Page 1 C01-Cover_A str Important Operating and Safety Instructions are found in the Mower Safety Video that can be instantly accessed on the Internet at: www.algqr.com/ave Alamo Industrial ® 1502 East Walnut Seguin, Texas 78155 www.alamo-industrial.com E-Mail: parts@alamo-industrial.com...
Page 3 Your Authorized Alamo Industrial Dealer may have shown this video and presented you a DVD Video when you purchased your mower. If you or any mower operator have not seen this video, watch the Video, Read this Opera- tor’s Manual, and Complete the Video Guidebook before operating your new mower.
Page 4 Alamo Industrial will provide one (1) AEM Mower Safety Practices Video Please Send Me:  VHS Format – AEM/FEMA Mower Operator Safety Video  DVD Format – AEM/FEMA Mower Operator Safety Video  Mower Operator’s Manual  AEM Mower Operator’s Safety Manual...
Page 5 A Manual canister is provided on the implement where this manual can be properly stored. If you lose or damage this manual a free replacement manual can be obtained from an authorized Alamo Industrial dealer or by down loading the manual from the Alamo Industrial website www.www.alamo-industrial.com...
Page 6 DEALER to CUSTOMER Pre-Delivery / Operation Instructions Dealer should inform the Purchaser of this product of Warranty terms, provisions, and procedures that are applica- ble. Dealer should also inform the Purchaser to review the contents of the Operator’s Manual including safety equipment, safe operation and maintenance, to review the Safety Signs on the implement (and tractor if possible) and of Purchaser’s responsibility to train his/her operators in safe operation procedures.
Page 7 DECAL DESCRIPTION ..........................1 - 18 INTRODUCTION SECTION ................2 - 1 ATTENTION OWNER/OPERATOR......................... 2 - 4 ALAMO INDUSTRIAL LIMITED WARRANTY ....................2 - 5 ASSEMBLY SECTION...................3 - 1 GENERAL ................................ 3 - 2 Dealer Setup Instructions .......................... 3 - 2 ATTACHING COUPLING TO TRACTOR ......................
Page 8 Table of Contents Adjusting Degree of Mulching........................4 - 10 Adjusting the Leaf Spring Safety Mechanism ..................4 - 11 DRIVELINE ATTACHMENT .......................... 4 - 12 PRE-OPERATION INSPECTION AND SERVICE ..................4 - 14 Tractor Pre-Operation Inspection/Service ....................4 - 15 Mower Pre-Operation Inspection/Service ....................
Page 9 SAFETY SECTION Safety Section 1-1 @ 2021 Alamo Group Inc.
Page 10 SAFETY SAFETY MESSAGES A careful operator is the best operator. Safety is of primary importance to the manufacturer and should be to the owner/operator. Most accidents can be avoided by being aware of your equipment, your surroundings, and observing certain precautions. The first section of this manual includes a list of Safety Messages that, if followed, will help protect the operator and bystanders from injury or death.
Page 11 SAFETY OPERATOR SAFETY TO AVOID DEATH OR SERIOUS INJURY DO THE FOLLOWING: READ, UNDERSTAND and FOLLOW Operator's Manual instructions, Warnings and Safety Messages. • • WEAR SAFETY GLASSES with side shields (marked with ANSI Z87), safety shoes, hard hat, hearing protection and gloves when operating or repairing equipment.
Page 12 SAFETY CONNECTING OR DISCONNECTING IMPLEMENT SAFETY TO AVOID DEATH OR SERIOUS INJURY FROM BEING CRUSHED BY TRACTOR OR IMPLEMENT: WHEN BACKING tractor to implement hitch: • DO NOT ALLOW BYSTANDERS between tractor and implement BEFORE connecting and disconnecting implement hitch: STOP TRACTOR ENGINE, place transmission into park, engage parking brake and remove key.
Page 13 SAFETY CRUSHING HAZARDS TO AVOID DEATH OR SERIOUS INJURY FROM FALLING OFF TRACTOR, EQUIPMENT RUN OVER, ROLLOVER AND CRUSHING BY FALLING WING OR IMPLEMENT: • USE ROPS and SEAT BELT equipped tractors for mowing operations. • KEEP ROPS lock in up position. •...
