MULTICODE NXT-S
8
9
10
11
14
15
1. Tablet.
2. Soporte tablet.
3. Pomos tablet.
4. Guarda trasera.
5. Enchufe alimentación.
6. Seta emergencia.
7. Bandeja viruta.
8. Luz led.
9. Display.
10. Fresa serreta.
11. Mordaza MP1.
12. Carro XY.
13. Guarda transparente.
14. Conector USB Tipo B.
15. Conector USB Tipo A (Carga Tablet)
1
13
12
5
3
1. Tablet.
2. Tablet stand.
3. Tablet knobs.
4. Rear guard shield.
5. Power plug.
6. Emergency stop button.
7. Swarf tray.
8. LED light.
9. Display.
10. Cylinder cutter.
11. MP1 clamp.
12. XY carriage assembly.
13. Transparent protective guard shield.
14. Type B USB connector.
15. Type A USB connector (tablet charging).
17
ES / EN
7
