PROXIMA CL

OPERATOR´S MANUAL

01/2022

100

110

Tractor is Zetor. Since 1946.

Need help?

Do you have a question about the Proxima CL 100 and is the answer not in the manual?

Questions and answers

Summary of Contents for Zetor Proxima CL 100

Page 1 PROXIMA CL OPERATOR´S MANUAL 01/2022 Tractor is Zetor. Since 1946.
Page 2 ZETOR This Operator’s Manual for the Zetor tractors, which we are presenting to you will help you to become familiar with the operation and maintenance of your new tractor. Although many of you have rich experience with the operation of other tractors, please, read the information contained in this Operator’s Manual very carefully.
Page 4 Aggregation tractor - machine/trailer ......................25 Tractors equipped with front end loader ...................... 25 Principles for operating tractors equipped with front end loader ..............26 Zetor tractors used for work in the woods ....................27 Safety labels ..............................27 Preventive daily service ..........................29 Preventive daily maintenance........................
Page 5 CONTENTS Fast heating of the cabin area ........................42 Fast cooling of the space of the cabin ......................42 Immediately after cooling the cabin ......................43 Operation of heating or air-condition with tractor´s work ................43 Heating and air conditioning vents ......................44 Heating and air conditioning vents control ....................
Page 6 CONTENTS Replenish fuel .............................. 70 Add urea ..............................70 High temperature of the cooling liquid ......................71 Full pushing filter of the hydraulics ......................71 Signalling of driver's seat ..........................71 System of additional treatment of exhaust gases ..................73 Conditions for dpf operation ........................
Page 7 CONTENTS Limiting travel speed ............................ 98 Running-in the tractor ............................ 99 General principles of new tractor run-in in first 100 hours of operation ............99 In first 10 hours of operation ........................99 From 100 hours of operation ........................99 Transport use ..............................
Page 8 CONTENTS Quick-couplings with drip collection ......................130 Connecting and disconnecting quick-couplers ..................130 Amount of oil taken from outer hydraulic drives ..................131 Connecting machines and tools to external hydraulic circuit ..............131 Hitches ................................133 Rear three-point hitch ..........................133 Safety principles of working with the three-point hitch ................
Page 9 Liquid for the cooling system of the tractors ....................162 Liquid for control of the travel clutch ......................162 Fuel for zetor engines which are equipped with diesel paricle filter ............162 Urea (urea solution aus 32) ........................162 Safety instructions for lubrication of the tractor ..................163 Tractor greasing plan ..........................
Page 10 CONTENTS Air-conditioning maintenance ........................182 Maintenance - exhaust system ........................182 Draining condensate from the air reservoir ....................182 Checking the air systems for leaks ......................182 Working pressure of air brakes ......................... 183 Maintenance and treatment of tyres ......................183 Tractor shutdown and recommended points for tractor lifting ..............
Page 12 LOCATION OF SERIAL NUMBERS PCLS5N004.gif 1. Tractor data plate 2. Cab serial number 3. Engine serial number 4. Tractor serial number When ordering spare parts and within all written and oral communication always specify the data of your tractor that should be written in the frames below. Tractor type Tractor serial number Engine serial number...
Page 13 LOCATION OF SERIAL NUMBERS The 'right', 'left', 'front' and 'back' indications refer to the driving direction of the tractor. PCLS5N005...
Page 14 SAFETY INSTRUCTIONS FOR USERS Pay increased attention to the parts in the instructions for use and maintenance indicated with this symbol. The symbol can be found next to all important warnings related to the operational safety. Follow these warnings and be particularly careful in these situations! Inform your colleagues and other users about these warnings.
Page 15 SAFETY INSTRUCTIONS FOR USERS Used pictograms Engine oil pressure Front axle drive Engine failure Differential lock Engine coolant temperature Slow operation Engine air filter clogged Fast operation Engine emissions system, failure or Hydraulic system sensitivity control malfunction Engine emissions system temperature, Three-point hitch, lowering speed control regeneration underway DPF filter clogged...
Page 16 SAFETY INSTRUCTIONS FOR USERS Read operator's manual Rear work light Service indicator Work light Information alert Interior compartment illumination Operator alert Beacon Engine, urgent stop High beam Engine glow plugs Rear fog lights Battery charging condition Windscreen wiper, intermittent Fuel Windscreen washer and wiper Hourmeter Rear window wiper...
