- Page 1 INSTALLATION MANUAL DEEP FAT FRYER PRO900 APPLY TO : INSTALLATION MANUAL V03169 EN PRO800-900_G1-FR-28-HR_REV 0 FM ECE: - Date: 25/10/18 Revision N°: …by ECE Date 25/10/18...
- Page 3 CONTENT INTRODUCTION ..................................2 Foreword ....................................................2 About the symbols used in this manual ..........................................2 Notice regarding the recycling of the equipment ......................................2 PRODUCT IDENTIFICATION ............................... 3 Data plate....................................................3 ...
- Page 4 INTRODUCTION 1- Foreword Thank you for choosing Charvet. Our equipment is designed and manufactured in France by our teams, focussed on five main objectives: Robustness Performance Hygiene Ergonomics Safety If, despite our commitment and efforts, you encounter a problem with one of our products, our after-sales service is at your disposal After Sales Service and Information: sales@charvet.co.uk...
- Page 5 PRODUCT IDENTIFICATION 1- Data plate 2- Operator stamp (See section 3 to find the location of the data plate) 3- Notes INSTALLATION MANUAL EN PRO800-900_G1-FR-28-HR_REV 0 FM ECE: - Date: 25/10/18 Revision N°: …by ECE Date 25/10/18...
- Page 6 INSTALLATION 1- General The appliance must be installed in a room with adequate ventilation, equipped with an air extraction system, in compliance with the regulations and standards in force in the country of installation, and with the instructions contained in this manual. Special attention must be paid to the local fire prevention regulations of the organization concerned (see [Public Access Premises]).
- Page 7 INSTALLATION 6- Data plate The appliance has a data plate which information are useful for any communication during maintenance operation. The location of the data plate is shown on Fig 2. Open the door (Fig. 2 – Mark 1) and remove the protection cover (Fig 2 – Mark 2) Fig.
- Page 8 POWER CONNECTION The appliance must be earth wired. It is dangerous to connect the appliance unless it is earthed. Use a standardized cable (245 IEC 57 or 245 IEC 66) or other approved cable with the same characteristics. The cable used to connect the appliance to the mains supply hall have a minimum section of 1.5mm².
- Page 9 Required fresh air input (m /h/kW) V03169 PRO900 G1-FR-28-HR Table – Required fresh air input 2- Connection the appliance to the gas mains Connect the gas mains to the M1/2’’ coupling located on the rear of the appliance as shown on Fig. 6 Fig.
- Page 10 OPERATION ON BURNERS Before any intervention, make sure that the main shut off valve is closed. ATTENTION 1- Changing the injectors Open the door (Fig. 7. – Mark. 1) Remove the protection cover (Fig. 7. – Mark 2) Fig. 7. Loosen the fixing screw of the electrical box (Fig.
- Page 11 OPERATION ON BURNERS 2- Setting the air ring Fig. 9. Fig. 9. bis Main burner Cross-lighting burner Loosen locknut (Fig. 9. – Mark 1) Loosen the locknut (Fig. 9.bis – Mark. 1) Adjust the setting of the air ring (Fig. 9. – Mark 2) using the data in Adjust the setting of the air ring (Fig.
- Page 12 TROUBLESHOOTING 1- Reset the burner In case of burner failure, the red light switches on. In this case, please push the reset button (See Fig.1) to reset the burner. The operation may be renewed in case it hasn’t worked. If so, please wait around 5~6 seconds before pushing the reset button again. If the burner doesn’t start after a few tries, please shut off the equipment and call the installer for proper repair work.
- Page 13 ANNEX 1 – GAS DIAGRAM Parts list Mark Code Description Mark Code Description 08755A Gas coupling M ½’’ Min burner injector 00120A Torch burner 00161A Cross-lighting burner Venturi Cross-lighting burner injector 08959A Brass elbow MM ½’’ 506222 Gas valve 506229 Gas control box 500986 Brass elbow FF 15x21...
- Page 14 ANNEX 2 – WIRING DIAGRAM Parts list Rep n° Code Désignation Rep n° Code Désignation 02468A 4mm² Live Terminal block 08968A ON/OFF Switch 07690A 4mm² Earth Terminal block 09020A Temperature control board 07067A 4mm² Neutral terminal block 09021A Display board 172957 Temperature probe kit 09023A...
- Page 15 ANNEX 3 – EXPLODED VIEW Parts list Mark Code Description Mark Code Description F11155 ½ PRO900 GFR28HR Top frame 173130 Gas valve set for 28HR Evolution 173018 Stainless steel control panel ELE0018 Ignition push button 09021A Display board 173639 Red indicator light 230V...
- Page 16 ANNEX 4 – BASIC SPARE PARTS Spark plug / Flamme ON/OFF Switch Gas valve sensor 08968A 506222 171364 Ignition push button Gas control box Potentiometer ELE0018 506229 09023A Temperature control Filter mesh Burner fixation kit board 02273A 173127 09020A Drain tap Safety thermostat kit Display board 507059...
- Page 17 USER’S MANUAL DEEP FAT FRYER PRO900 APPLY TO : USER’S MANUAL V03169 EN PRO800-900_G1-FR-28-HR_REV 0 FM ECE: - Date: 25/10/18 Revision N°: …by ECE Date 25/10/18...
- Page 19 CONTENT CONTENT ....................................1 INTRODUCTION ..................................2 Foreword ....................................................2 À propos des symboles contenus dans ce manuel About the symbols used in this manual ......................... 2 Notice regarding the recycling of the equipment ......................................2 PRODUCT IDENTIFICATION ...............................
- Page 20 INTRODUCTION 1- Foreword Thank you for choosing Charvet. Our equipment is designed and manufactured in France by our teams, focussed on five main objectives: Robustness Performance Hygiene Ergonomics Safety If, despite our commitment and efforts, you encounter a problem with one of our products, our after-sales service is at your disposal After Sales Service and Information: sales@charvet.co.uk...
- Page 21 PRODUCT IDENTIFICATION 1- Data Plate 2- Installer Stamp (See section 3 to find the location of the data plate) 3- Notes USER’S MANUAL EN PRO800-900_G1-FR-28-HR_REV 0 FM ECE: - Date: 25/10/18 Revision N°: …by ECE Date 25/10/18...
- Page 22 1- Warning 1. Always keep oil between the marks Mini and Maxi as show on the figure beside. Heating oil while the level is under the Mini or above the Maxi. The lack or excess of oil can lead to the risk of burns of the user or the inflammation of the oil bath 2.
- Page 23 It is recommended to filter the cooking oil on a daily basis. Fully drain the tank in a collection bucket equipped with a filter mesh. Once the tank is refilled with the filtered oil, adjust the level using new oil. Charvet suggests to use its mobile filtration unit (Model No V01149). Please contact your installer for further information.
- Page 24 ANNEX 1 – BASIC SPARE PARTS Spark plug / Flamme ON/OFF Switch Gas valve sensor 08968A 506222 171364 Ignition push button Gas control box Potentiometer ELE0018 506229 09023A Temperature control Filter mesh Burner fixation kit board 02273A 173127 09020A Drain tap Safety thermostat kit Display board 507059...
