- Page 1 Model numbers: EVO-COVER-CENT-XL, EVO-COVER-EXT-XXL, EVO-LOUVRE-CENT-XL, EVO-LOUVRE-EXT-XXL EVOLAR EVO COVER User manual...
- Page 3 FOREWORD Thank you for purchasing the Evolar cover. This manual contains all the information required for the safe and correct use and installation of the Evolar cover. Make sure you have read and understood the entire contents of this manual before installing or maintaining the product.
- Page 4 PRODUCT Description The Evolar Evo cover is a heat pump/air conditioning/outdoor unit enclosure. The Evolar Evo cover is intended for use over installed heat pumps/air conditioners/outdoor units. This manual applies to the following Evolar Evo covers: • EVO-COVER-CENT-XL • EVO-COVER-EXT-XXL •...
- Page 5 Risk of injury! The product is designed for use as described in this document. Any usage of the product for purposes other than those specified in this document may lead to hazardous situations. Only use the product and the supplied tools as described in this document. Evolar cover | User manual www.evolarshop.com...
- Page 6 Front panel (1×) Hinge pin (6×) Hinge pin (4×) EVO-COVER-TOP Drilling template Expansion bolts (4×) Check that all parts are present and that they are not damaged. If parts are missing or damaged, contact Evolar. Evolar cover | User manual www.evolarshop.com...
- Page 7 Installation steps STEP 1 Remove all packaging material. STEP 2 6× Assemble the cover. NAVIGATION Installation without cover extension Step 3 Installation with cover extension Step 4 Evolar cover | User manual www.evolarshop.com...
- Page 8 STEP 3 Install the top cover. NAVIGATION Mounting to a wall Step 7 Mounting to the floor Step 10 STEP 4 4× Assemble the cover extension. Evolar cover | User manual www.evolarshop.com...
- Page 9 STEP 5 Install the top cover. STEP 6 Install the cover extension. NAVIGATION Mounting to a wall Step 7 Mounting to the floor Step 10 Freestanding The installation is finished. Evolar cover | User manual www.evolarshop.com...
- Page 10 STEP 7 Drill 10 mm (0.39 inch) holes in the wall around your air conditioning/heat pump using the drilling template. STEP 8 Screw the expansion bolts into the holes. Evolar cover | User manual www.evolarshop.com...
- Page 11 7× Screw the cover to the floor using the 8 mm holes at the bottom of the cover. Make sure to use a connection appropriate for the floor surface. NAVIGATION The installation is finished. Evolar cover | User manual www.evolarshop.com...
- Page 12 OPTIONAL PARTS Installing the back panel STEP 10 Install the back panel. STEP 11 If applicable, install the back panel extension Evolar cover | User manual www.evolarshop.com...
- Page 13 Risk of damaging the surface of the product! Harsh chemical cleaning agents, such as ammonia, acid or acetone, can damage the product. • Only clean the product with a soft, clean, and dry cloth. • Avoid abrasives that could damage the surface. Evolar cover | User manual www.evolarshop.com...
- Page 14 Follow the local regulations for disposing of the Evolar Evo cover. WARRANTY The Evolar Evo cover has a warranty period of 24 months. This warranty is void if the Evolar Evo cover has been used differently than indicated in this manual.
- Page 16 Evolar inc. 700 Milam Street, Suite 1300 - #353 Houston, Texas 77002 United States T +31 (0)24 2120369 EN – Original user manual www.evolarshop.com V1.0 | 09-2023...