Page 14 SAFETY THROWN OBJECT HAZARDS ROTARY MOWERS CAN THROW OBJECTS 300 FEET OR MORE UNDER ADVERSE CONDITIONS.. TO AVOID DEATH OR SERIOUS INJURY TO OPERATOR OR BYSTANDERS FROM THROWN OBJECTS: • KEEP bystanders 300 feet away STOP MOWING IF PASSERSBY ARE WITHIN 300 FEET UNLESS: •...
Page 15 SAFETY THROWN OBJECTS HAZARDS (CONTINUED) MOWER OPERATION: DO NOT exceed mower's rated Cutting Capacity or cut non-vegetative material. • • USE ENCLOSED TRACTOR CABS when two or more mowers are operating in mowing area. • Do Not mow in areas where bees or insects may attack unless you WEAR PROTECTIVE CLOTHING or use enclosed tractor cab.
Page 16 SAFETY RUN OVER HAZARDS TO AVOID DEATH OR SERIOUS INJURY FROM FALLING OFF TRACTOR OR EQUIPMENT RUN OVER: • USE ROPS and SEAT BELT equipped tractors for mowing operations. • KEEP ROPS locked in UP position. • ONLY start tractor while seated in tractor seat. ALWAYS BUCKLE UP seat belt when operating tractor and equipment.
Page 17 SAFETY PTO ENTANGLEMENT HAZARDS KEEP AWAY FROM ROTATING DRIVELINES AND ELEMENTS TO AVOID DEATH OR SERIOUS INJURY: STAY AWAY and KEEP hands, feet and body AWAY from rotating blades, drivelines and parts until all moving elements have stopped. • STOP, LOOK and LISTEN before approaching the mower to make sure all rotating motion has stopped. •...
Page 18 SAFETY MOWER BLADE CONTACT HAZARDS KEEP AWAY FROM ROTATING BLADES TO AVOID DEATH OR SERIOUS INJURY FROM BLADE CONTACT: • STAY AWAY and KEEP HANDS, FEET and BODY AWAY from rotating blades, drivelines and parts until all moving elements have stopped. DO NOT put hands or feet under mower decks •...
Page 19 SAFETY HIGH PRESSURE OIL LEAK HAZARDS TO AVOID DEATH OR SERIOUS INJURY FROM HIGH PRESSURE HYDRAULIC OIL LEAKS PENERATING SKIN: • DO NOT OPERATE equipment with oil or fuel leaks. • KEEP all hydraulic hoses, lines and connections in GOOD CONDITION and TIGHT before applying system pressure.
Page 20 SAFETY ELECTRICAL & FIRE HAZARDS TO AVOID DEATH OR SERIOUS INJURY FROM ELECTRICAL CONTACT WHEN WORKING AROUND ELECTRICAL POWER LINES, GAS LINES AND UTILITY LINES: • INSPECT mowing area for overhead or underground electrical power lines, obstructions, gas lines, cables and Utility, Municipal, or other type structure.
Page 21 SAFETY TRANSPORTING HAZARDS TO AVOID DEATH OR SERIOUS INJURY WHEN TOWING OR TRANSPORTING EQUIPMENT: • KEEP transport speed BELOW 20 mph to maintain control of equipment. • REDUCE SPEED on inclines, on turns and in poor towing conditions.. • DO NOT TOW with trucks or other vehicles USE only properly sized and equipped tractor for towing equipment.
Page 22 SAFETY HAZARDS WITH MAINTENANCE OF IMPLEMENT AVOID DEATH OR SERIOUS INJURY FROM COMPONENT FAILURE BY KEEPING IMPLEMENT IN GOOD OPERATING CONDITION IN PERFORMING PROPER SERVICE, REPAIRS AND MAINTENANCE. BEFORE PERFORMING SERVICE, REPAIRS AND MAINTENANCE ON THE IMPLEMENT: SECURE EQUIPMENT FOR SERVICE BLOCK OUT POTENTIAL ENERGY HAZARDS;...
Page 23 Non-genuine "will fit" parts do not consistently meet these specifications. The use of “will fit” parts may reduce mower performance, void mower warranties, and present a safety hazard. Use genuine Alamo Industrial mower parts for economy and safety. (SPAM-1str) See Your Alamo Dealer...
Page 24 NOTE: Alamo Industrial supplies safety decals on this product to promote safe operation. Damage to the decals may occur while in shipping, use, or reconditioning. Alamo Industrial cares about the safety of its customers, operators, and bystanders, and will replace the safety decals on this product in the field, free of charge (Some shipping and handling charges may apply).
