MiTAC MB2-10ANS User Manual

Master series embedded system intel alder lake-n processors efficient, compact, and reliable
Hide thumbs

Advertisement

Quick Links

Download this manual
MB2-10ANS
User Manual
V1.0
M
aster Series Embedded System
Intel® Alder Lake-N Processors
Efficient, Compact, and Reliable

Advertisement

loading
Need help?

Need help?

Do you have a question about the MB2-10ANS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MiTAC MB2-10ANS

Summary of Contents for MiTAC MB2-10ANS

  • Page 1 MB2-10ANS User Manual V1.0 aster Series Embedded System Intel® Alder Lake-N Processors Efficient, Compact, and Reliable...
  • Page 2 PREFACE Copyright Notice Copyright © MiTAC Digital Technology Corporation (MiTAC Group). No part of this document may be reproduced, copied, translated, or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the prior written permission of MiTAC Corp., Ltd. All information and specification provided in this manual are for reference only and remain subject to change without prior notice.
  • Page 3 Safety Information WARNING! / AVERTISSEMENT! Always completely disconnect the power cord from your chassis whenever you work with the hardware. Do not make connections while the power is on. Sensitive electronic components can be damaged by sudden power surges. Only experienced electronics personnel should open the PC chassis.
  • Page 4 Information Products Pollution Control Labeling Standard” of Chinese Mainland, marked with the Environmental Friendly Use Period (EFUP) logo. The number inside the EFUP logo that MiTAC uses (please refer to the photo) is based on the “Standard of Electronic Information Products Environmental Friendly Use Period” of Chinese Mainland.
  • Page 5 Ordering Information Model Number CPU Model COM / GPIO AC Adaptor MB2-10ANS-N97 2 x COM / None None MB2-10ANS-N97-AC 2 x COM / None 60W AC to DC Adaptor MB2-10ANS-N305 i3-N305 4 x COM / 8-bit GPIO None MB2-10ANS-N305-AC i3-N305...
  • Page 6 Packing List Q’ty Item Description MB2-10ANS Embedded System SATA Power Cable SATA Signal Cable Wall Mount Brackets (2 pcs in 1 set) Screw Pack (For HDD and Wall Mount Bracket) 2 x 2-pin Terminal Block Power Connector 1 x 10-pin Terminal Block Male Connector (for i3-N305 SKU only)
  • Page 7 Optional Accessories Model Number Description MB-01DINVESA-MPB2 1. Mechanical Adapter Bracket for MB2/MP2 (5412N8610001) 2. Din-rail + VESA 75x75mm holes Combo Mounting kit AC/DC 12V/5A, 60W 2PIN Terminal Block Power Adaptor with MPE-060W12-2TUE EU+US power cords 442110000189*1 332810000397*1 332810000281*1...
  • Page 8 CONTENTS CHAPTER 1: INTRODUCTION ......................10 1.1 Overview ..........................10 1.2 Product Features ........................10 1.3 Hardware Specification ......................11 1.4 Mechanical Specification ..................... 13 1.5 System I/O Placement ......................14 CHAPTER 2: JUMPER SETTING AND PIN DEFINITION ................. 16 2.1 Jumper and Internal Connector Overall Placement .............
  • Page 9 INTRODUCTION This chapter provides the MB2-10ANS Embedded System product overview, including features, hardware and mechanical specifications.
  • Page 10 I/O placement. 1.1 Overview MiTAC’s MB2-10ANS embedded system is the next generation embedded MB with Intel® Alder Lake-N (10nm manufacturing process) processor which improves performance and computing power by comparing to Elkhart Lake and Apollo Lake. This cost effective processor provides the solution for more complicated task and most types of application.