Page 17 SAFETY INSTRUCTIONS FOR USERS Seat occupant switch Seat adjustment, longitudinal (fore and aft) Seat adjustment, seatback recline Bottom seat cushion-Longitudinal adjustment controller Seat turning controller Seat tilt controller...
Page 18 SAFETY INSTRUCTIONS FOR USERS General safety regulations • The tractor may only be operated by a trained person that has a valid driving licence and has been thoroughly acquainted with the operation and safety rules. • Besides the safety instructions mentioned in the Operator´s Manual you are obliged to respect generally valid safety and traffic rules of the country where the tractor is used.
Page 19 • During aggregation of Zetor tractors with machines and implements with high tensile resistance when the engine speed drops and the engine tends to stall, the 1R, 2R, 3R reduced gears must not be used...
Page 20 SAFETY INSTRUCTIONS FOR USERS Risk of the tractor overturning The risk of the tractor overturning is increased especially when the following is used: • a narrow wheel gauge • inappropriate tractor travelling speed • travel on the slope along a contour line or turning on the slope •...
Page 21 SAFETY INSTRUCTIONS FOR USERS Leaving the tractor • Park the tractor only on an even land and where not possible, support with a shim assy. • Do not park the tractor with an attached implement in the lifted position. • Usually use the left-hand side tractor door when leaving the tractor. Look round whether any vehicle is coming, that could jeopardize your safety when leaving the tractor.
Page 22 SAFETY INSTRUCTIONS FOR USERS Health and environment protection • The tractors are not equipped with special filters of air aspirated to the cab. Therefore, they are not designed for work with aerosols and other harmful substances. • Coolant, brake liquid, kerosene, diesel fuel, mineral oil and other oil products that are used for the operation and maintenance of the tractor may cause various skin disorders in case of direct contact with your skin and can irritate mucous membranes, eyes, the digestive system and upper respiratory ways.
Page 23 • When handling the battery you must pay increased attention and avoid short-circuits. In tractors equipped with a battery disconnector switch the disconnector off when handling the battery. • Zetor tractors must not be operated with a disconnected battery as this may lead to a serious failure of the tractor.
Page 24 PCLP18N003 is operated. Protection of cab against aerosols The cab of Zetor tractors in standard version is not designed for work with aerosols and other harmful substances. The level of protection of the cab in the standard version is in accordance with standard EN 15 695-1:2017, category 2 (dustproof cab only).
Page 25 83,5 The level of vibrations on driver´s seat ZETOR tractors are classified in the category A and the class I/II/III. The category A includes all tractors with specified levels of vibration due to similar specifications of the construction. The following table presents the results of the measurement on the test bench according to the Commission Delegated Regulation (EU) No.
Page 26 Tractors equipped with front end loader Zetor Tractors in standard design are designed for utilization in agriculture and are not designed for special purposes. Tractors designed for operation within the European Union must be equipped, in case of using front end loader, with a protective structure (FOPS - Falling Object Protective Structure) protecting drivers from potential falling objects.
Page 27 ZETOR´s ap-proval. The loader may become dangerous as a result of not observing these instructions. ZETOR TRACTORS shall not be held responsible in case of any damage or injury. • Use front end loader without additional weights on the tractor (danger of mutual contact). The load of front and rear drive axle must not exceed the maximum permitted load listed in the manual.
Page 28 Standard tractors Zetor do not provide sufficient protection for operation in forest terrain as, for example, protection against a fal-ling tree or branch on a cab or penetration of objects to a cab. If Zetor tractor is utilized for forest work, a tractor operated within the European Union must be protected against these risks.
Page 29 NOTES...
Page 30 PREVENTIVE DAILY SERVICE Preventive daily maintenance Perform this maintenance daily or after every 8 - 10 hours of operation at the latest. PCLS5N006.gif Fuel system leaks Check the fuel system, including the fuel tank, for leaks. Repair leaks immediately. The fuel tank drain bolt is at the bottom of the tank.
Page 31 PREVENTIVE DAILY SERVICE Windshield washer tank PHSS5N105 Washer nozzle PCLS5N010 The liquid reservoir for control of the clutch PCLS5N017 Trailer brakes Trailer air brakes Trailer hydraulic brakes...
