- Page 1 Wired Digital Thermostat Model: HTRP230 INSTALLER MANUAL...
- Page 2 Important info Your benefit HRTP230 Thermostat Manual Contents: Box Contents Introduction Wired Digital Thermostat Model: HTRP230 Product Compliance and Safety Information Installation User Interface INSTALLER MANUAL Status/LED indication Installers notes Fixing Screws 1 x Installer Manual Warranty HTRP230 Instruction Manual...
- Page 3 Product Compliance and Safety Info Product Compliance SALUS Controls hereby declares that the product complies with the essential requirements of the following EC Directives: 2014/30/EU, 2014/35/EU and 2011/65/EU. The full text of the EU Declaration of Conformity is available at the following internet address: www.saluslegal.com.
- Page 4 Product Description Thank you for purchasing the Salus HTRP230 Thermostat. This thermostat is a device that lets you customize the heating and cooling of your home as needed. The HTRP230 device from Salus Controls is a stylish and accurate digital room thermostat that is fitted with a large easy to read LCD screen and one touch buttons.
- Page 5 1. Mounting the Thermostat Gently remove front housing. Without floor sensor With floor sensor HTRP230 Instruction Manual...
- Page 6 2. Terminal Connection Note: You can wire the thermostat directly to the KL08NSB wiring centre or to an actuator (purchased separatly). OPTIONAL EXTERNAL PROBE ACTU OR OUTPUT E.G. TO MULTIPLE HEAT DEVICES PUMP OUTPUT 230VAC 50Hz HTRP230 Instruction Manual...
- Page 7 Indicates AUTO ON or AUTO OFF Indicates that the Party Mode is active Indicates that the Holiday Mode is ON. Frost Protection Indicator: Frost protection is active, not available in cooling mode. Heat Mode indicator: Indicates heating is running HTRP230 Instruction Manual...
- Page 8 Temperature indicator • Display the room temperature • Display the set temp Temporary override indicator: The hand will appear until the next programs starting time. Programs number indicator. Indicates the time. Indicates the the day of the week HTRP230 Instruction Manual...
- Page 9 Long press to return home without saving. OK key. Short press to confirm selection. Long press to save and return home. Long press to enter Temperature offset Heat/Cool. Decrease or increase Setpoint Temperature. Note: LCD backlight is activated by pressing any key. HTRP230 Instruction Manual...
- Page 10 When you first power up your device you 6. Setting Date and Time will have to set up the date and time. Press Press confirm. choose 12/24 hr then press to confirm. HTRP230 Instruction Manual...
- Page 11 Set the hour Set the minutes by using by using Press confirm. Set the date using the . Press to confirm. Note: You can access the date and hour by long pressing . After that press to confirm. HTRP230 Instruction Manual...
- Page 12 Press to confirm. setting the minutes. Note: If you want to select another Program Profile (from the available 5), please enter in Installer Mode, choose option d17 and after that select the desired program. HTRP230 Instruction Manual...
- Page 13 6:00 Sunny Sunny 7:00 Sunny Sunny 9:00 Moon Moon 23:00 Moon Moon 16:00 Sunny Sunny --:-- --:-- --:-- 23:00 Moon Moon --:-- --:-- --:-- --:-- --:-- --:-- --:-- --:-- --:-- --:-- --:-- --:-- --:-- --:-- --:-- HTRP230 Instruction Manual...
- Page 14 6:00 Sunny Sunny 7:00 Sunny Sunny 22:30 Moon Moon 23:00 Moon Moon --:-- --:-- --:-- --:-- --:-- --:-- --:-- --:-- --:-- --:-- --:-- --:-- --:-- --:-- --:-- --:-- --:-- --:-- --:-- --:-- --:-- --:-- --:-- --:-- HTRP230 Instruction Manual...