  • Page 11 1.3 Hardware Specification SYSTEM Intel® Alder Lake-N N97 (4C) / i3-N305 (8C8T) Processor System Memory DDR5 4800 MHz / 1 x 262-pin SO-DIMM / Max. 16GB (Non-ECC) ® Graphics Intel UHD Graphics Display Interface HDMI, DisplayPort Storage Slot 2 x SATAIII* / 1 x SATA power header 1 x M.2 2242/3042/3052 B Key (USB2.0/PCIeX1/SATAIII) 1 x M.2 2280 M Key (PCIeX1/SATAIII) *1 SATA port Multiplexed with M.2 B key SATA...
  • Page 12 Thermal Design Fanless 6.7” x 5.2” x 2.2” (171 x 133 x 57 mm) Dimension ENVIRONMENTAL Operating -25~60°C Temperature *with 0.7m/s Air Flow (w/ Extended Temp. SSD/mSATA/RAM) Storage Temperature -40 ~ 85°C Operating Humidity 10%~95% R/H (Non-condensing) Vibration Resistance Operating: 5Hz~500Hz / 2Grms / 3Axis (w/ SSD, according to IEC60068-2-64) Shock Resistance Operating: 50 Grms, Half-sine 11 ms Duration (w/ SSD, according to IEC60068-2-27)
  • Page 13 1.4 Mechanical Specification  Mechanical Dimension: 171 mm x 133 mm x 57 mm...
  • Page 14 1.5 System I/O Placement...
  • Page 15 JUMPER SETTING AND PIN DEFINITION This chapter provides information about how to set up the jumper and use internal I/Os of MB2-10ANS Embedded System hardware.
  • Page 16 CHAPTER 2: JUMPER SETTING AND PIN DEFINITION This chapter provides information about how to set up the jumper, and use internal I/Os of MB2-10ANS Embedded Motherboard hardware. 2.1 Jumper and Internal Connector Overall Placement TOP View...
  • Page 17 Bottom View PH10ANS Connector/ Header External power button T19 M2E_1 M.2 KEY E PWRBT_C1 DP(up)+ HDMI(lower) Display T20 FIO_PANEL1 Front panel header DPHDMI_1 Dual LAN ports T21 USB2_1 USB2 internal header DLAN1 T4 DUSB3_1 Dual USB3 ports T22 XBT1 RTC Battery header USB3 port(upper) T23 EBIOS1 BIOS...
  • Page 18 2.2 Jumper Setting MUX_1 M.2 B Key SATA Selection 331020000840 PIN1-PIN2 M.2 B key SATA Mode With JUMPER PIN2-PIN3 SATA1 Mode AT mode select 331020000840 PIN1-PIN2 AT Mode With JUMPER PIN2-PIN3 ATX Mode CMOS1 Clear CMOS 331020000840 PIN1-PIN2 RTC Reset With JUMPER PIN2-PIN3...
  • Page 19 2.3 Internal Connector Pin Definition COM12 COM1+ COM2 291000512046 PIN1 DCD1 PIN2 PIN3 RTX1 PIN4 DTR1 PIN5 RS232/422/485 COM1 PIN6 DSR1 PIN7 RTS1 PIN8 CTS1 PIN9 PIN10 PIN11 DCD2 PIN12 PIN13 RTX2 PIN14 DTR2 PIN15 RS232 COM2 PIN16 DSR2 PIN17 RTS2 PIN18 CTS2...
  • Page 20 PIN15 PIN16 DSR4 PIN17 RTS4 PIN18 CTS4 PIN19 PIN20 SATA_PWR1 SATA power header(4pins) 291000510408 PIN1 VCC3 PIN2 PIN3 PIN4 +12V SATA_PWR2 SATA power header(3pins) 291000510307 PIN1 PIN2 PIN3...
  • Page 21 DCIN1 DC IN header 331020000859 PIN1 PIN2 DC IN PIN3 DC IN PIN4 FIO_PANEL1 Front panel header 291020001029 USB2_1 USB2 internal header 291020000452 SPK_C1 Internal Speaker 291000510408 Left out + PIN1 PIN2 Left out - PIN3 Right out - PIN4 Right out +...
  • Page 22 AUD_H1 AUDIO header 291020000613 Headphone JACK Detect PIN1 Headphone OUT Left PIN2 PIN3 Headphone OUT Right PIN4 MIC-L/RING2 for TRRS PIN5 PIN6 MIC-R/SLEEVE for TRRS PIN7 PIN8 MIAPI_1 MiAPI header 291000512046...
  • Page 23 2.4 External Connector Pin Definition  2-pin Terminal Block for Power Button  2 x 2.5G LAN  2-pin Terminal Block for DC Input Signal +8~26VIN DC IN...
  • Page 24 SYSTEM SETUP This chapter provides information about how to set up the MB2-10ANS Embedded System hardware installation.
  • Page 25 CHAPTER 3: SYSTEM SETUP This chapter provides information about how to set up the MB2-10ANS Embedded System hardware installation.
  • Page 26 BIOS SETUP This chapter provides information about how to set up BIOS and use BIOS menu items to adjust basic function settings.
