 Contents 1 Safety Precautions ............... 1 2 Outline of the Unit and Main Parts ........8 3 Operation and Introduction of Remote Controller....9 4 Preparative for Installation ..........16 4.1 Standard Accessory Parts ............16 4.2 Selection of the Installation Location ........16 4.3 Connection Pipe Requirement ..........17 4.4 Electrical Requirement ............18 5 Installation of the Unit ............19...
  • Page 4 Explanation of Symbols WARNING This symbol indicates the possibility of death or serious injury. This symbol indicates the possibility of injury or damage to CAUTION property. Indicates important but not hazard-related information, used NOTICE to indicate risk of property damage. Exception Clauses Manufacturer will bear no responsibilities when personal injury or property loss is caused by the following reasons.
  • Page 5 The refrigerant process or to clean,other than those recomm- Refrigerant Before install the ended by the manufacturer. Safety Group appliance, read Servicing shall be performed only as recomm- the installation ended by the manufacturer. Appliance filled with manual first. Should repair be necessary,contact your nearest flammable magas R32.
  • Page 6 Safety operation of flammable refrigerant table a - Minimum room area ( m Filling the refrigerant Based on UL 60335-2-40 requirements Use the refrigerant filling appliances specia- The following installation height and area for lized for R32. Make sure that different kinds customer reference of refrigerant won’t contaminate with each other.
  • Page 7 Safety operation of flammable refrigerant Pressure test and leak detect Avoid using it in the environment with electro- magnetic interference, chemical substances After completion of field piping for split (such as chemical plants, etc.), flammable systems, the field pipework shall be pressure gas, combustible and explosive gas and tested with an inert gas and then vacuum smog, etc.
  • Page 8 Floor Ceiling Type Unit 1 Safety Precautions This mark indicates procedures which, if improperly performed, might lead to WARNING! the death or serious injury of the user. This mark indicates procedures which, if improperly performed, might CAUTION! possibly result in personal harm to the user, or damage to property. WARNING! (1).
  • Page 9 Floor Ceiling Type Unit WARNING Installation Installation or maintenance should comply with nation- must be performed by qua- al electric safety regula- tions. lified professionals. Air Conditioner should be The appliance shall be in- properly grounded. Inco- stalled in accordance with rrect grounding may cause national wiring regulations.
  • Page 10 Floor Ceiling Type Unit CAUTION Installation Instructions for installation line. and use of this product are The yellow-green wire in provided by the manufac- air conditioner is ground- turer. ing wire, which can't be us- Select a location which is ed for other purposes.
  • Page 11 Floor Ceiling Type Unit WARNING Before operation, please If abnormal condition confirm whether power occurs (e. g. burned smell), specification complies please disconnect power with that on nameplate. at once and then contact Before cleaning or main- local dealer. taining the air condi- When nobody is taking tioner, please turn off air care of the unit, please...
  • Page 12 Floor Ceiling Type Unit WARNING on the nameplate for the air conditioner without detailed specification. supervision. Keep children from play- The appliance shall be ing or climbing on the installed in accordance air conditioner. with national wiring reg- Do not put or hang drip- ulations.
  • Page 13 Floor Ceiling Type Unit WARNING Operation and Maintenance ket. Otherwise, it may cau- se fire hazard. This appliance can be used Do disconnect power supp- by children aged from 8 ly when cleaning air condi- years and above and per- t ioner.
  • Page 14 Floor Ceiling Type Unit CAUTION Operation and Maintenance instructions shall be Do not spill water on the re- provided for completing mote controller, otherwise the assembly to ensure the remote controller may compliance with be broken. the requirements. Do not use fire or hair dry- When below phenomenon er to dry the filter to avoid occurs, please turn off air...
  • Page 15 Floor Ceiling Type Unit 2 Outline of the Unit and Main Parts On/Off Wifi Health UD-swing Timer on LR-swing Clock Timer off Light 3.Wired controller (optional) Fig.1 Notes: The connection pipe and duct for this unit should be prepared by the user.
  • Page 16 Floor Ceiling Type Unit 3 Operation and Introduction of Remote Controller Introduction for icons on display Buttons on remote controller screen Quiet Set fan speed Turbo mode Send signal Auto mode Cool mode Dry mode Fan mode Heat mode X-FAN function Power limiting operation Set temperature Indoor ambient temp.
  • Page 17 Floor Ceiling Type Unit Introduction for buttons on ● When selecting heat mode, the air conditioner remote controller operates under heat mode. Press " + " or " - " button to adjust set temperature. Press "Fan" NOTE button to adjust fan speed. Press " "...
  • Page 18 Floor Ceiling Type Unit swing angle . When reaching your required + / - button angle, release the button. Press " + " or " - " button once increase or decrease NOTE set temperature 1℃(℉). Holding " + " or " - " button, ●...
