Page 1
Read the manual carefully and ensure you have fully understood its contents before operating this device for the first time. English Deutsch Español Italiano Português Français Nederlands ES-A214207-1 B...
Page 2
Read the manual carefully and ensure you have fully understood its contents before operating this device for the first time. English...
Page 3
Important Safety Instructions ▐ Important Notice Paragraphs beginning with the symbol indicate important instructions, tips or conditions for the following settings. For your own safety and the optimal performance of your TV, ensure to read the safety instructions before performing any installation. Compatibility with 3rd party products, software and services are not guaranteed.
Page 4
Important Safety Instructions The intended use and ambient conditions for this TV This TV is intended for the rendering of video and audio signals, on a table-top or wall- mounted, in a home or office environment. It must not be used in rooms with a high level of humidity or dust concentration.
Page 5
Important Safety Instructions Moving/Transportation Power plug and power cable Before moving this TV, disconnect all - Do not touch the power plug with wet cables and move in the vertical position hands. only. Grasp the device on the upper and - Do not place heavy objects on the lower edges of the frame.
Page 6
Important Safety Instructions When mounting the TV on a wall, follow 20cm the instructions supplied with the wall- mount, make sure not to install the TV by 10cm 10cm 10cm hanging the power and signal cables on the back of the TV. ...
Page 7
Important Safety Instructions Radio waves fine and the fumes from the off-gassing will diminish eventually. - Do not use the TV in any medical institutions or locations with medical Supervision equipment. Radio waves may interfere with medical equipment and cause - Do not let children play unsupervised malfunction.
Page 8
Important Safety Instructions Cleaning and care swallowed. If swallowed by mistake, force the patient to vomit and visit the nearest hospital. CAUTION: Unplug the power cord prior to cleaning Modification the TV. Clean the TV, the screen, and the remote Do not attempt to modify this product control with a soft, moist, clean and in any way.
Contents Figures and illustrations in this manual are provided for reference only and may differ from actual product appearance. Parts of the software function changes with the system upgrade. Contents Accessories List......................1 Installing the Stand or Wall mount bracket ..............2 TV Front..........................4 TV Rear ..........................5 Making Connections .......................6...
Installing the Stand or Wall mount bracket CAUTION Be sure to disconnect the AC power cord before installing a stand or wall mount brackets. The display on your TV is fragile. Make sure the TV screen is not scratched or damaged by hard objects or from pressure.
Page 11
Installing the Stand or Wall mount bracket Screws: M4×12 Base Stand Installing the wall mount bracket Before mounting the TV, remove the TV stand if you have already attached it, and make sure the wall mount bracket supports the weight of your TV. CAUTION When mounting the TV on a wall, follow instructions provided with the wall mount bracket.
TV Front TV Front Remote sensor/Power indicator/Single button (Standby/Source) Item Description Receive remote signals from the remote control. Remote sensor Do not put anything near the sensor, as its function may be affected. Power indicator The light is red in standby mode. Press the single button when in standby mode, and the TV will be turned on.
TV Rear TV Rear 43" 50"/58" AC INPUT NOTES For 43", ANT2 Jack supports power supply for satellite antenna (13/18V, 420mA max.) For 50"/58", ANT2 Jack supports power supply for satellite antenna (13/18V, 0.5A max.) Check the jacks for position and type before making any connections.
Making Connections Wired setup LAN ( Connect your TV to your network by connecting the LAN port on the back of your TV to an external modem or router using a LAN (Ethernet/Cat 5) cable. See the illustration below. · It is recommended to use a modem or router that supports Dynamic Host Configuration Protocol (DHCP).
