- Page 1 Model numbers: EVO-COVER-XS, EVO-COVER-S, EVO-COVER-M, EVO-COVER-L, EVO-COVER-XL, EVO COVER-T EVOLAR COVER User manual...
- Page 3 FOREWORD Thank you for purchasing the Evolar cover. This manual contains all the information required for the safe and correct use and installation of the Evolar cover. Make sure you have read and understood the entire contents of this manual before installing or maintaining the product.
- Page 4 PRODUCT Description The Evolar cover is a heat pump/air conditioning enclosure. The Evolar cover is intended for use over installed heat pumps/air conditioners. This manual is suitable for the following Evolar covers: • Evolar XS (2' × 3' × 1' 4") •...
- Page 5 Optional parts Back panel Bottom panel Feet Tools required (not included) • Screwdriver • Drill with 8 mm (0.31 inch) and 10 mm (0.39 inch) bits. Evolar cover | User manual www.evolarshop.com...
- Page 6 Risk of damaging the surface of the product! Harsh chemical cleaning agents, such as ammonia, acid or acetone, can damage the product. • Only clean the product with a soft, clean, and dry cloth. • Avoid abrasives that could damage the surface. Evolar cover | User manual www.evolarshop.com...
- Page 7 Check that all parts are present and that they are not damaged. If parts are missing or damaged, contact Evolar. Installation steps STEP 1 Remove the film from the enclosure and the roof panel. STEP 2 Unfold the enclosure. Evolar cover | User manual www.evolarshop.com...
- Page 8 STEP 3 Fasten the corner profiles with the screws. STEP 4 Fasten the roof panel onto the enclosure with the screws. Evolar cover | User manual www.evolarshop.com...
- Page 9 If the heat pump requires more air, fold the folding edge of the top plate downwards. STEP 6 Drill the holes around your installed heat pump. Drill 10 mm (0.39 inch) holes in the wall using the drilling template supplied. Evolar cover | User manual www.evolarshop.com...
- Page 10 STEP 7 Screw the expansion bolts into the holes. STEP 8 Place the enclosure over the air conditioning/heat pump and/or expansion bolts. Evolar cover | User manual www.evolarshop.com...
- Page 11 OPTIONAL PARTS Feet STEP 1 Some Evolar covers already have pre-drilled holes. If not, drill 8 mm (0.31 inch) holes at the corners underneath the enclosure. STEP 2 Insert the feet in the holes and tighten them with the nut supplied.
- Page 12 Back panel STEP 1 Screw the back panel against the Evolar cover with the screws. Bottom panel STEP 1 Screw the bottom panel against the Evolar cover with the screws. Evolar cover | User manual www.evolarshop.com...
- Page 13 Follow the local regulations for disposing of the Evolar cover. WARRANTY The Evolar cover has a warranty period of 24 months. This warranty is void if the Evolar cover has been used differently than indicated in this manual. Evolar cover | User manual...
- Page 16 Evolar inc. 700 Milam Street, Suite 1300 - #353 Houston, Texas 77002 United States T +31 (0)24 2120369 EN – Original user manual www.evolarshop.com V1.0 | 09-2023...
