TOOL KIT
To gain access to the tool kit, unlock and lift
the saddle as described on page 24 (UN-
LOCKING / LOCKING THE SADDLE).
The wrenches are fixed in the upper part of
the battery compartment cover.
The tool kit is formed by:
– No. 1 16 mm socket wrench (1);
– No. 1 17 mm wrench of the DIN type;
– No. 1 screwdriver (2) with one cross end
of the PH type, size 2, and opposite end
with hexagonal male wrench of 4 mm.
The wrenches are located in the comparment
found in the undersaddle plastic part.
The tool kit is formed by:
– No.1 16 mm socket wrench (1);
– No. 1 screwdriver (2) with one cross end
of the PH type, size 2, and opposite end
1
with hexagonal male wrench of 4 mm.
100
– No. 1 O ring for the two tools.
100
BAG HOOK
Do not hang excessively bulky bags or
parcels to the hook, as this may seriously
compromise the manoeuvrability of the
vehicle or the movement of your feet.
The bag hook (3) is positioned on the front
part of the inner shield.
Max. allowed weight: 1.5 kg.
