Read the manual carefully and ensure you have fully understood
its contents before operating this device for the first time.
English
ES-A214005-1

Advertisement

loading
Need help?

Need help?

Do you have a question about the ERF3A80 and is the answer not in the manual?

Questions and answers

Summary of Contents for Hisense ERF3A80

  • Page 1 Read the manual carefully and ensure you have fully understood its contents before operating this device for the first time. English ES-A214005-1...
  • Page 2 Important Safety Instructions ▐ Important Notice Paragraphs beginning with the symbol indicate important instructions, tips or conditions for the following settings. For your own safety and the optimal performance of your TV, ensure to read the safety instructions before performing any installation. Compatibility with 3rd party products, software and services are not guaranteed.
  • Page 3 Important Safety Instructions The intended use and ambient conditions for this TV This TV is intended for the rendering of video and audio signals, on a table-top or wall- mounted, in a home or office environment. It must not be used in rooms with a high level of humidity or dust concentration.
  • Page 4 Important Safety Instructions „ Moving/Transportation „ Power plug and power cable Before moving this TV, disconnect all - Do not touch the power plug with wet cables and move in the vertical position hands. only. Grasp the device on the upper and - Do not place heavy objects on the lower edges of the frame.
  • Page 5 Important Safety Instructions „ Air ventilation and high Prevent small items from getting into the interior of the device through the ventilation temperatures slots. Such objects may cause short circuits, Install your TV only where there is proper which may cause fire. ventilation, and ensure that there is at least If something should get inside the unit, 10 cm free space on the sides and 20 cm...
  • Page 6 Important Safety Instructions If you have a cardiac pacemaker, keep a „ Supervision distance of at least 22 cm from the TV. Radio - Do not let children play unsupervised waves may interfere with the operation of a close to the TV. It could tip over, be pacemaker.
  • Page 7 Important Safety Instructions „ Cleaning and care swallowed. If swallowed by mistake, force the patient to vomit and visit the nearest hospital. CAUTION: Unplug the power cord prior to cleaning „ Modification the TV. Clean the TV, the screen, and the remote Do not attempt to modify this product control with a soft, moist, clean and in any way.
  • Page 8 Contents Figures and illustrations in this manual are provided for reference only and may differ from actual product appearance. Parts of the software function changes with the system upgrade. Contents Accessories List......................1 Installing the Stand or Wall mount bracket ..............2 TV Front..........................5 TV Rear ..........................6 Making Connections .......................8...
  • Page 9 Installing the Stand or Wall mount bracket CAUTION Be sure to disconnect the AC power cord before installing a stand or wall mount brackets. The display on your TV is fragile. Make sure the TV screen is not scratched or damaged by hard objects or from pressure.
  • Page 10 Installing the Stand or Wall mount bracket Screws: M4×12 Base Stand 65" Follow the illustrations and textual instructions below to complete the installation steps: 1. Carefully place your TV face-down on a soft, flat surface to prevent damage to the TV or scratching to the screen.
  • Page 11 Installing the Stand or Wall mount bracket Installing the wall mount bracket Before mounting the TV, remove the TV stand if you have already attached it, and make sure the wall mount bracket supports the weight of your TV. CAUTION When mounting the TV on a wall, follow instructions provided with the wall mount bracket.
  • Page 12 TV Front TV Front Remote sensor/Power indicator/Single button (Standby/Source) Item Description Receive remote signals from the remote control. Remote sensor Do not put anything near the sensor, as its function may be affected. Power indicator The light is red in standby mode. Press the single button when in standby mode, and the TV will be turned on.
  • Page 13 TV Rear TV Rear 43" 50"/55"/58" 43"/50"/55"/58" AC INPUT NOTES For 43", ANT2 Jack supports power supply for satellite antenna (13/18V, 420mA max.) For 50"/55"/58", ANT2 Jack supports power supply for satellite antenna (13/18V, 0.5A max.) Check the jacks for position and type before making any connections.
  • Page 14 TV Rear TV Rear 65" AC INPUT NOTES ANT2 Jack supports power supply for satellite antenna (13/18V, 0.5A max.) Check the jacks for position and type before making any connections. Loose connections can result in image or color problems. Make sure that all connections are tight and secure. Not all A/V devices have the ability to connect to a TV, please refer to the user’s manual of your A/V device for compatibility and connections procedure.
