- Page 1 WOOD PELLET GRILLS ZPG-6002B OWNER’S MANUAL MON TO FRI, 8:00 A.M. - 5:00 P.M. PACIFIC STANDARD TIME SERVICE CONTACT: 1-833-947-4557/1-833-ZGRILLS EMAIL: support@zgrills.com WEBSITE: www.zgrills.com VN122024...
- Page 3 CONTENTS IMPORTANT SAFETY INFO COMPONENT LIST ASSEMBLY INSTRUCTIONS SUBSEQUENT START-UP OPERATING TIPS MAINTENANCE & CLEANING TROUBLESHOOTING DIGITAL THERMOSTAT CONTROL WIRING DIAGRAM Z GRILLS SUPPORT 3-Y LIMITED WARRANTY INITIAL FIRING INSTRUCTIONS...
- Page 4 SAVE THIS MANUAL FOR FUTURE REFERENCE...
- Page 5 IMPORTANT SAFETY INFO GENERAL WARNINGS Please read this entire manual before installation and use of the pellet fuel-burning appliance. Failure to follow these instructions could result in property damage, bodily injury or even death. Contact local building or fire officials about restrictions and installation inspection requirements in your area.
- Page 6 DO NOT place anything heavy on top of hopper lid. It is not a shelf and is a tip hazard. Never use gasoline, gasoline-type lantern fuel, kerosene, charcoal lighter fluid, or similar liquids to start or ‘freshen up’ a fire in this appliance. Keep all such liquids well away from the appliance when in use.
- Page 7 There is no guarantee that other brands of pellets are suitable for use in Z GRILLS. And Z GRILLS assumes no liability for any loss, damage or injury caused by the use of any other brands of pellets.
- Page 8 COMPONENT LIST ITEM DESCRIPTION ITEM DESCRIPTION Grill Chamber Assembly Chimney Cap Assembly Furnace Hinge Upper Hopper Safety Grate Lid Hinge Fixed Plate Lid Handle Digital Control Hopper Burner Lid Lower Hopper Safety Grate Hopper Assembly Cable Clip Hopper Handle Power Cord Grease drain pan left support Hot Rod (Ignitor) A RTD Temperature Probe...
- Page 9 HARDWARE PACKAGE LIST ITEM DESCRIPTION ITEM DESCRIPTION Step Screws 1/4-20 Bolt 1/4-20× 1/2 Gasket (Ø0.79*Ø0.26) Bolt 1/4-20×32 Tapping Screw 1/3 Bolt 8#-32×3/8 Pin Shaft Hexagon Nut 1/4-20 8#-32 Hexagon Kep Nut Step Screw 8#-32 Hexagon Bolt 1/4-20×1/2 Open End Wrench Bolt 8#-32×...
- Page 10 ASSEMBLY INSTRUCTIONS PARTS DIAGRAM HOPPER BURNER ASSEMBLY...
- Page 11 BODY FRAME ASSEMBLY 1.MOUNTING THE BODY FRAME 1.Insert the Left Front Leg (45) and Left Rear Leg (44) into the Food Pads (46). 2.Secure Legs (44)(45)(50)(51) on the Bottom Plate (47) with Bolt (A). 3.Insert the Axle (49) through the holes in the Bottom Plate (47) and Legs (50)(51), assemble the Nut (I) onto the Axle (49)through wheels(48).
- Page 12 2.MOUNTING THE BODY FRAME TO THE CHAMBER 1.With the help of another person, carefully attach the Grill Chamber Assembly (1) on the Body Frame and using Bolt (A). Use the Screwdriver (Q) to tighten. Caution: The grill is very heavy. Always lift the grill with 2 people. 3.MOUNTING THE HOPPER TO THE CHAMBER 1.Insert Bolt (C) into Hopper Burner Lid (6) and Hopper Assembly (7), align the holes, then assemble it with Nut (O).
- Page 13 4.Locate the RTD Male Plug-In-Connector coming from the Grill Chamber Assembly. It will look like a loose wire with a connector on the end. Locate Connect the RTD Female Plug-In-Connector coming from the Hopper Assembly. Connect the two RTD Plug-In-Connectors together. Pull the RTD wire down so that it is sandwiched between the hopper and the chamber.
- Page 14 5.ATTACHING THE SIDE TABLE 1.Assemble Side Table (26) to the Grill Chamber Assembly (1) with Bolt (A). 2.Assemble Bottle Opener (23) to the Grill Chamber Assembly (1) with Bolt (C). 3.Assemble Step Screw (F) to the Side Table (26). 6.LID ASSEMBLY 1.Insert the Bolt (G) through Gasket (K) and Lid (4) and into the Lid Handle (5).
- Page 15 7.Windshield,Feeder ASSEMBLY ssembly Windshield,Feeder(54) to feed pipe as the photo shown. 8.ATTACHING THE IGNITION ROD Take out Feeder Assembly(53),put in place as shown below photo,Connect the ignition rod B(38) with Hot Rod (Ignitor) A (37) as shown .
