Assembly Instructions
5pc Woven C-Spring Chat
Set with Gas Firepit
(Chairs)
Model # 113-P80-5CS-GFP-V1
Customer Service:
Pacific Casual L.L.C.
TEL:888-445-6690
(07:30am-4:30pm PST, Monday to Friday)
CustomerService@PacificCasual.com
Discription
Back
Armrest (Left)
Armrest (Right)
Cross Bar
Wrench
Bolt Cover
Bolt
M6X10MM
Bolt
M6X40MM
Steel Washer
Qty
4
4
4
4
1
40
8
32
40