Page 25 DANGER Thrown Object Hazards D628 DANGER Crushing Hazard - Pinch Points D547 DANGER Driveline Hazard D564 WARNING Use Genuine Alamo Industrial Parts 1458392 REFLECT Red Reflector D697 DANGER Crushing Hazard - Transport Latch 00776031 Canister 32122949 Operator’s Manual (inside Canister)
Page 26 SAFETY DECAL DESCRIPTION Roadmaster 1902S 11/21 Safety Section 1-18 @ 2021 Alamo Group Inc.
Page 27 SAFETY Roadmaster 1902S 11/21 Safety Section 1-19 @ 2021 Alamo Group Inc.
Page 28 SAFETY Roadmaster 1902S 11/21 Safety Section 1-20 @ 2021 Alamo Group Inc.
Page 29 SAFETY Roadmaster 1902S 11/21 Safety Section 1-21 @ 2021 Alamo Group Inc.
Page 30 SAFETY Roadmaster 1902S 11/21 Safety Section 1-22 @ 2021 Alamo Group Inc.
Page 31 SAFETY Roadmaster 1902S 11/21 Safety Section 1-23 @ 2021 Alamo Group Inc.
Page 32 SAFETY Roadmaster 1902S 11/21 Safety Section 1-24 @ 2021 Alamo Group Inc.
Page 33 SAFETY Roadmaster 1902S 11/21 Safety Section 1-25 @ 2021 Alamo Group Inc.
Page 34 SAFETY FEDERAL LAWS AND REGULATIONS This section is intended to explain in broad terms the concept and effect of federal laws and regulations con- cerning employer and employee equipment operators. This section is not intended as a legal interpretation of the law and should not be considered as such.
Page 36 Contents Acknowledgment ......2 Foreword ........2 Safety Alerts.
Page 37 Safety Alerts Symbol Signal Words This Safety Alert Symbol means: “ATTENTION! Signal words are distinctive words that will typically be STAY ALERT! YOUR SAFETY IS INVOLVED!” found on safety signs on the mower and other worksite equipment. These words may also be found in this The Safety Alert Symbol identifi es important safety manual and the manufacturer’s manuals.
Page 38 The Industrial/Agricultural Mower Industrial/Agricultural Mower Types Mowers are used for pasture clipping, crop residue shredding, heavy brush cutting, waterways, right-of- Flail ways, roadside or highway mowing. Also, these mowers are used for cutting grass and other growth in public areas such as parks and cemeteries. Boom Rotary Sickle Bar...
Page 39 Follow A Safety Program Protect Yourself Wear personal protective clothing and Personal Protective Equipment (PPE) issued to you or called for by job conditions. You must ALWAYS wear safety glasses with side shields. You may also need: — Hard hat —...
Page 40 Follow A Safety Program Avoid Injury From Raised Equipment Avoid Injury From High Pressure Fluid Avoid possible crushing injury from falling mower or Avoid fl uid injection injury due to high pressure fl uid leaks. other raised equipment. High Pressure Fluid Can Inject into the Body Avoid Crushing –...
Page 41 Follow A Safety Program Be Alert! For Safe Operation Know where to get assistance. Know how to use a fi rst You must be a qualifi ed and authorized operator for aid kit and fi re extinguisher/fi re suppression system. proper operation of your machine.
Page 42 Follow A Safety Program Some Rules You Must Work By (continued) Keep — Only qualifi ed and authorized individuals may operate Children this equipment. Away from — Never allow children to play on, ride on or operate Equipment the equipment. Children are not qualifi ed to operate this equipment.
Page 43 Prepare For Safe Operation Check The Mower And Tractor Equipment Before beginning your work day inspect the machine Walk-Around and have all systems in good operational condition. Inspection WARNING! Prevent possible crushing injury from falling equipment. Hydraulic system or part failure could cause unsupported equipment to fall.
Page 44 Prepare For Safe Operation Know The Work Area Correct unsafe conditions. Do not operate in problem areas where debris and obstacles cannot be removed Before you operate the mower thoroughly inspect or marked. the work area. Walk around the area and inspect the Analyze mowing area to determine: surfaces you will travel on when using the mower.
Page 45 Prepare For Safe Operation Tractor And Mower Controls Safety Test — Raise and lower mower to check for driveline bottoming out or engagement problems. Start the tractor following the specifi c procedures in the — Check the equipment for excessive vibration and manufacturer’s operator’s manual.
