Model W1857/W1858
***IMPORTANT UPDATE***
Applies to Models Mfd. Since 06/24
and Owner's Manual Revised 09/21
Phone #: (360) 647-0802 • Tech Support: techsupport@shopfoxtools.com • Web: www.shopfoxtools.com
The following changes were recently made since the owner's manual was printed:
Inventory has changed.
Parts have changed.
Assembly steps have changed.
Aside from the information contained in this update, all other content in the owner's manual is
applicable and MUST be read and understood for your own safety.
IMPORTANT: Keep this update with the owner's manual for future reference. If you have any
further questions, contact our Technical Support.
Revised Inventory
Additional Loose Items (Figure 1)
T.
Open-End Wrench 14/17mm .................. 1
U. Hex Nuts M8-1.25 ............................... 2
V.
Lock Nuts
"-16 ................................ 4
3
8
W. Wheel Axles
"-16 x 1
3
8
X. Wheels ........................................... 4
Y.
Mobile Base Lock Knobs ....................... 2
Z. Adjustable Feet M8-1.25 ...................... 2
T
W
Y
Figure 1. Additional loose items inventory.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT
READ THIS FIRST
Qty
", 2
"L ........... 4
3
1
16
2
U
V
X
Z
COPYRIGHT © MAY, 2024 BY GRIZZLY INDUSTRIAL, INC.
THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
Revised Parts
86-4
86-3V2
REF
PART #
DESCRIPTION
86-3V2
X1857086-3V2
MOTOR PULLEY V2.02.22
142
X1857142
WRENCH 14 X 17 OPEN-ENDS
142
86-4
#23222KS
Printed in Taiwan