Page 32 PREVENTIVE DAILY SERVICE Hydrostatic steering Oil for hydrostatic control is pumped from the gearbox cartridge • check the oil level in the gearbox • check the tightening of the nuts and bolts of the control rods and levers • check the condition of all the hoses of the hydraulic control circuit for damage and oil leakage PCLPNN072 Air cleaner...
Page 33 PREVENTIVE DAILY SERVICE Inspection of fouling of coolers After opening the bonnet, check that cooler fins are not clogged with engine coolant and AC condenser, and also the front PTO oil cooler, and transmission oil cooler if the tractor is equipped with them. In case of clogging, clean the cooler fins with compressed air.
Page 34 ACQUAINTANCE WITH TRACTOR Tractor user must be properly acquainted with recommended operating and safety rules for safe tractor operation in advance. It is too late to do it within operation! Opening the bonnet To open the bonnet: Press the appropriate tool (e.g. screwdriver) against the rod (1) in the direction of the arrow to unlock the bonnet.
Page 35 ACQUAINTANCE WITH TRACTOR Opening the door from the inside 1. Lever for opening the door from the inside 2. Lever for opening the door from the inside The door is held by a gas strut with a full opening. It is forbidden driving with open door due to its possible damage.
Page 36 ACQUAINTANCE WITH TRACTOR Sun visor and hinged lid cover Pull out the sun visor of the windscreen (1), by pulling the handle in the direction of the arrow. To return to the starting position, briefly press the button (2). The sliding hinged lid cover (3) closes and opens by pushing or pulling the slots in the direction of the arrow.
Page 37 ACQUAINTANCE WITH TRACTOR Right rear panel The following parts are placed on the right rear panel: 1 - two-pin socket 12V, (+) pole is marked in red 2 - lighter 3 - three-pin socket 12 V PGPPN166 Internal lighting To be turned on and off by means of a button marked with the arrow.
Page 38 ACQUAINTANCE WITH TRACTOR Passenger´s seat Passenger´s seat is tiltable and placed on the left mudguard of the cabin. P15N028 Seat tilting out Passenger´s seat to be tilted out in the direction of an arrow (1) upward. Locking of the seat is done automatically.
Page 39 ACQUAINTANCE WITH TRACTOR Driver's seat Sears PGPPN124 The Sears driver's seat can be equipped with mechanical (A) or pneumatic (B) suspension. 1 - Seat suspension control according to the driver's weight (adjustment by rotation, direction according to the pictogram on the seat bellows) 2 - Seat height adjustment control (releasing the control - higher seat, tightening the control - lower seat) 3 - Lateral seat adjustment lever (after raising the lever, the seat can be adjusted laterally, the lever is locked by returning the lever to its original position)
Page 40 ACQUAINTANCE WITH TRACTOR Tilt steering wheel Adjusting the angle of the wheel The angle can be adjusted by tilting the wheel after it is unlocked by moving the lever (1) in the direction shown by the arrow. After adjusting, lock the wheel by pressing the lever (1) in the opposite direction than shown by the arrow.
Page 41 ACQUAINTANCE WITH TRACTOR Heating control panel, * air-condition As standard, the tractor is fitted with a heating panel without air conditioning and air recirculation. The standard panel can be replaced on request. The heating and air conditioning control panel is located on the right side of the cab roof ceiling.
Page 42 ACQUAINTANCE WITH TRACTOR Cab air recirculation control (D) Press button (D) to switch on and off the full internal air recirculation - Internal air recirculation switched off (indicated by the yellow control light), external air is sucked through the filters into the cab - Internal air recirculation switched on (indicated by the yellow control light), air is drawn from the cab and blown back into the cab, (internal air recirculation for quick...
Page 43 ACQUAINTANCE WITH TRACTOR Fast heating of the cabin area Fast heating of the cab compartment is only possible if the heating panel is equipped with internal recirculation. As standard, the tractor is fitted with a panel without air recirculation and air conditioning.
Page 44 ACQUAINTANCE WITH TRACTOR Immediately after cooling the cabin Immediately, after the cab has cooled down and the internal temperature has been lowered to the desired value, we recommend: 1 - Switch off the internal air circulation by pressing the button (D) 2 - By opening the heating valve (A), perform the continuous regulation of the air temperature, with the air conditioning on.
Page 45 ACQUAINTANCE WITH TRACTOR Heating and air conditioning vents Heating and air conditioning vents, front (A), side (B). PGPPN189 Heating and air conditioning vents control A - opening the vent - open the vent by pressing it, where indicated by the arrow B - closing the vent - close the vent by pressing the slat of the vent in the direction of the arrow C - change the direction of air flow from the vent - set the...
Page 46 ACQUAINTANCE WITH TRACTOR Control panel on right cab pillar 1 - front windscreen wiper cycler switch. 2 - washer button 3 - front windscreen wiper switch. 4 - rear windscreen wiper switch. 5 - switch for heating the rear-view mirrors. 6 - rear window heating switch 7 - front work light switch.
