M15 HD AV Surround Sound Preamplifier
M A S T E R P E R F O R M A N C E I N H I G H D E F I N I T I O N
When the M15 was introduced in 2005 it redefi ned the performance and value expectations for consumers worldwide. With a string of rave
When the M15 was introduced in 2005 it redefi ned the performance and value expectations for consumers worldwide. With a string of rave
reviews and awards including the prestigious EISA Award for 'Best Home Cinema', the M15 has become a classic in its own right. There is now
reviews and awards including the prestigious EISA Award for 'Best Home Cinema', the M15 has become a classic in its own right. There is now
a new generation of video source and display products that support high resolution video and high defi nition audio. The new M15 HD has been
re-engineered to take full advantage of these new High Defi nition formats. We have also added some interesting new features to enhance your
enjoyment and protect your investment.
> F E A T U R E S
• 4 Digital HD AV Inputs with HDMI
Repeating
• 4 Analogue AV Inputs with Composite
and S-Video
• 3 HD Component Video Inputs
• 4 Coax and 4 Optical Digital inputs
• 3 Analogue Stereo Inputs
• 7.1 Direct Analogue Input
• Dolby TrueHD, DTS HD Master Audio,
Linear PCM will run at 192kHz; Dolby
Digital Plus, DTS HD High Resolution
Audio, DTS 96/24
• DTS Neo:6 [Cinema/Music], Dolby
ProLogic IIx [Movies/Music], EARS,
Enhanced Stereo
• Audyssey MultEQ Pro
• Video upconversion; Composite and
S-Video inputs available on Component
Video output and HDMI output
• Sigma VXP Image Processing with HD
scaling to 1080p
• MP Data Port for connection to NAD
Dock for iPod
• Lip sync compensation – (option to
200mS)
• Flexible Bass Management including
individual crossover frequencies for
Front, Centre, and Surround speakers
• Tone controls
• RS-232 interface for advanced custom
installations
• 12V Triggers for advanced control
options, 1 In and 3 Out
• 3.5mm IR Control jacks, 1 In and 4 Out
• Zone 2 Independent AV output
• Zone 3 and Zone 4 Independent
Audio output
• Dual differential 24-bit, 192 kHz DACs
• Dynamic
Headroom
Scaling
optimum resolution and S/N ratio for
all program and decoding combinations
• Switch Mode Power Supply for Digital
Audio and Video Stages
• Linear Power Supply with Custom C-Core
Transformer for Analogue Audio Stages
• Detachable AC cord
• 8 Device HTRM Illuminated Learning
Remote control with LCD display
• ZR 5 Second Zone Remote
> S I M P L E C O N V E N I E N C E ,
O P T I M U M F L E X I B I L I T Y
The surround preamp processor serves as the 'brains' of
your surround sound system. It takes the raw, unprocessed
digital audio signals, decodes them into multiple (5.1, 6.1,
or 7.1) analogue channels, and sends them on downstream
to your amplifi er and speakers. Compatibility is an important
issue, as there is a multitude of different audio and video
formats that must be catered to, with provision for several
different types of signal transmission. Whether it is digital
or analogue, the M15 HD has the fl exibility to accept all the
popular formats, including the latest, HDMI (High Defi nition
Digital Interface).
Once the signal arrives at the M15 HD's input, it must be
buffered, identifi ed, decoded, and any 'post processing'
for
routines (like Audyssey XT Pro) must be applied before
the signal is converted from digital to analogue and sent
to the outputs. There is also a requirement to 'redirect'
bass frequencies, depending on the capabilities of the
particular speakers used in your system. All this processing
is controlled in the M15 HD by the latest high speed DSPs,
loaded with NAD's proprietary software. These DSPs are
capable of 100s of millions of operations per second!
Fortunately, we use all this processing power to keep the
everyday operation of the M15 HD as simple and intuitive as
possible. Once the system and user preferences are set, the
M15 HD operates very much like our stereo preamplifi ers.
> continued