  • Page 27 CHAPTER 4: BIOS SETUP This chapter provides information about how to set up BIOS and use BIOS menu items to adjust basic function settings. 4.1 Main Page Field Name BIOS Vendor Default Value American Megatrends Comment This field is not selectable. There is no help text associated with it. Field Name Core Version Default Value...
  • Page 28 Comment This field is not selectable. There is no help text associated with it. Field Name Build Date Default Value Display build date of the BIOS Comment This field is not selectable. There is no help text associated with it. Field Name ME FW Version Value...
  • Page 29 4.2 Advanced Page Field Name Onboard Device Help Onboard Device Configuration. Comment Press Enter when selected to go into the associated Sub-Menu. Field Name CPU Configuration Help CPU Configuration Parameters. Comment Press Enter when selected to go into the associated Sub-Menu. Field Name Trusted Computing Help...
  • Page 30 Field Name S5 RTC Wake Settings Help Enable system to wake from S5 using RTC alarm Comment Press Enter when selected to go into the associated Sub-Menu. Field Name Network Stack Configuration Help Network Stack Settings. Comment Press Enter when selected to go into the associated Sub-Menu. Field Name NVMe Configuration Help...
  • Page 31 4.2.1 Onboard Device Field Name LVDS/eDP Panel Default Value [Disabled] Possible Value Enabled Disabled Help LVDS/eDP Panel Enable/Disable Field Name SATA1 Select Default Value [SATA1 Header] Possible Value M2B SATA_PCIE Slot SATA1 Header Help Select SATA1 device from M2B SATA_PCIE Slot or SATA1 Header Field Name Turbo Mode Default Value...
  • Page 32 (G3 state). Field Name Aperture Size Default Value [256MB] Possible Value 128MB 256MB 512MB 1024MB Help Select the Aperture Size Note : Above 4GB MMIO BIOS assignment is automatically enabled when selecting > 2048MB aperture. To use this feature, please disable CSM Support. Field Name DVMT Pre-Allocated Default Value...
  • Page 33 4.2.2 CPU Configuration Field Name Default Value Displays CPU Signature Comment This field is not selectable. There is no help text associated with it. Field Name Brand String Default Value Displays the CPU brand string Comment This field is not selectable. There is no help text associated with it. Field Name L1 Data Cache Default Value...
  • Page 34 Default Value VMX Supported or Not Comment This field is not selectable. There is no help text associated with it. Field Name SMX/TXT Default Value SMX/TXT Supported or Not Comment This field is not selectable. There is no help text associated with it. Field Name Intel (VMX) Virtualization Technology Default Value...
  • Page 35 4.2.3 Trusted Computing Field Name Firmware Version Default Value TPM module version. Comment This field is not selectable. There is no help text associated with it. Field Name Vendor Default Value TPM module vendor name. Comment This field is not selectable. There is no help text associated with it. Field Name Security Device Support Default Value...
  • Page 36 4.2.4 SMART Settings Field Name SMART Self Test Default Value [Disabled] Possible Value Enabled Disabled Help Run SMART Self Test on all HDDs during POST.
  • Page 37 4.2.5 Super IO Configuration Field Name Serial Port 1 Configuration Help Set Parameters of Serial Port 1 (COMA) Comment Press Enter when selected to go into the associated Sub-Menu. Field Name Serial Port 2 Configuration Help Set Parameters of Serial Port 2 (COMB) Comment Press Enter when selected to go into the associated Sub-Menu.
