Summary of Contents for Hisense 32A5700FA
- Page 1 Read the manual carefully and ensure you have fully understood its contents before operating this device for the first time. English Deutsch Español Italiano Português Français Nederlands ES-A201902-2...
- Page 2 Read the manual carefully and ensure you have fully understood its contents before operating this device for the first time. English...
- Page 3 Important Safety Instructions ▐ Important Notice Paragraphs beginning with the symbol indicate important instructions, tips or conditions for the following settings. For your own safety and the optimal performance of your TV, ensure to read the safety instructions before performing any installation. It is not guarantee operation and performance of peripheral devices made by other manufacturers.
- Page 4 Important Safety Instructions The intended use and ambient conditions for this TV This TV is intended for the rendering of video and audio signals, on a table-top or wall- mounted, in a home or office environment. It must not be used in rooms with a high level of humidity or dust concentration.
- Page 5 Important Safety Instructions „ Moving/Transportation „ Power plug and power cable Before moving this TV, disconnect all - Do not touch the power plug with wet cables and move in the vertical position hands. only. Grasp the device on the upper and - Do not place heavy objects on the lower edges of the frame.
- Page 6 Important Safety Instructions „ Air ventilation and high Prevent small items from getting into the interior of the device through the ventilation temperatures slots. Such objects may cause short circuits, Install your TV only where there is proper which may cause fire. ventilation, and ensure that there is at least If something should get inside the unit, 10 cm free space on the sides and 20 cm...
- Page 7 Important Safety Instructions If you have a cardiac pacemaker, keep a „ Volume distance of at least 22 cm from the TV. Radio Loud music and noises can lead to waves may interfere with the operation of a irreversible damage to your ears. Avoid pacemaker.
- Page 8 Important Safety Instructions - Do not spray water or other liquids „ Remote Control batteries directly on the TV. Liquid inside the TV - Incorrect installation may cause battery could lead to product failure. leakage, corrosion and explosion. - The surface of the display panel is - Replace only with the same or treated and may be easily damaged.
-
Page 9: Table Of Contents
The accessories may be different from the list above due to different models, countries / regions, please refer to the actual accessory bag. SIMPLIFIED EU DECLARATION OF CONFORMITY Hereby, Hisense Visual Technology Co., Ltd. declares that the radio equipment type [32A5700FA/ 32A5720FA/ 32A5740FA/ 32A5760FA/ 32AE5600FA/ 32AE5610FA/ 32AE5630FA/ 32AE5650FA/ 32AE5730FA/ 32AE5750FA] is in compliance with Directive 2014/53/EU. -
Page 10: Installing The Stand Or Wall Mount Bracket
Installing the Stand or Wall mount bracket Installing the Stand CAUTION Be sure to disconnect the A/C power cord before installing a stand or Wall-Mount brackets. The screen is very fragile, and must be protected at all times when installing the base stand. - Page 11 Installing the Stand or Wall mount bracket Installing the wall mount bracket Wall mount hole pattern (mm) 100 × 200 Wall mount screw size (mm) 9.5 -11.5 mm Wall mount bracket Wall Mount Screw Rear cover of the TV Wall Mount Spacer Follow instructions provided with the Wall mount bracket.
-
Page 12: Tv Front
TV Front TV Front Remote sensor STANDBY Power indicator Item Description Receive remote signals from the remote control. Remote sensor Do not put anything near the sensor, as its function may be affected. Power indicator The light is red in standby mode. Press the button to turn on / off the TV. -
Page 13: Tv Rear
TV Rear TV Rear Power cord NOTES Check the jacks for position and type before making any connections. Loose connections can result in image or color problems. Make sure that all connections are tight and secure. Not all A/V devices have the ability to connect to a TV, please refer to the user’s manual of your A/V device for compatibility and connections procedure. -
Page 14: Making Connections
Making Connections Wired setup LAN ( Connect your TV to your network by connecting the LAN port on the back of your TV to an external modem or router using a LAN (Ethernet/Cat 5) cable. See the illustration below. · We recommend to use a modem or router that supports Dynamic Host Configuration Protocol (DHCP). - Page 15 Making Connections Outdoor Antenna Cable ANT OUT ANT 1 DVB-T/T2/C (not included) Antenna Cable (75Ω) VHF/UHF Antenna (not included) Satellite antenna Audio Amplifier/Speaker DIGITAL DIGITAL AUDIO OUT AUDIO OUT DIGITAL AUDIO cable (not included) Audio Amplifier/Speaker HDMI (ARC) HDMI HDMI cable (not included) HDMI DVD/Blu-Ray/AV receiver/ Set-top Box...
- Page 16 Making Connections COMMON INTERFACE (CARD FACE FRONT) CAM CARD SMART CARD NOTES Before you insert/remove the CI+ module, ensure that the TV is switched off. Then insert the CI card into the CI+ module in accordance with the Service Provider’s instructions. COMMON Do not repeatedly insert or remove the Common Access INTERFACE...
-
Page 17: Remote Control
Remote Control POWER: Switch the TV on or into standby mode INPUT: Select input sources INPUT Number button: Direct channel selection or numbers input GUIDE: Display the Electronic Program Guide (DTV mode) Subtitle: Activate or deactivate the subtitle mode Special function buttons GUIDE Subtitle The button for the Menu... - Page 18 Remote Control POWER: Switch the TV on or into standby mode INPUT: Select input sources Number button: Direct channel selection or numbers input GUIDE: Display the Electronic Program Guide (DTV mode) Display the current program information Special function buttons The button for the Menu TXT: Turn on/off the teletext function Receive the voice / <...
- Page 19 Remote Control Installing Batteries in the Remote Control 1. Slide the back cover to open the battery compartment of the remote control. 2. Insert two AAA size batteries. Make sure to match the (+) and ( - ) ends of the batteries with the (+) and ( - ) ends indicated in the battery compartment.
- Page 20 Remote Control NOTES If an unknown error occurred with the remote then it could have been caused by interference. Try to remove what's causing the interference and pair it again. If an unknown error occurred in the remote control while the battery power is normal, you can take out the batteries, press any key for 1~2 seconds, and insert them back.
-
Page 21: Turning The Tv On For The First Time
2. The first time you turn the TV on, it will go straight into the Setup Wizard. 3 Please complete your initial configuration with setup wizard before the experience of our Hisense Android TV. The prompt menu of setup wizard may vary per different models or countries. -
Page 22: Specifications
Specifications Features, appearance and specifications are subject to change without notice. 32" Item 28.2 × 16.9 × 3.4 inches Without Stand (716 × 428 × 86 mm) Dimension (W × H × D) 28.2 × 18.4 × 6.5 inches With Stand (716 ×... -
Page 23: Other Information
Other Information Recycling/Licenses WEEE (Waste Electronic Electric Equipment) European Directive 2012/19/EU This symbol on the product or on its packaging indicates that this product must not be disposed of with your household waste. Instead, it is your responsibility to dispose of your waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment. - Page 24 Other Information EPREL Registration Information Model identifier Eprel registration number Model identifier Eprel registration number 32A5700FA 359439 32A5720FA 359563 32A5740FA 359443 32A5760FA 359444 32AE5600FA 359565 32AE5610FA 359569 32AE5630FA 359570 32AE5650FA 359573 32AE5730FA 359575 32AE5750FA 359576...
