Page 4
READ AND SAVE THESE INSTRUCTIONS WARNING TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT USE THIS FAN WITH ANY SOLID-STATE CONTROL DEVICE. WARNING TO REDUCE THE RISK OF FIRE ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: a.
Page 5
WARNING TO REDUCE THE RISK OF FIRE, USE ONLY METAL DUCTWORK. CAUTION To reduce risk of fire and to properly exhaust air outside - Do not vent exhaust air into spaces within walls, ceilings, attics, crawl spaces or garages. OPERATION Always leave safety grilles and filters in place. Without these components, operating blowers could catch onto hair, fingers and loose clothing. The manufacturer declines all responsibility in the event of failure to observe the instructions given here for installation, maintenance and suitable use of the product.
Page 6
3/16 x 3/8” (4) PARTS NOT SUPPLIED - Ducting, conduit and all installation tools - Cable connector (if required by local codes) - Duct Cover Accessory - Backsplash Accessory - Wood Board to hang hood ( W x D x H) RH70230BS - 27” x 1/2” x 4” Rh70236BS - 33” x 1/2” x 4” RH70248BS - 45” x 1/2” x 4”...
Page 7
Equivalent number Equivalent number Duct pieces Duct pieces length x used T otal T otal length x used 3- 1/ 4” x 10” 1 Ft. 3- 1/ 4” x 10” 5 Ft. Rect., Rect. to straight 6” round transition 6”, 7”, 8”, 10” 1 Ft.
Page 8
Minimum mount height between range top to hood bottom should be no less than 24”. Maximum mount height should be no higher than *12" 36”. It is important to install the hood at the proper mounting height. Hoods mounted too low could result in heat damage and fire hazard; while hoods 18"...
Page 9
WARNING FIRE HAZARD NEVER exhaust air or terminate duct work into spaces between walls, crawl spaces, ceiling, attics or garages. All exhaust must be ducted to the outside. Use metal ductwork only. Fasten all connections with sheet metal screws and tape all joints with certified Silver Tape or Duct Tape. Some Ducting Options Roof Pitch w/ Flashing & Cap Side wall cap w/ gravity damper Soffit or crawl space Rear Ducting...
Page 11
4. Level and mark top of wood board line B, 16 7/8” from line A. 5. Mark center line of wood board. Center and align top of board with line B. Secure wood board to studs using (4) M4 wood screws. Wood Board Dimensions: (W x D x H) RH70230BS - 27” x 1/2” x 4” RH70236BS - 33” x 1/2” x 4” RH70248BS - 45” x 1/2” x 4” 24” 6. Prepare duct pipe and duct cut outs in upper cabinet or ceiling if vertical ducting or prepare cut outs and ducting in wall If horizontally ducting hood. Refer to hood specifications on page 8 for dimensions.
Page 12
1. Disconnect both blower plugs. 2. Remove (4) screws attaching dual blower plate to top of interior body of hood. Remove dual blower from hood body. 3. Remove knock out plate A from back of hood 4. Position dual blower at back of hood. Tuck dual body using flat head screw driver and rubber blower plate under blower clips and secure mallet. blower to back of hood by (4) screws removed from step 2. 5. Attach 10” round collar to back of hood body by 6. Attach top cover plate to top of hood body by (4) (4) M4 x 8 screws.
Page 13
Power / Delay Off Lights On/Off Speed Indicators Power / Delay Off Button Button will turn power on and off for entire hood (fan and lights.) - Hood will remember the last speed and light level it was last turned off at. (Example: Press button to turn off hood when on fan speed 3 and high lights.
Page 14
SURFACE MAINTENANCE: Do not use corrosive detergents, abrasive detergents or oven cleaners. Do not use any product containing chlorine bleach or any product containing chloride. Do not use steel wool or abrasive scrubbing pads which will scratch and damage surface. Cleaning Stainless Steel Clean periodically with warm soapy water and clean cotton cloth or micro fiber cloth. Always rub in the direction of the stainless steel grain.
Page 15
CFM SELECTOR Some local codes limit the maximum amount of CFM a range hood can move. CFM Selector allows you to control the maximum blower CFM without the need for expensive make up air kits. CFM Selector enables the installer to easily set the maximum blower speed to one of two most commonly specified CFM levels; 590 or 390 CFM. The usage of CFM Selector may not be necessary for your installation. Please check your local codes for CFM restrictions. By default the maximum blower CFM is set to 1200 CAUTION: Hood must be disconnected from main power prior to performing the conversion instructions listed below.
Page 16
TROUBLESHOOTING PROCEDURES FOR RH702 Issue Cause What to do After installation, 1. The power source is not turned ON. 1. Make sure the circuit breaker and the unit’s the unit doesn’t power is ON. work. 2. The power line and the cable locking connector 2. Check the power connection with the unit is is not connecting properly. connected properly. 3. The wires on rotary switch are loose. 3. Make sure the wires on the switch are connected properly.
Page 18
DESCRIPTION PART # Replacement Parts Light Bulb MR16 (GU10) 50W (each) Z0B-0020 Optional Accessories Back Splash (30”) AK0710 Back Splash (36”) AK0716 Back Splash (48”) AK0718 12” Duct Cover (30”) AK0720 12” Duct Cover (36”) AK0726 12” Duct Cover (48”) AK0728 To order parts, please call us at 1.888.750.1698...
Page 19
STAPLE YOUR RECEIPT HERE Proof of the original purchase Limited Warranty date is needed to obtain service under warranty TO OBTAIN SERVICE UNDER WARRANTY OR FOR ANY SERVICE RELATED QUESTIONS, please call: 1-888-750-1698 Venting Services (referred to herein as “we” or “us”) warrants to the original consumer purchaser (referred to herein as “you”...