Page 47 ACQUAINTANCE WITH TRACTOR Rear window wiper The rear window wiper switch is located on the right pillar of the cab. The single-speed wiper of the rear window is controlled by a single-position switch. 0 - rear window wiper off 1 - rear window wiper on F18N012 Front and rear windscreen washer The button for controlling the front and rear windscreen...
Page 48 ACQUAINTANCE WITH TRACTOR Panel of the instrument panel PCLS5N013 1 - Reverse shift lever 2 - Combination switch (direction indicator, low beam, full beam, horn). 3 - Light switch (off, parking, main headlights). 4 - Dipped-beam switch in the tractor bonnet and dipped-beam switch on the tractor cab. * on request, this light switch on the tractor cab can be operated independently of the lights in the bonnet.
Page 49 ACQUAINTANCE WITH TRACTOR Switch of warning lights a - warning lights on b - warning lights off Function of warning lights is signalized by interrupted blinking control on the dashboard. PCLS5N016 Lights switch between the grill and the cabin The low beam lights on the brackets and under the cab roof must be adjusted correctly to prevent the drivers of oncoming vehicles to be dazzled.
Page 50 ACQUAINTANCE WITH TRACTOR Switch box Switchbox is placed on the dashboard, see arrow. PCLS5N024 Switch box key in the position (0) The voltage of all the equipment controlled via the key is disconnected. The key can be removed. PCLPN035 Switch box key in the position (I) The voltage is connected to all the equipment excluding starter.
Page 51 ACQUAINTANCE WITH TRACTOR Manual throttle A - Maximum speed of the engine B - Idle run The lever allows setting of speed of the engine within range A to B. PCLS5N025 Pedals and levers 1. Travel clutch pedal 2. Foot operated service brake pedals connected by latch 3.
Page 52 ACQUAINTANCE WITH TRACTOR Reversing lever F - forward driving; the lever in the front N - neutral position R - reverse driving; the lever in the back Shifting is performed when the tractor is idling. If the tractor is equipped with the reductor of crawling speeds, the reversing lever is not mounted.
Page 53 ACQUAINTANCE WITH TRACTOR PTO selection control lever P18N016 a - independent revolutions of the PTO shaft drive - revolutions are dependent on the engine revolutions n - neutral position b - dependent revolutions of the PTO shaft drive through the gearbox - revolutions are dependent on the shifted gear Shifting is performed when the tractor is idling.
Page 54 ACQUAINTANCE WITH TRACTOR Battery disconnector P18N100 The battery disconnector is located on the left side of the tractor behind the driver's stairs. A - Battery connected B - Battery disconnected C - Disconnector plate is located on the cover of the accumulator battery When the engine is switched off, the engine control unit remains active for about 2 minute because of storage of operation data.
Page 55 ACQUAINTANCE WITH TRACTOR Fuel tank The fuel tank is fitted at the right-hand tractor side. A plastic tank of 150 litres volume is mounted as a standard for all types of tractors. Do not step on the fuel tank! PCLS5N029 Add fuel only when the engine is stopped and the key in the switch box is in the position 0.
Page 56 INSTRUMENT PANEL Instrument panel - signal lamps P18N039 1 - green - signal lamp of left direction lamps 2 - blue - distance lights signal lamp Lights up with distance lights on. 3 - green - signal lamp of direction lights of the 1st trailer 4 - green - signal lamp of direction lights of the 2nd trailer 5 - orange - warning signal lamp 6 - blue - operational protection signal lamp.
Page 57 INSTRUMENT PANEL Instrument panel - instruments P18N040 A - coolant thermometer B - fuel gauge C - engine speedometer D - information display Instrument panel - buttons P18N041 A - reset button, exit from menu of the instrument panel B - enter button, entry to menu of the instrument panel, item selection confirmation in the instrument panel menu C - button for rolling up in the instrument panel menu D - button for rolling down in the instrument panel menu...
Page 58 INSTRUMENT PANEL Display description P18N042 The following values are displayed on the main display: 1 - neutral position of the reversing lever or the lever of the reductor of crawling speeds, according to the tractor equipment 2 - low air pressure indicator in the tractor's air pressure system 3 - graphical representation of air pressure in the air-pressure system of the tractor 4 - air pressure in the air-pressure system of the tractor 5 - viewing part of the display...
Page 59 INSTRUMENT PANEL When the key in the switch box is moved to position I, the home screen is displayed on the display. C15N030 After about three seconds the main screen is displayed on the display. 1 - total operating hours (the value cannot be reset) 2 - operating hours of the tractor since the last reset of the value 3 - total distance covered (the value cannot be reset)
