Summary of Contents for AFRISO CosiTherm FT

Page 1 Operating instruc- tions Room temperature sensor (wireless) Product family CosiTherm® Type: FT Type: FTF Copyright 2023 AFRISO-EURO-INDEX GmbH. All rights reserved. Lindenstraße 20 74363 Güglingen Telephone +49 7135 102-0 Service +49 7135 102-211 Telefax +49 7135 102-147 info@afriso.com Version: 11.2023.0...
Page 2 About these operating instructions About these operating instructions These operating instructions describe the room temperature sensor "FT / FTF" (also referred to as "product" in these operating instructions). These operating instructions are part of the product. • You may only use the product if you have fully read and understood these operating instructions.
Page 3 Information on safety Information on safety Safety messages and hazard categories These operating instructions contain safety messages to alert you to poten- tial hazards and risks. In addition to the instructions provided in these oper- ating instructions, you must comply with all directives, standards and safety regulations applicable at the installation site of the product.
Page 4 Information on safety Intended use The room temperature sensor is a part of CosiTherm®. This product may only be used to control the room temperature (heat/cool) of individual rooms with underfloor heating system. Any use other than the application explicitly permitted in these operating instructions is not permitted and causes hazards.
Page 5 Information on safety Qualification of personnel Only appropriately trained persons who are familiar with and understand the contents of these operating instructions and all other pertinent product doc- umentation are authorized to work on and with this product. These persons must have sufficient technical training, knowledge and expe- rience and be able to foresee and detect potential hazards that may be caused by using the product.
Page 6 Transport and storage Transport and storage The product may be damaged as a result of improper transport or storage. NOTICE INCORRECT HANDLING • Verify compliance with the specified ambient conditions during transport or storage of the product. • Use the original packaging when transporting the product. •...
Page 7 Product description Product description The product is a part of CosiTherm® or of the AFRISOhome gateway. The following products are available for different applications: • Room temperature sensor "FT" (temperature) • Room temperature sensor "FTF" (temperature and humidity) Overview A. Solar cell B.
Page 8 Product description Application examples Fig. 1: Base module with controller module, timer module, room temperature sensors, external antenna and actuators FT / FTF...
Page 9 Product description Fig. 2: Base module with controller module F6A, timer module, room temperature sen- sors, gateway, external antenna and actuators FT / FTF...
Page 10 Product description Function CosiTherm® is a single room temperature controller used to control the tem- perature in rooms with underfloor heating system (heat/cool). The product is equipped with a solar cell for power supply. If the product is used in dark environments, use an optional battery (refer to "Technical spec- ifications").
Page 11 Product description Technical specifications Parameter Value General specifications Dimensions (W x H x D) 78 x 82.5 x 12.5 mm Weight 43 g Housing material Colour White, similar to RAL 9003 Temperature adjustment range/ 8 ... 30 °C temperature measuring range Temperature measurement 0 ...
Page 12 Product description Parameter Value EnOcean® wireless Frequency 868.3 MHZ Transmission power Maximum 10 mW Range See chapter "Information on EnOcean® wireless" EnOcean® Equipment Profile (EEP) A5-10-03 A5-10-12 FT / FTF...
Page 13 Mounting Mounting Preparing mounting If you want to install several products, create an installation plan with the indi- vidual installation sites. Label the individual products according to the instal- lation plan with a number or the designation of the installation. ...
Page 14 Mounting Cold walls and draughts affect temperature measure- ment. 1. Mount the product to an indoor wall and at an ade- quate distance from doors and windows. Sticking the product to a wall: 1. Stick the product to the wall using the adhesive dots.
Page 15 Mounting Screwing the product to a wall 1. Turn the cam screw at the bottom of the product approximately 90° using a screwdriver. 2. Lift the rotary knob and remove it. 3. Remove the upper part of the housing. 4. Screw the bottom part of the housing to the even wall.
Page 16 Mounting 6. Turn the cam screw at the product back to the initial position using a screw- driver. FT / FTF...
Page 17 Mounting 7. Fit the upper part of the housing and the rotary knob to the bottom part of the housing. - Verify correct position with reference to the axis of rotation when insert- ing the rotary knob. Inserting a battery (optional) In the case of daylight with an illuminance of less than 200 lux, use an optional battery (see "Technical specifications", not included).
Page 18 Commissioning Commissioning Connecting the product to a controller module The procedure (with EnOcean wireless) is described in the operating instruc- tions of the "Controller module (wireless)".  Verify that the EnOcean wireless signal of the product reaches the room temperature sensor to be connected and that the room temperature sen- sor is in the vicinity of the controller module.
Page 19 Operation Operation Adjusting the room temperature 1. Adjust the desired tem- perature at the product. - Without temperature reduction: CosiTherm® controls the room tem- perature to the adjusted value. - With temperature reduc- tion: CosiTherm® con- trols the room tempera- ture to a value 4 K below the adjusted value.
Page 20 Operation 2. Lift the rotary knob and remove it. 7.2.1 Setting the minimum temperature 1. Lift the blue restrictor at the flag (A). 2. Turn the blue restrictor with the restrictor adjust- ment edge (B) to the desired value for the mini- mum temperature and refit it.
Page 21 Operation 7.2.2 Setting the maximum temperature 1. Lift the red restrictor at the flag (A). 2. Turn the red restrictor with the restrictor adjustment edge (B) to the desired value for the maximum temperature and refit it. 3. Turn the cam screw at the product back to the initial position so that you can refit the rotary knob.
Page 22 3. Dispose of the product and of the optional battery sepa- rately. Returning the device Get in touch with us before returning your product (service@afriso.de). Warranty See our terms and conditions at www.afriso.com or your purchase contract for information on warranty. FT / FTF...
Page 23 Spare parts and accessories Spare parts and accessories NOTICE UNSUITABLE PARTS • Only use genuine spare parts and accessories provided by the manufac- turer. Failure to follow these instructions can result in equipment damage. Product Product designation Part no. Figure Room temperature sensor 78111 "FT"...
Page 24 • AN001 • AN102 • AN103 • AN201 14.3 Features of the EnOcean® technology Visit www.afrisohome.de for documents on EnOcean® technologies. A variety of videos on AFRISO products can also be found on the AFRISO YouTube channel. FT / FTF...
Page 25 Appendix Appendix 15.1 EU Declaration of Conformity FT / FTF...
