Summary of Contents for Hisense ERF3A86
-
Page 14: Installing The Stand Or Wall-Mount Bracket
Installing the Stand or Wall mount bracket 10. Slightly push the centre of the Part a2, then slightly pinch the both sides. Part a2 Part a2 11. Now, you can place the TV on a surface, and tear off all protective film on TV. Installing the wall mount bracket Before mounting the TV, remove the TV stand if you have already attached it, and make sure the wall mount bracket supports the weight of your TV. - Page 15 TV Front TV Front TV back view Joystick button Remote sensor/Light sensor Power indicator Item Description Receives remote signals from the remote control. Remote sensor Do not put anything near the sensor, as its function may be affected. The light is off when the TV is turned on. The light is white in Power indicator standby mode.
- Page 16 TV Rear TV Rear AC INPUT DIGITAL AUDIO OUT USB 2 DC 5V 0.5A(MAX) NOTE ANT2 Jack supports power supply for satellite antenna (13/18V, 0.5A max.) Check the jacks for position and type before making any connections. Loose connections can result in image or colour problems.
-
Page 17: Making Connections
Making Connections Wired setup LAN ( Connect your TV to your network by connecting the LAN port on the back of your TV to an external modem or router using a LAN (Ethernet/Cat 5) cable. See the illustration below. · It is recommended to use a modem or router that supports Dynamic Host Configuration Protocol (DHCP). - Page 18 Making Connections Outdoor Antenna Cable ANT OUT ANT 1 DVB-T/T2/C Antenna Cable (75Ω) (not included) VHF/UHF Antenna ANT 2 DVB-S/S2 (not included) Satellite antenna 13/18V 0.5A Audio Amplifier/Speaker DIGITAL DIGITAL AUDIO OUT AUDIO OUT DIGITAL AUDIO cable (not included) Audio Amplifier/Speaker HDMI (eARC) HDMI...
- Page 19 Making Connections CAM CARD SMART CARD NOTE Before you insert/remove the CI+ module, ensure that the TV is switched off. Then insert the CI card into the CI+ module in accordance with the Service Provider's instructions. COMMON Do not repeatedly insert or remove the Common Access INTERFACE Module as this may damage the interface and cause a malfunction.
-
Page 20: Remote Control
Remote Control POWER: Switch the TV on or into standby mode INPUT: Select input sources APP: Quick access buttons to apps EDIT: Custom to launch input or app Physical Switch (Side view): Turn on to activate hands-free wake-up feature* Special function buttons : Display the Quick setup menu : Media content control function button / <... - Page 21 Remote Control INPUT: Select input sources POWER: Switch the TV on or into standby mode Number button: Direct channel selection or numbers input GUIDE: Display the Electronic Programme Guide (DTV mode) CH.LIST: Display the Channel List on the screen Special function buttons : Display the Quick setup menu : Media content control function buttons / <...
- Page 22 Remote Control : Switch the TV on or into standby mode INPUT: Select input sources : Activate the microphone : Media content control function buttons : Enter Channels / input numbers and special function buttons (Red/Green/Yellow/Blue) / < / >: Allow you to navigate the on-screen menus and adjust the system settings to your preference OK: Confirm the selection in the on-screen menus...
- Page 23 Remote Control POWER: Switch the TV on or into standby mode INPUT: Select input sources Number button: Direct channel selection or numbers input GUIDE: Display the Electronic Programme Guide (DTV mode) CH.List: Display the Channel List on the screen Special function buttons : Display the Quick setup menu : Media content control function buttons / <...
-
Page 24: Installing Batteries In The Remote Control
Remote Control Installing Batteries in the Remote Control 1. Slide the back cover to open the battery compartment of the remote control. 2. Insert two AA or AAA size batteries. Make sure to match the (+) and ( - ) ends of the batteries with the (+) and ( - ) ends indicated in the battery compartment. -
Page 25: Remote Control Operation Range
Remote Control Remote Control Operation Range 1. The remote control can work at a distance of up to 8 metres in front of the TV set. 2. The remote control angle: taking the remote sensor as an apex, 6 metres away, its controlled horizontal angle is within ±30°, while the vertical angle is within ±15°. -
Page 26: Turning The Tv On For The First Time
Turning the TV on for the First Time Turning the TV on for the First Time 1. Connect the mains cable to the mains socket after you have completed all the connections. 2. The first time you turn the TV on, it will go straight into the Installation Guide. / <... -
Page 27: Environmental Conditions
Specifications Features, appearance and specifications are subject to change without notice. 65" Item 57.0 × 33.7 × 1.9 inches Without Stand (1447 × 857 × 49 mm) Dimension (W × H × D) 57.0 × 36.5 × 11.3 inches With Stand (1447 ×... - Page 28 Specifications RGB / 60Hz (640×480, 800×600, 1024×768) YUV / 60Hz (480i, 480p, 720p, 1080i, 1080p) YUV / 50Hz (576i, 576p, 720p, 1080i, 1080p) 3840×2160 / 24Hz, 3840×2160 / 25Hz, 3840×2160 / 30Hz, 3840×2160 / 50Hz, HDMI Input 3840×2160 / 60Hz For HDMI 3, 4: 3840×2160 / 120Hz, 2560×1440 / 120Hz, 1920×1080 / 120Hz...
-
Page 29: Other Information
Other Information Recycling/Licenses WEEE (Waste Electronic Electric Equipment) European Directive 2012/19/EU This symbol on the product or on its packaging indicates that this product must not be disposed of with your household waste. Instead, it is your responsibility to dispose of your waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment. - Page 30 Other Information For DTS patents, see http://patents.dts.com. Manufactured under license from DTS Licensing Limited. DTS, DTS-HD Master Audio, DTS-HD, Virtual:X, and the DTS-HD logo are registered trademarks or trademarks of DTS, Inc. in the United States and other countries. © 2021 DTS, Inc. ALL RIGHTS RESERVED.
- Page 31 Other Information SIMPLIFIED EU DECLARATION OF CONFORMITY Hereby, Hisense Visual Technology Co., Ltd. declares that the radio equipment type [ERF3A86 / ERF3B86H / ERF3C86H / ERF3D86H / ERF3E86H / ERF3F86H / ERF3G86H / ERF3N80H / ERF3M80H / ERF3F90H / 65A9H / 65A90H / 65A91H / 65A92H / 65A9HCH / 65A90HCH /...