  • Page 38 4.2.5.1 Serial Port 1 Configuration Field Name Serial Port Default Value [Enabled] Possible Value Disabled Enabled Help Enable or Disable Serial Port(COM) Field Name Device Settings Default Value Device Super IO COM1 Address and IRQ. Comment This field is not selectable. There is no help text associated with it. Field Name Change Settings Default Value...
  • Page 39 1T/1R RS485 TX ENABLE Low Active 1T/1R RS422 with termination resistor 1T/1R RS485 with termination resistor TX ENABLE Low Active Help Configure serial port as RS232/RS422/RS485. 4.2.5.2 Serial Port 2 Configuration Field Name Serial Port Default Value [Enabled] Possible Value Disabled Enabled Help...
  • Page 40 4.2.5.3 Serial Port 3 Configuration Field Name Serial Port Default Value [Enabled] Possible Value Disabled Enabled Help Enable or Disable Serial Port(COM) Field Name Device Settings Default Value Device Super IO COM3 Address and IRQ. Comment This field is not selectable. There is no help text associated with it. Field Name Change Settings Default Value...
  • Page 41 4.2.5.4 Serial Port 4 Configuration Field Name Serial Port Default Value [Enabled] Possible Value Disabled Enabled Help Enable or Disable Serial Port(COM) Field Name Device Settings Default Value Device Super IO COM4 Address and IRQ. Comment This field is not selectable. There is no help text associated with it. Field Name Change Settings Default Value...
  • Page 42 4.2.6 Hardware Monitor Type Range CPU Temperature -20 ~ (By Processor Tjmax) °C CPU VR Temperature -20 ~ 120 °C DIMM Temperature -20 ~ 120 °C CPU Fan Speed There are many kinds of the fan could be installed into the system, so we could only set 0 RPM for the failed fan speed, and there is also no high RPM limitation.
  • Page 43 4.2.7 RTC Wake Settings Field Name Wake system from S5 Default Value [Disabled] Possible Value Disabled Fixed Time Help Enable or disable System wake on alarm event. Select FixedTime, system will wake on the hr::min::sec specified. Field Name Wake up hour(Show when Wake system from S5 set to Fixed Time) Default Value Possible Value 0-23...
  • Page 44 4.2.8 Network Stack Configuration Field Name Network Stack Default Value [Disabled] Possible Value Disabled Enabled Help Enable/Disable UEFI Network Stack. Field Name IPv4 PXE Support (Available when Network Stack Enabled) Default Value [Disabled] Possible Value Disabled Enabled Help Enable/Disable IPv4 PXE boot support. If disabled, IPv4 PXE boot support will not be available.
  • Page 45 4.2.9 NVMe Configuration Field Name (Device) Comment Press Enter when selected to go into the associated Sub-Menu.
  • Page 46 4.3 Security Page Field Name Administrator Password Help Set Administrator Password Field Name User Password Help Set User Password. Field Name HDD Security drive Help HDD Security Configuration for selected drive Comment Press Enter when selected to go into the associated Sub-Menu. Field Name Secure Boot Help...
  • Page 47 4.3.1 HDD Security Field Name Set User Password Help Set HDD User Password. *** Advisable to Power Cycle System after Setting Hard Disk Passwords ***.Discard or Save changes option in setup does not have any impact on HDD when password is set or removed. If the 'Set HDD User Password' option is hidden, do power cycle to enable the option again...
  • Page 48 4.3.2 Secure Boot Field Name Secure Boot Default Value [Enabled] Possible Value Enabled Disabled Help Secure Boot feature is Active if Secure Boot is Enabled,Platform Key(PK) is enrolled and the System is in User mode.The mode change requires platform reset Field Name Secure Boot Mode Default Value...
  • Page 49 Comment Enables expert users to modify Secure Boot Policy variables without variable authentication...
