IS32L3183A DEMO KIT USER GUIDE
BILL OF MATERIALS
Name Symbol
IC U1
Capacitor C1, C2
Capacitor C3
Capacitor C4
Capacitor C5
Resistor R1, R2, R3
Resistor FB1
LED LD1
Diode D1
Diode D2
Connector CN4, CN5
Lumissil Microsystems – www.lumissil.com
Rev. C, 10/09/2023
Description
Constant current LED driver
CAP,0.1µF/50V,SMD,0603
CAP,4.7µF/50V,1206
NC
CAP,100pF/50V,0603
RES,200R,1206
RES,0R,0805
LED, RGB, LRTBGVSG
DSS26, SOD-123FL
PESD1CAN, SOT23
2.0mm-4PIN
Figure 9 IS32LT3183-GRLA3-EBGUI Evaluation Board Layout - Top Layer
Figure 10 IS32LT3183-GRLA3-EBGUI Evaluation Board Layout - Bottom Layer
Qty Supplier
1 Lumissil IS32LT3183A-GRLA3-TR
2 Yageo
1 Yageo
1
1 Yageo
3 Yageo
1 Yageo
1 OSRAM
1 JSCJ
1 Nexperia
2
Part No.
AC0603KKX7R9BB104
CC1206KKX7R9BB475
AC0603KKX7R9BB101
AC1206FR-07200RL
AC0805JR-07000RL
LRTB_GVSG
DSS26
PESD1CAN
X4611WV-04I