- Page 16 9. ATTACHING BURNER BOX 1.Assemble the Feeder Assembly(53) to the Grill Chamber with Bolt (H). 2.Use Screw(L)to fix the Windshield,Feeder. 10.POSITIONING THE GREASE DRAIN PAN LEFT SUPPORT Assemble the grease drain pan left support (9) to Chamber with Bolt (A).
- Page 17 11.POSITIONING THE GREASE DRAIN PAN BOTTOM SUPPORT 1.Assemble the grease drain pan bottom support (19) to Chamber with Bolt (C) and Nut (O). 12.POSITIONING THE GREASE DRAIN PAN BOTTOM SUPPORT Pass the Oil connecting pipe Assembly（56） through the furnace body and fix it with screws（H) and nuts(O).
- Page 18 13.POSITIONING THE GREASE DRAIN PAN BOTTOM SUPPORT Insert the Oil Trap Assembly (55) into the oil leakage pipe weldment, and use screws(C) to fix it to the lower support of the oil collection pan. 14. POSITIONING THE GREASE DRAIN PAN 1.Clip the Grease Drain Pan Left Support(9) into the mounting hole of the Grease Drain Pan(18) 2.Take out Grease Drain Pan Cover(17) on the Grease Drain Pan(18).
- Page 19 15. POSITIONING PULL ROD,GREASE DRAIN PAN HANDLE 1.Thread one end of the pull rod ,grease drain pan handle(24) into the hole of the Grill Chamber. 2.Use R Pin(N) to fix the other end of the pull rod ,grease drain pan handle(24) into the hole of Grease Drain Pan Cover(17).
- Page 20 WARING:BE CAREFUL NOT TO BURN YOURSELF WHEN USING THIS FEATURE. Z Grills most versatile pellet grills with direct flame capacity. You can not only smoke at temps of 180 but you can sear a steak at the temperatures up to 75(degrees for unparalleled flavor, restaurant-quality wood-fired grilling and unmatched searing and charring ability.lmportant Notes for Cooking in...
- Page 21 17.ATTACHING THE COOKING GRATE AND WARMING RACK Attaching the Porcelain Cooking Grates (16) and Warming Rack (15) in the Chamber. 18.HANG ON SPICE RACK Install step screws（J）into grill chamber(1),Hang on the spice rack（20） on the step screws（K）...
- Page 22 19.HANG ON THE GREASE BUCKET Hang the Grease Bucket (22) on the Step (J). Screws...
- Page 23 Temperature Dial to any cooking setting desired. 5.If this step is not successful, see TROUBLESHOOTING or contact Z GRILLS Technical Support to help diagnose the problem.
- Page 24 OPERATING TIPS 1.Like all grills, the actual temperature of this grill and the cooking times will be affected by external temperature, humidity, wind conditions, quality of pellets, etc. 2.It is beneficial to shelter your grill from the wind. This will aid in temperature output, heat retention and heat recovery time when the lid is open.
- Page 25 2.It is highly recommended that you use Z GRILLS Cover to protect your grill . 3.You can use a high-quality car wax on the outside surfaces of your grill to protect it’s finish.
- Page 26 Clean the ash from the interior of the grill periodically. If excessive ash is in the firepot, it may cause the fire to go out. This is especially true in the SMOKE setting. A shop vac is an excellent tool to use for removing the ash. WARNING: MAKE SURE THE GRILL FIRE IS OUT, THE UNIT IS OFF, UNPLUGGED AND COLD BEFORE ATTEMPTING TO CLEAN ASH FROM THE GRILL.
- Page 27 TROUBLESHOOTING CAUTION: Make sure the grill is completely cool and unplugged before you do any inspection, cleaning, maintenance or service work. Potential Problem Solution Cause Make sure the power cord is plugged Power in. Verify there is power at the electrical outlet.
- Page 28 Pellets pellets. When contacting customer support Contact please have the following information Z GRILLS available: Your authorized Z Grills Customer dealer, your name, phone number, Get your new parts Service or your address, your Z Grill serial number and Z GRILLS part identification number.
- Page 29 Supplementary Instruction Issue description: Plug the power cord and turn on the grill. If the temperature is not rising within 8-10 minutes, the grill is unsuccessfully ignited firstly. Please check: 1. The pellets are too wet. 2. Check the tip length of Hot Rod (at least 0.35 inch). Please adjust the tip length.
- Page 30 DIGITAL THERMOSTAT CONTROL WIRING DIAGRAM DIGITAL THERMOSTAT CONTROL WIRING DIAGRAM...
- Page 31 Thank you for purchasing a Z GRILL! If you have any question, please contact customer support or your Z GRILL dealer. Z GRILLS, INC. offers the best technical and sales support in the industry. When calling customer please be prepared to provide the following information: 1.Dealer's name and date of purchase...
- Page 32 Z GRILLS, Inc. shall not be liable if you install, operate, clean or maintain your grill without following the owners' manual instructions. Misuse, abuse, alteration and natural disasters...
- Page 33 Please read this manual carefully and follow it step by step before starting your Z Grills for the first time and each time the grill runs out of pellets. 1.Remove the Porcelain Grills, Warming Rack, Grease Drain Pan from the interior of the grill.