Page 60 INSTRUMENT PANEL 1 - immediate fuel consumption in L/100 km 2 - average fuel consumption in L/100 km since the last reset of the value 3 - average fuel consumption in L/hour since the last reset of the value 4 - fuel consumed since the last reset of the value P18N046 1 - temperature of the engine cooling liquid 2 - accumulator battery voltage...
Page 61 INSTRUMENT PANEL Display - display of air pressure in the air-pressure system of the tractor P18N075 The air pressure in the tractor's air system is displayed on the instrument panel display. 1 - Air pressure symbol, white light, has no signaling function. 2 - Red display field, gradual filling of the field with red color indicates the increase of air pressure in the tractor's air-pressure system in the range from 0 bar to 4.5 bar.
Page 62 INSTRUMENT PANEL Display - resetting data P18N047 The procedure for resetting data on the main screens where the data can be reset is as follows: 1 - Use the buttons (C) and (D) to select display of the corresponding main screen. 2 - Reset the data by longer pressing of the button (A) (RESET).
Page 63 INSTRUMENT PANEL Display - indicator of service inspection intervals P18N070 The warning regarding an approaching maintenance date (service interval) is displayed if there are less than 25 operating hours remaining to the planned maintenance. The maintenance symbol (1) is shown on the display of the instrument panel. When the key in the switch box is moved from the position 0 to the position I, the main screen appears on the display and after several seconds the warning regarding an approaching maintenance (B) with the number of operating hours of the tractor (2) remaining to the maintenance date are displayed on the display.
Page 64 INSTRUMENT PANEL Error signalling Errors arising during tractor operation are indicated by switching the corresponding signal lamp, acoustic signal and error message in the instrument panel display. If the error is indicated, the signal lamp still glows, even though the display is switched to the next display. If the error is not eliminated or the indicated state has not returned to a normal state: the corresponding signal lamp glows...
Page 65 INSTRUMENT PANEL Description of the display of error messages 1 - The symbol of the defect significance. 2 - Node of the tractor where the defect appeared. 3 - Main display field - defect code. 4 - Secondary display field - defect specification. P18N074 Current error messages display - go to the ALARM screen to view the current error messages...
Page 66 INSTRUMENT PANEL Display - setting language mutation P18N077 Press the button (B) to enter the service menu 1 - use the buttons (C) and (D) to select the item Language; press the button (B) to enter the screen with language mutations. 2 - use the buttons (C) and (D) to select the required language mutation and press the button (B) for confirmation.
Page 67 INSTRUMENT PANEL Display - setting of day and night backlight of the display P18N098 Enter the display settings menu. a - Use the buttons (C) and (D) to select the item for the day display backlight. Long press the button (B) to enter the screen for the display backlight setting (b).
Page 68 INSTRUMENT PANEL Display - setting the automatic mode of the display backlight P18N099 Enter the display settings menu. a - Use the buttons (C) and (D) to select the item (1) for the automatic mode of the display backlight. Long press the button (B) to enter the screen for setting the automatic mode of the display backlight (b).
Page 69 INSTRUMENT PANEL Display - setting and calibration P18N078 Press the button (B) to enter the service menu 1 - use the buttons (C) and (D) to select the item Calibration; press the button (B) to enter the screen with the calibration menu. 1 - setting of display of revolutions of the rear PTO shaft - more information in the chapter POWER OF AGRICULTURAL MACHINES 2 - calibration of travel speed...
Page 70 INSTRUMENT PANEL Travel speed calibration PCLPN090 The instrument panel after assembly in the factory is calibrated. Perform a new calibration of the travel speed: - after a considerable tyre wear - when installing new tyres - during replacement of the instrument panel Calibration procedure - indicate the track of the length of 100 m on a suitable place - inflate the tractor tyres to the specified pressure;...
Page 71 INSTRUMENT PANEL System of treatment of exhaust gases - setting The regeneration of the diesel particulate filter in case of increased temperature of exhaust gases is performed at higher engine load. The system of regeneration of the diesel particulate filter DPF can be controlled through the menu of the engine setting on the instrument panel.
Page 72 INSTRUMENT PANEL High temperature of the cooling liquid PHS18N041 High temperature of the cooling liguid is indicated in several stages of warning A - informative - reduce the engine power B - warning - stop the tractor, set the engine to idling until the temperature of the cooling liquid is reduced C - caution - stop the engine, wait until the temperature of the cooling liquid is reduced and check the level of the cooling liquid;...