Page 15
Making Connections Outdoor Antenna Cable ANT OUT ANT 1 DVB-T/T2/C Antenna Cable (75Ω) (not included) VHF/UHF Antenna ANT 2 DVB-S/S2 (not included) Satellite antenna Audio Amplifier/Speaker DIGITAL DIGITAL AUDIO OUT AUDIO OUT DIGITAL AUDIO cable (not included) Audio Amplifier/Speaker HDMI (ARC) HDMI HDMI (ARC)
Page 16
Making Connections CAM CARD SMART CARD NOTES Before you insert/remove the CI+ module, ensure that the TV COMMON is switched off. Then insert the CI card into the CI+ module in INTERFACE accordance with the Service Provider's instructions. Do not repeatedly insert or remove the Common Access Module as this may damage the interface and cause a malfunction.
Remote Control INPUT: Select input sources POWER: Switch the TV on or into standby mode Number button: Direct channel selection or numbers input GUIDE: Display the Electronic Programme Guide (DTV mode) CH.LIST: Display the Channel List on the screen Special function buttons : Display the Quick setup menu : Media content control function buttons / <...
Page 18
Remote Control POWER: Switch the TV on or into standby mode INPUT: Select input sources Number button: Direct channel selection or numbers input GUIDE: Display the Electronic Programme Guide (DTV mode) CH.LIST: Display the Channel List on the screen Special function buttons : Display the Quick setup menu : Media content control function buttons / <...
Page 19
Remote Control Installing Batteries in the Remote Control 1. Slide the back cover to open the battery compartment of the remote control. 2. Insert two AAA size batteries. Make sure to match the (+) and ( - ) ends of the batteries with the (+) and ( - ) ends indicated in the battery compartment.
Page 20
Remote Control Remote Control Operation Range 1. The remote control can work at a distance of up to 8 metres in front of the TV set. 2. The remote control angle: taking the remote sensor as an apex, 6 metres away, its controlled horizontal angle is within ±30°, while the vertical angle is within ±15°.
Turning the TV on for the First Time Turning the TV on for the First Time 1. Connect the mains cable to the mains socket after you have completed all the connections. 2. The first time you turn the TV on, it will go straight into the Installation Guide. 3.
Specifications Features, appearance and specifications are subject to change without notice. Item 43" 37.9 × 22.0 × 2.9 inches Without Stand (963 × 560 × 74 mm) Dimension (W × H × D) 37.9 × 24.2 × 7.7 inches With Stand (963 ×...
Page 23
Specifications Model TX7663BU51T 2.4~2.4835GHz Frequency Range 5.15~5.85GHz Wireless 2.4~2.4835GHz 17dBm LAN Module specifications 5.15~5.25GHz 15dBm Output Power 5.25~5.35GHz(DFS Band) 14dBm (Max.) 5.49~5.71GHz(DFS/TPC Band) 13dBm 5.725~5.85GHz(for Non EU) 13dBm Model TX7663BU51T Bluetooth Frequency Range 2.4~2.4835GHz Module specifications Output Power 2.4~2.4835GHz,Class1,6dBm (Max.) Temperature: 41°F - 95°F (5°C - 35°C) Environmental conditions Humidity: 20% - 80% RH...
Other Information Recycling/Licenses WEEE (Waste Electronic Electric Equipment) European Directive 2012/19/EU This symbol on the product or on its packaging indicates that this product must not be disposed of with your household waste. Instead, it is your responsibility to dispose of your waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment.
Page 25
ALL RIGHTS RESERVED. SIMPLIFIED EU DECLARATION OF CONFORMITY Hereby, Hisense Visual Technology Co., Ltd. declares that the radio equipment type [ ERF3A80 / ERF3B80H / ERF3C80H / ERF3D80H / ERF3E80H / ERF3H80H / ERF3I80H / ERF3A80(0012) / ERF3B80H(0012) / ERF3C80H(0012) / ERF3D80H(0012)
Page 26
Other Information EPREL Registration Information Model identifier Eprel registration number Model identifier Eprel registration number 50A6BG 726259 58A6BG 772598 50A6CG 726487 58A6CG 772904 50A6DG 726498 58A6DG 772910 50A6DGCH 726500 58A6DGCH 772914 50A6EG 726503 58A6EG 772919 50A6FG 726504 58A6FG 772924 50A6GG 848170 58A6GG 851466...