  • Page 15 Making Connections Wired setup LAN ( Connect your TV to your network by connecting the LAN port on the back of your TV to an external modem or router using a LAN (Ethernet/Cat 5) cable. See the illustration below. · It is recommended to use a modem or router that supports Dynamic Host Configuration Protocol (DHCP).
  • Page 16 Making Connections Outdoor Antenna Cable ANT OUT ANT 1 DVB-T/T2/C Antenna Cable (75Ω) (not included) VHF/UHF Antenna ANT 2 DVB-S/S2 (not included) Satellite antenna Audio Amplifier/Speaker DIGITAL DIGITAL AUDIO OUT AUDIO OUT DIGITAL AUDIO cable (not included) Audio Amplifier/Speaker HDMI (ARC) HDMI HDMI (ARC)
  • Page 17 Making Connections CAM CARD SMART CARD NOTES Before you insert/remove the CI+ module, ensure that the TV COMMON is switched off. Then insert the CI card into the CI+ module in INTERFACE accordance with the Service Provider's instructions. Do not repeatedly insert or remove the Common Access Module as this may damage the interface and cause a malfunction.
  • Page 18 MEDIA: Enter the media mode : All Apps BROWSER: Enter into BROWSER Bluetooth remote control module specifications for ERF3A80 / ERF3B80H / ERF3C80H / ERF3D80H / ERF3E80H / ERF3I80H / Bluetooth remote control module specifications for ERF3H80H / ERF3A80(0012) / ERF3B80H(0012) / ERF3C80H(0012)
  • Page 19 Remote Control : Switch the TV on or into standby mode INPUT: Select input sources : Activate the microphone : Media content control function buttons : Enter Channels / input numbers and special function buttons (Red/Green/Yellow/Blue) / < / >: Allow you to navigate the on-screen menus and adjust the system settings to your preference OK: Confirm the selection in the on-screen menus...
  • Page 20 Remote Control POWER: Switch the TV on or into standby mode INPUT: Select input sources Number button: Direct channel selection or numbers input GUIDE: Display the Electronic Programme Guide (DTV mode) CH.List: Display the Channel List on the screen Special function buttons : Display the Quick setup menu : Media content control function buttons / <...
  • Page 21 Remote Control Installing Batteries in the Remote Control 1. Slide the back cover to open the battery compartment of the remote control. 2. Insert two AAA size batteries. Make sure to match the (+) and ( - ) ends of the batteries with the (+) and ( - ) ends indicated in the battery compartment.
  • Page 22 Remote Control Remote Control Operation Range 1. The remote control can work at a distance of up to 8 metres in front of the TV set. 2. The remote control angle: taking the remote sensor as an apex, 6 metres away, its controlled horizontal angle is within ±30°, while the vertical angle is within ±15°.
  • Page 23 Turning the TV on for the First Time Turning the TV on for the First Time 1. Connect the mains cable to the mains socket after you have completed all the connections. 2. The first time you turn the TV on, it will go straight into the Installation Guide. 3.
  • Page 24 Specifications Features, appearance and specifications are subject to change without notice. Item 43" 50" 37.9 × 22.0 × 2.9 inches 44.0 × 25.4 × 2.9 inches Without Stand (963 × 560 × 74 mm) (1117 × 646 × 74 mm) Dimension (W ×...
  • Page 25 Specifications Item 58" 51.0 × 29.6 × 2.8 inches Without Stand (1295 × 752 × 70 mm) Dimension (W × H × D) 51.0 × 32.0 × 11.5 inches With Stand (1295 × 812 × 291 mm) Without Stand 27.6 lbs (12.5 kg) Weight With Stand 27.8 lbs (12.6 kg)
  • Page 26 Specifications Item 55" 65" 57.2 × 32.8 × 2.9 inches 48.5 × 28.0 × 2.9 inches Without Stand (1232 × 711 × 74 mm) (1452 × 834 × 74 mm) Dimension (W × H × D) 57.2 × 35.3 × 11.5 inches 48.5 ×...
  • Page 27 Other Information Recycling/Licenses WEEE (Waste Electronic Electric Equipment) European Directive 2012/19/EU This symbol on the product or on its packaging indicates that this product must not be disposed of with your household waste. Instead, it is your responsibility to dispose of your waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment.
  • Page 28 SIMPLIFIED EU DECLARATION OF CONFORMITY Hereby, Hisense Visual Technology Co., Ltd. declares that the radio equipment type [ERF3A80 / ERF3B80H / ERF3C80H / ERF3D80H / ERF3E80H / ERF3I80H / ERF3H80H / ERF3AB80H / ERF3N80H / ERF3F90H / ERF3A80(0012) / ERF3B80H(0012) /...
  • Page 29 Other Information EPREL Registration Information Model identifier Eprel registration number Model identifier Eprel registration number 43A6BG 758131 50A6BG 726259 43A6CG 758161 50A6CG 726487 43A6DG 758177 50A6DG 726498 43A6DGCH 758183 50A6DGCH 726500 43A6EG 758332 50A6EG 726503 43A6FG 758338 50A6FG 726504 43A6GG 848551 50A6GG 848170...