  • Page 50 4.3.2.1 Key Management Field Name Factory Key Provision Default Value [Disabled] Possible Value Enabled Disabled Help Install factory default Secure Boot keys after the platform reset and while the System is in Setup mode Field Name Restore Factory Keys Help Force System to User Mode.
  • Page 51 Help Enroll Factory Defaults or load certificates from a file: 1.Public Key Certificate: a)EFI_SIGNATURE_LIST b)EFI_CERT_X509 (DER) c)EFI_CERT_RSA2048 (bin) d)EFI_CERT_SHAXXX 2.Authenticated UEFI Variable 3.EFI PE/COFF Image(SHA256) Key Source: Factory,Modified,Mixed comment Press Enter when selected to go into the associated Sub-Menu “Key Management”. Field Name Key Exchange Keys (KEK) Default Value...
  • Page 52 1.Public Key Certificate: a)EFI_SIGNATURE_LIST b)EFI_CERT_X509 (DER) c)EFI_CERT_RSA2048 (bin) d)EFI_CERT_SHAXXX 2.Authenticated UEFI Variable 3.EFI PE/COFF Image(SHA256) Key Source: Factory,Modified,Mixed comment Press Enter when selected to go into the associated Sub-Menu. Field Name OsRecovery Signatures (dbr) Default Value Size:0, Keys:0, Key Source: No Keys Help Enroll Factory Defaults or load certificates from a file: 1.Public Key Certificate:...
  • Page 53 4.3.3 BIOS Update Field Name Path for ROM Image Help Enter the path to the BIOS update option...
  • Page 54 4.4 Boot Page Field Name Setup Prompt Timeout Default Value Possible Value 1~65535 Help Number of seconds to wait for setup activation key. 65535(0xFFFF) means indefinite waiting. Field Name Bootup NumLock State Default Value [On] Possible Value Help Select the keyboard NumLock state Field Name Boot Option #1 Default Value...
  • Page 55 Network, Disabled Help Sets the system boot order Field Name Boot Option #3 Default Value [USB CD/DVD] Possible Value USB Floppy, CD/DVD, USB CD/DVD, Hard Disk , USB Key, USB Hard Disk , Network, Disabled Help Sets the system boot order Field Name Boot Option #4 Default Value...
  • Page 56 Field Name (UEFI) USB Key Drive BBS Priorities Help Specifies the Boot Device Priority sequence from available UEFI USB Key Drives. Comment Press Enter when selected to go into the associated Sub-Menu. Field Name (UEFI) USB Hard Disk Drive BBS Priorities Help Specifies the Boot Device Priority sequence from available UEFI USB Hard Disk Drives.
  • Page 57 4.4.1 (List Boot Device Type) Drive BBS Priorities Field Name Boot Option #1 Default Value Possible Value Boot Device Name 1 of this type, Disable Help Sets the system boot order...
  • Page 58 4.5 Save & Exit Page Field Name Save Changes and Reset Help Reset the system after saving the changes. Field Name Discard Changes and Reset Help Reset system setup without saving any changes. Field Name Restore Defaults Help Restore/Load Default values for all the setup options.
  • Page 59 4.6 Evnet logs Field Name Change Smbios Event Log Settings Help Press <Enter> to change the Smbios Event Log configuration. Comment Press Enter when selected to go into the associated Sub-Menu. Field Name View Smbios Event Log Help Press <Enter> to view the Smbios Event Log records. Comment Press Enter when selected to go into the associated Sub-Menu.
  • Page 60 4.6.1 Change Smbios Event Log Settings Field Name Smbios Event Log Default Value [Enabled] Possible Value Enabled Disabled Help Change this to enable or disable all feature of Smbios Event Logging during boot. Field Name Erase Event Log Default Value [No] Possible Value No / Yes, Next reset / Yes, Every reset...
  • Page 61 4.6.2 View Smbios Event log Field Name DATE / TIME / ERROR CODE / SEVERITY / COUNT Default Value MM/DD/YY HH:MM:SS Smbios 0x16 N/A N/A Possible Value By Events. Help By Events.
