- Page 2 REV G 08/31/2024 CONTENTS 01/ Safety Information ......................2 02/ Technical Specifications....................3 03/ Overview ..........................4 04/ Operation ..........................5 4.1 Self-Upgrade ......................... 5 4.2 Upgrade Fixture’s Firmware (Normal Upgrade)..........5 4.3 Upgrade Fixture’s Firmware (Locked Upgrade) ..........8 4.4 DMX Test ........................10 - 1 -...
- Page 3 REV G 08/31/2024 01/ Safety Information Please read the instruction carefully which includes important information about the installation, usage and maintenance. WARNING Please keep this User Manual for future consultation. If you sell the unit to another user, be sure that they also receive this instruction manual. Important: Damages caused by the disregard of this user manual are not subject to warranty.
- Page 4 REV G 08/31/2024 02/ Technical Specifications External Power Supply 100-240Vac; 50/60Hz Power Voltage DC 9-12V Max. Power 12.2W Consumption LCD display 3-pin and 5-pin DMX output Features Battery operation SD card slot Dimensions 79x159x51mm 3.1"x6.3"x2" Weight 0.6 kg 1.3 lbs - 3 -...
- Page 5 REV G 08/31/2024 03/ Overview 1. Indicators Power (Full) Power (Low) 2. Display To show the various menus and the selected function MENU To enter into move backward or leave the menu UP To go backward to move up in the menu 3.
- Page 6 4.2 Upgrade Fixture’s Firmware (Normal Upgrade) 1. Download the fixture’s software update files from the ACME website and store them in the SD card supplied with the Uploader II. Insert the SD card into the SD card slot of the Uploader II.
- Page 7 6. A window pops up in the display. Set a desired speed (1-100: slow-fast) of upgrade and press ENTER. 7. The Uploader II will display the upgrade process from 0-100%. Once the first file (V00) upgrade is complete, the upgrade process will display 100% OK!. While still in the Firmware Upgrade screen, pressing MENU once returns you to the Firmware Files screen.
- Page 8 REV G 08/31/2024 9. Again, set the desired speed of upgrade and press ENTER. 10. Again, the upgrade process displays from 0-100%. Once the second file (Vxx) upgrade is complete, the upgrade process will display 100% OK!. Press MENU to exit. - 7 -...
- Page 9 This method is usually used after several failed upgrades to the fixture. 1. Download the fixture’s software update files from the ACME website and store them in the SD card supplied with the Uploader II. Insert the SD card into the SD card slot of the Uploader II.
- Page 10 7. Power up the fixture and press ENTER of the Uploader II. 8. The Uploader II will display the upgrade process from 0-100%. Once the first file (V00) upgrade is complete, the upgrade process will display 100% OK!. While still in the Firmware Upgrade screen, pressing MENU once returns you to the Firmware Files screen.
- Page 11 1. Connect the Uploader II to fixture, using 3-pin or 5-pin DMX cable. 2. With the fixture connected, power up the fixture and switch on the Uploader II. 3. Press the MENU button and the display will show the following menu. Use (DOWN)/(UP) button to select DMX Test and press ENTER.
- Page 12 REV G 08/31/2024 4. The Uploader II will display the Manual Test screen. Use (DOWN)/(UP) button to select a channel for which the manual test is to be performed, press ENTER. Select a value (0-255), confirm your selection with ENTER. (Select Clear, use (DOWN)/(UP) button to select Yes and press ENTER, all channel values will be cleared.)
