5pc Woven C-Spring Chat Set with Gas Firepit
WARNING
Improper installation, adjustment, alteration, service or maintenance can cause injury or
property damage. Read the installation, operating and maintenance instructions thoroughly
before installing or servicing this equipment.
Propane tank not included.
AAA battery included.
ASSEMBLY INSTRUCTIONS
IMPORTANT: Please read this manual carefully before beginning assembly of this product.
Keep this manual for future reference.
Ver： 1/12/2021
INSTRUCTION MANUAL
Model No.: 113-P80-5CS-GFP-V1
(Table)
Advertisement
Related Manuals for Pacific Casual 113-P80-5CS-GFP-V1
Summary of Contents for Pacific Casual 113-P80-5CS-GFP-V1
- Page 1 INSTRUCTION MANUAL 5pc Woven C-Spring Chat Set with Gas Firepit (Table) Model No.: 113-P80-5CS-GFP-V1 WARNING Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Read the installation, operating and maintenance instructions thoroughly before installing or servicing this equipment.
- Page 2 WARNING For Outdoor Use Only. DANGER If you smell gas: 1. Shut off gas to the appliance. 2. Extinguish any open flame. 3. If odor continues, keep away from the appliance and immediately call your gas supplier or fire department. WARNING Do not store or use gasoline or other flammable liquids or vapors in the vicinity of this or any other appliance.
- Page 3 TABLE OF CONTENTS Specifications...........................4 Safety Warning.........................5 Replacement Parts List (I)......................7 Replacement Parts List (II）....................8 Installation..........................9 Location.........................9 Set Up..........................9 Gas Connection......................10 Leak Check ........................11 Operation..........................11 Lighting.........................11 Shut Down the Gas Appliance..................13 How to Disconnect the Cylinder..................13 Storage and Maintenance......................13 Trouble Shooting........................14 Cleaning and Maintenance.......................14 One Year Limited Warranty.......................15 Gas Cylinder Required......................15...
- Page 4 SPECIFICATION 5pc Woven C-Spring Chat Set Product Name with Gas Firepit (Table) 113-P80-5CS-GFP-V1 Model No. Rated Heat input 40,000 BTU/hr Fuel Propane Gas Supply 20-lb LP gas cylinder Manifold Pressure 11 in. water column Orifice Size (diameter) 1.9 mm Gas Supply Pressure 250 PSI (max) 106.5 x 106.5 x 61.5 cm ;...
- Page 5 SAFETY WARNINGS • When the appliance is connected to a fixed-gas system, the installation must conform with local codes, or in the absence of local codes with the National Fuel Gas Code, ANS Z223.1 /NFPA54; International Fuel Gas Code, Natural Gas and Propane Installation Code, CSA B149.1; or Propane Storage and Handling Code, B149.2, as applicable.
- Page 6 • Children and adults should be alerted to the hazards of high surface temperatures and should stay away to avoid burns or prevent clothing ignition. • Young children should be carefully supervised when they are in the area of the appliance. •...
- Page 7 REPLACEMENT PARTS LIST (I) Part Quantity Description Quantity Part Description Cover Door handle (right) Table top Lava glass 1BOX Main frame Left access door Right access door Door handle (left)
- Page 8 REPLACEMENT PARTS LIST (II) Part Description Quantity Part Description Quantity Electronic igniter button Fire bowl (with battery box) Ignitor block Gas control knob Burner Hose Pressure regulator Ignition wire Thermocouple Knob Valve Hose...
- Page 9 Installation Location Your gas appliance must be installed on a flat, stable surface, away from any combustible materials or construction. Installation will be much easier with two or more people. Minimum clearance from combustible constructions: rear and side: 40 in. / 1016 mm, top 72 in. / 1829 mm. (Fig.1) Fig.1 Set Up Your gas appliance comes assembled, ready for a gas connection.
- Page 10 3. Unscrew the battery box, insert the negative electrode side of the battery into the bottom of the battery box. (Fig.6) NOTE: The battery is located in the plastic bag with the instruction manual. Fig.6 NOTE: Please follow the above instructions to replace the battery when needed. Gas Connection 4.
- Page 11 Leak Check WARNING!!! Do not use an open flame to check for leaks. Do not smoke during testing. Do not test indoors. A leak check must be performed whenever the gas cylinder is replaced. NOTE 1. Make sure the gas control knob (I2) is in the “OFF" position. Open access doors. 2.
- Page 12 Shut Down the Gas Appliance 1. Press in and turn the gas control knob (I2) to “OFF” to shut down appliance. 2. Turn the gas cylinder valve (1) off when the gas appliance will not be in use. WARNING Do not try to cool lava glass with cold water right after shutting down the gas appliance or they will get crack.
- Page 13 TROUBLE SHOOTING PROBLEM OBSERVED POSSIBLE CAUSE CORRECTIVE MEASURES Gas odor Gas leak Perform "Leak Check" on page 11. If odor continues shut off gas supply and contact your customer service department. Delayed ignition Low gas pressure Check gas supply pressure. Clogged or dirty burner ports.
- Page 14 ONE YEAR LIMITED WARRANTY Subject to the conditions set out below, this product is warranted to the original purchaser to be free from defects in workmanship and materials for one (1) year from the date of purchase. • Dated proof of purchase is required at the time of the warranty claim is submitted. •...
- Page 15 Serial No. : 2020JWD010-1 Supplier: Pacific Casual L.L.C. Address: 1060 Avenida Acaso, Camarillo, CA 93012 TEL: 888-445-6690 (7:30 am to 4:30 pm, Pacific Standard Time, Monday to Friday) Email:CustomerService@PacificCasual.com...