  • Page 19 Floor Ceiling Type Unit Function introduction for Timer on / Timer off button combination buttons ● TIMER ON button "TIMER ON" button can set the time for timer Energy-saving function on. After pressing this button, " " icon disap- pears and the word "ON" on remote controller Under cooling mode, press "Mode"...
  • Page 20 Floor Ceiling Type Unit following: NOTE blank ● No Setting Once the reminder function is turned on, only this cycle reminder can be cleared. ● This function is only available for some models. ● Maximum power limited under the mode is lower than that of mode.
  • Page 21 Floor Ceiling Type Unit ● Sleep 3 the sleep curve setting under Sleep mode according to the detected temperature. Press by DIY could be inquired: "Health" and " + " buttons simultaneously again to The user could accord to sleep curve setting method turn off I FEEL function and "...
  • Page 22 Floor Ceiling Type Unit Replacement of batteries in remote controller reinstall battery remove Cover of battery box Press the back side of remote controller marked with " ", as shown in the fig, and then push out the cover of battery box along the arrow direction.
  • Page 23 Floor Ceiling Type Unit 4 Preparative for Installation 4.1 Standard Accessory Parts The standard accessory parts listed below are furnished and should be used as required. Table 1 Indoor Unit Accessories Name Appearance Q'ty Usage Wired Controller(optional) To control the indoor unit Wireless Controller + To control the indoor unit Battery...
  • Page 24 Floor Ceiling Type Unit 4.2.1 Indoor Unit (1). Install the unit at a place where is strong enough to withstand the weight of the unit. (2). The air inlet and outlet of the unit should never be clogged so that the airflow can reach every corner of the room.
  • Page 25 Floor Ceiling Type Unit Table 2 Indoor unit Max. Height Max. Drainage Size of Fitting Pipe(Inch) Item Difference Pipe pipe(Outer between Indoor Length Diameter × Model Unit and Outdoor (ft) wall thickness) Liquid Unit (ft) (inch) FLR09HP230V1R32AH 5/8x1/8 FLR12HP230V1R32AH 5/8x1/8 FLR18HP230V1R32AH 5/8x1/8 FLR24HP230V1R32AH...
  • Page 26 Floor Ceiling Type Unit 5 Installation of the Unit 5.1 Installation of the Indoor Unit 5.1.1 Indoor unit dimension WARNING ! Install the indoor unit in a location which can withstand a load of at least five times the ①. weight of the main unit and which will not amplify sound or vibration.
  • Page 27 Floor Ceiling Type Unit Table 4 Unit:inch Model FLR09HP230V1R32AH 34 1/4 9 1/4 12 1/2 26 1/8 FLR12HP230V1R32AH FLR18HP230V1R32AH FLR24HP230V1R32AH 47 1/4 9 1/4 12 1/2 26 1/8 5.1.2 Preparation for Installing the Indoor Unit (1). Open the air inlet grille and the screw cover, and remove the screws. (2).
  • Page 28 Floor Ceiling Type Unit (5). Adjust the height of the unit to make the drain pipe slant slightly downward so that the drainage will become much smoother. ◆Floor type Fig. 5 ◆Ceiling type Fig. 6 (6). Reinstall and tighten the right and left side panel.
  • Page 29 Floor Ceiling Type Unit 5.1.4 Leveling The water level test must be done after installing the indoor unit to make the unit is horizontal, as shown below. Fig. 7 5.2 Installation of the Connection Pipe 5.2.1 Flare Processing (1). Cut the connection pipe with the pipe cutter and remove the burrs. (2).
  • Page 30 Floor Ceiling Type Unit 5.2.2 Bending Pipes (1). The pipes are shaped by your hands. Be careful not to collapse them. Fig. 9 (2). Do not bend the pipes in an angle more than 90°. (3). When pipes are repeatedly bent or stretched, the material will harden, making it difficult to bend or stretch them any more.
  • Page 31 Floor Ceiling Type Unit 5.2.3 Connecting the Pipe at the Indoor Unit Side Detach the caps and plugs from the pipes. CAUTION! Be sure to apply the pipe against the port on the indoor unit correctly. If the centering is ①...
  • Page 32 Floor Ceiling Type Unit Pipe Diameter Tightening Torque 1/4〞（Inch） 11-22 (ft-lb) 3/8〞（Inch） 25-29 (ft-lb) 1/2〞（Inch） 33-36 (ft-lb) 5/8〞（Inch） 44-47 (ft-lb) 3/4〞（Inch） 51-55 (ft-lb) 7/8〞（Inch） 59-62 (ft-lb) CAUTION! Be sure to connect the gas pipe after connecting the liquid pipe completely. 5.2.4 Connecting the Pipe at the Outdoor Side Unit Tighten the flare nut of the connection pipe at the outdoor unit valve connector.
  • Page 33 Floor Ceiling Type Unit 5.2.7 Liquid Pipe and Drain Pipe (1). If the outdoor unit is installed lower than the indoor unit. (See Fig. 15) 1). A drain pipe should be above ground and the end of the pipe does not dip into water. All pipes must be restrained to the wall by saddles.