- Page 15 5:00 Sunny Sunny 7:30 Sunny Sunny 8:00 Moon Moon 22:30 Moon Moon 14:00 Sunny Sunny --:-- --:-- --:-- 22:00 Moon Moon --:-- --:-- --:-- --:-- --:-- --:-- --:-- --:-- --:-- --:-- --:-- --:-- --:-- --:-- --:-- HTRP230 Instruction Manual...
- Page 16 6:00 Sunny Sunny 7:30 Sunny Sunny 9:00 Moon Moon 23:00 Moon Moon 15:00 Sunny Sunny --:-- --:-- --:-- 22:30 Moon Moon --:-- --:-- --:-- --:-- --:-- --:-- --:-- --:-- --:-- --:-- --:-- --:-- --:-- --:-- --:-- HTRP230 Instruction Manual...
- Page 17 6:00 Sunny Sunny 7:30 Sunny Sunny 10:00 Moon Moon 23:30 Moon Moon 16:00 Sunny Sunny --:-- --:-- --:-- 23:00 Moon Moon --:-- --:-- --:-- --:-- --:-- --:-- --:-- --:-- --:-- --:-- --:-- --:-- --:-- --:-- --:-- HTRP230 Instruction Manual...
- Page 18 8. How to reset the thermostat Press the indicated keys Select P47 if you want to Press to confirm. together for 3 seconds. reset to factory settings. Press to confirm. HTRP230 Instruction Manual...
- Page 19 Installer Mode. o confirm. Select your option by using Press to confirm. Note: This function allows you to customise your thermostat as you desire. In order to do this please consult the tables on the next pages. HTRP230 Instruction Manual...
- Page 20 F: if d03 = 1, IN disabled and OUT controls Tr Floor Protection ON-OFF: 0.5ºC (± 0.25ºC) Cooling Control ON-OFF: 1.0ºC (± 0.5ºC) Valve Protection 0 = VP disabled 1 = Enable Frost Setpoint 5ºC - 17ºC 5.0ºC HTRP230 Instruction Manual...
- Page 21 Turn on relay output when oor sensing temp < 10ºC 6ºC - 40ºC (heating low limit-LL) protecting limit, step is 0.5ºC Floor sensor protection limit Turn o relay output when oor sensing temp < 6ºC - 45ºC 6ºC (cooling) protecting limit, step is 0.5ºC HTRP230 Instruction Manual...
- Page 22 LCD screen. Ice flake will also be turned off. Note: d19 will be available only if d18 is set on 1 (Heat/Cool Mode selection Connected). HTRP230 Instruction Manual...
- Page 23 If you want to exit Party Mode, press ime allowed on to move the (box) to a different program. he Party Mode Once Party Mode ends the countdown s 9 h 50 min and automatically resets to 0. can be set from 0-10 min. HTRP230 Instruction Manual...
- Page 24 Note: Vacation Modes ends when it reaches day 0. After that the device goes back to Auto Mode. 14. Frost Mode Press if you want to Press change the Frost to select Frost Mode temp. Press Mode. Press to confirm. to confirm. HTRP230 Instruction Manual...
- Page 25 Long press in order Press to enter Press in order to to enter Settings Mode. Setting Mode. set the Temperature Offset. The Temperature Offset can be set at any value between -3ºC and +3ºC. Press to confirm. HTRP230 Instruction Manual...
- Page 26 125 g net / 170 g gross Puls-wide-modulation (PWM) Yes Clock, Timer Yes, programmable Profile Modes 3 ( Sun, Moon, Automatic) Heating and Cooling Yes, automatically Change Over on the Wiring Centre Parameter adjustment Yes, in Installer Mode Dimensions 85mm*85mm*25mm HTRP230 Instruction Manual...
- Page 27 five years from the date of installation. SALUS Controls sole liability for breach of this warranty will be (at its option) to repair or replace the defective product.
- Page 28 SALUS Controls is a member of the Computime Group Maintaining a policy of continuous product development SALUS Controls plc reserve the right to change specification, design and materials of products listed in this brochure without prior notice. For PDF Installation guide please go to www.salus-manuals.com...
