MAIN INDIPENDENT CONTROLS
CONTROLS ON THE LEFT SIDE OF THE
HANDLEBAR
NOTE
The electrical parts work only when the ignition switch is in
position "
".
NOTE
The lighting system works only when the engine is run-
ning.
1) DIMMER SWITCH (
-
When the light switch (
switch is in position "
", the low beam comes on; while if it is in
position "
", the high beam comes on.
2) DIRECTION INDICATOR SWITCH (
To indicate the turn to the left, move the switch to the left; to
indicate the turn to the right, move the switch to the right.
To turn off the direction indicator, press the switch.
3) HORN PUSH BUTTON (
The horn is activated when the "
) (not provided
)
•
-
) is in position "
", if the dimmer
)
)
" push button is pressed.
use and maintenance Scarabeo 50
1
2
3
- Scarabeo 100 4T