  • Page 34 Floor Ceiling Type Unit 5.3.1 Vacuum (1). Remove the caps of the liquid valve, gas valve and also the service port. (2). Connect the hose at the low pressure side of the manifold valve assembly to the service port of the unit’s gas valve, and meanwhile the gas and liquid valves should be kept closed in case of refrigerant leak.
  • Page 35 Floor Ceiling Type Unit Fig. 17 Note: For the large-sized unit, it has the service port for both the gas valve and the liquid valve. During evacuation, it is available to connect two hoses of the manifold valve assembly to two service ports to quicken the evacuating speed.
  • Page 36 Floor Ceiling Type Unit (1). Keep piping as short as possible and slope it downwards at a gradient of at least 1/100 so that air may not remain trapped inside the pipe. (2). Keep pipe size equal to or greater than that of the connecting pipe. (3).
  • Page 37 Floor Ceiling Type Unit Fig. 21 Fig. 22 Fig. 23 Tighten the clamp until the screw head is less than 4 mm from the hose. (Fig. ①- Metal clamp ②- Drain hose ③- Grey tape Insulate the pipe clamp and the drain hose using heat insulation sponge. (Fig. ①- Metal clamp ②- Insulation sponge (1).
  • Page 38 Floor Ceiling Type Unit Fig. 24 5.4.4 Testing of Drain Piping After piping work is finished, check if drainage flows smoothly. (1). As shown in the Figure, pour water into the drain pan from the right side to (2). check that water flows smoothly from the drain hose. Fig.
  • Page 39 Floor Ceiling Type Unit The special branch circuit breaker is installed in the permanent wiring. Always use a circuit ⑤. that can trip all the poles of the wiring and has an isolation distance of at least 3 mm between the contacts of each pole. Perform wiring work in accordance with standards so that the air conditioner can be ⑥.
  • Page 40 Floor Ceiling Type Unit Fig. 26 Fig. 27 WARNING! Before starting work, check that power is not being supplied to the indoor unit and outdoor ① unit. Match the terminal block numbers and connection cord colors with those of the indoor unit ②...
  • Page 41 Floor Ceiling Type Unit (4). Electric wiring between the indoor and outdoor units Single-phase units (9~24k) N(1) green white black (yellow- (blue) (brown) green) Outdoor unit connection...
  • Page 42 Floor Ceiling Type Unit (5). Electric wiring of indoor unit side Remove the left cover plate and the electric box cover then insert the end of the communication cord and the power cable into the terminal board. Electric box cover Left side panel Fig.
  • Page 43 Floor Ceiling Type Unit 7 Test Running 7.1 Trial Operation and Testing The meaning of error codes as shown below: (1). Table Number Error code Error Compressor high pressure protection Indoor anti-freeze protection Compressor low pressure protection, refrigerant lack protection and refrigerant colleting mode Compressor high discharge temperature protection AC over-current protection Communication error...
  • Page 44 Floor Ceiling Type Unit States of the Indicating Lamps: ①. Indicating Lamp of “POWER”: The indicating lamp will shine when power on, while it will go out when power off. ②. Indicating Lamp of “COOL” : The indicating lamp will shine when “COOL” is activated, while it will go out when “COOL”...
  • Page 45 Floor Ceiling Type Unit ① ② ③ ④ ① ② ③ (114.8°F). ① ② ③ ④ ⑤ ⑥ ⑦ ① ② ③ ④ ⑤ (23°F). ⑥ Note:...
  • Page 46 Floor Ceiling Type Unit 9 Specialist’s Manual Aptitude requirement for maintenance If any hot work is to be conducted on the refriger- man(repairs s hould be done only be ating equipment or any associated parts, appro- specialists). priate fire extinguishing equipment shall be avail- able to hand.
  • Page 47 Floor Ceiling Type Unit resistant to being corroded or are suitably protect- most refrigerants but the use of detergents con- ed against being so corroded. taining chlorine shall be avoided as the chlorine may react with the refrigerant and corrode the Checks to electrical devices ●...
  • Page 48 Floor Ceiling Type Unit Charging procedures ● Do not overfill cylinders. (No more than 80% volume liquid charge). In addition to conventional charging procedures, Do not exceed the maximum working pressure the following requirements shall be followed. of the cylinder, even temporarily. –...
  • Page 49 Floor Ceiling Type Unit to an acceptable level to make certain that flam- mable refrigerant does not remain within the lubricant. The compressor body shall not be heated by an open flame or other ignition sources to accelerate this process. When oil is drained from a system, it shall be carried out safely.
  • Page 50 GREE ELECTRIC APPLIANCES, INC. OF ZHUHAI Add: West Jinji Rd, Qianshan, Zhuhai,Guangdong, China, 519070 Tel: (+86-756) 8522218 Fax: (+86-756) 8669426 E-mail: global@cn.gree.com Web: www.gree.com 600005068091...
