APRILIA SCARABEO 50 I.E - DEALER INSTRUCTION SHEET 2002 Instruction Sheet

DEALER INSTRUCTION SHEET
2
1
ASSEMBLING THE LOCK
Remove the nut (1) from the lock unit (2).
Fit the lock unit to the housing on the street car
cover and secure with the nut (1).
Make sure the nut (1) is tight.
aprilia part #8202313 - 01/02 - USA
SCARABEO 50 i.e.
1
Pag. 8
DEALER INSTRUCTION SHEET
INSTRUCTIONS FOR REMOVING
MOTORCYCLE FROM CRATE
SAFETY MESSAGES
The following warning messages are used on all the
instruction sheets to draw your attention to the situations
described below.
Safety warning symbol. When you see this
symbol on the motorcycle or instruction sheets,
beware of potential injury hazards.
Failure to observe the instructions following these
symbols may affect your safety, the safety of
others and that of the motor cycle!
Risk of serious injury or death.
Possible risk of slight injury or damage to motor
cycle.
DANGER
Risk of serious injury or death.
CAUTION
Possible risk of slight injury or damage to motor
cycle.
IMPORTANT
The word "IMPORTANT"is written before any important
information on the instruction sheet.
SCARABEO 50 i.e.
Scarabeo 50 i.e.
Scarabeo 50 i.e.
For the sake of safety, before starting the
vehicle, carry out a thorough preliminary check.
See the PRELIMINARY CHECK LIST IN THE
VEHICLE OPERATION AND MAINTENANCE
HANDBOOK.
Failure to carry out these checks may lead to
serious injury or damage to the vehicle.
Very little time is required, and the benefits in terms
of safety are enormous.
The components in this handbook are supplied
disassembled, and have to be fitted to the motor cycle.
These instruction sheets for dealers describe the
correct fitting procedures.
Read the instructions in the sheets to avoid
breakages or incorrect assembly.
Remove the rear street case from the packing case,
containing the mirrors, battery and components.
After removing the nailed-on supports and crosspieces
from the crate (used for transport purposes), push the
motor cycle off the bottom of the crate and position it
on the stand.
You can now proceed with the operations described
below.
Pag. 1