Page 46 Prepare For Safe Operation Hitching Mower To Tractor Read and Three-point hitch-mounted mowers: Understand Manuals Before — Refer to mower and tractor manufacturers’ manuals. Operating — Place tractor’s hydraulic power lift (rockshaft) selector lever in down position to avoid unexpected movement.
Page 47 Start Safely Make The Right Start Mow only in daylight or good artifi cial light conditions. Rotating Blades – Avoid serious injury or death from mower-thrown Keep Away objects or blade contact: — Keep chain shields, fl exible or solid defl ector shields or discharge chutes in place and in good repair.
Page 48 Operate Safely Mower-Thrown Objects (continued) Disc Mowers — When using a disc mower it is Do Not Mow important to know the area to be mowed. If the operator in Reverse has mowed the fi eld before and is familiar with all obstacles that may be present, it is suffi cient to watch ahead of the mower path for any additional objects that may have entered the fi eld.
Page 49 Operate Safely Under Mount Mower Safety Practices When mowing with an under mount mower: Never Stand — Keep removable discharge chute in place and over on Mower – Keep Away discharge opening. — Never stand on a mower housing when the tractor engine is operating.
Page 50 Operate Safely Wing And Side Mount Mowers Safety Practices 300 ft (92 m) Raised wing positions reduce shielding protection and Keep Bystanders increases the thrown object and blade contact hazard Away from risks. Mowing Area Avoid possible serious injury or death by thrown objects or blade contact from raising and lowering wings during mowing operations: —...
Page 51 Operate Safely Uneven Terrain Mowing Safety Practices (continued) Maintain — Use extreme care to maintain control over the Control, Use Low equipment when operating in these conditions. Speeds — Increase tractor stability by adding wheel weights, ballast and increasing wheel spacing to maximum. Refer to operator’s manual for recommendations.
Page 52 Park Safely Parking Safety Practices — Use designated or out-of-traffi c areas. — Use fi rm level ground locations. Parking Brake — Set parking brake. — Lower raised equipment to ground. Shut down the mower and tractor using proper equipment shut down practice before dismounting tractor.
Page 53 Shut Down Safely Dismounting Properly — Never dismount from moving equipment. Wait for — Never jump from any machines. Moving Parts to Stop — Dismount carefully. — Check for slippery steps. — Keep feet and hands away from controls. — Use handholds and steps during dismount. —...
Page 54 Perform Maintenance Safely Prepare Yourself Wear personal protective clothing and Personal Protective Equipment (PPE) issued to you or called for by job conditions. You must ALWAYS wear safety glasses with side shields. You may also need: — Hard hat — Safety shoes —...
Page 55 Perform Maintenance Safely Prepare The Machine — Securely support, block up, or lock up mower wings with approved locking devices before working near or Stored energy sources (electrical, mechanical, hydraulic, underneath a wing mower. pneumatic, chemical, thermal, etc.) must be controlled —...
Page 56 Perform Maintenance Safely Perform Maintenance Safely Use Proper Ventilation Make sure the hoists or jacks you use are in good repair. Never use jacks with cracked, bent, or twisted parts. If it is necessary to run an engine in an enclosed area, Never use frayed, twisted or pinched cables.
Page 57 Perform Maintenance Safely Hydraulic System Hazards When venting or fi lling the hydraulic system, loosen the fi ller cap slowly and remove it gradually. The hydraulic system is under pressure whenever the Never reset any relief valve in the hydraulic system to a engine is operating and may hold pressure even after the pressure higher than recommended by the manufacturer.
Page 58 Perform Maintenance Safely Avoid Explosion — Observe the polarity of the batteries and connections. — Make the fi nal cable connection to the engine or the WARNING! Avoid possible serious injury from furthest ground point away from the battery. Never explosion.
Page 59 Perform Maintenance Safely Tire And Wheel Maintenance (continued) Never cut or weld on a wheel with an infl ated tire mounted on it. This could cause explosive WARNING! The types of wheels and tires usually decompression. found on this equipment require special care when Check that the tire size and wheel are correctly matched.
Page 60 Perform Maintenance Safely Mower Blade Maintenance (continued) — Avoid bending blades. Help prevent mower blades from bending or cracking by avoiding contact with — How are mower blades made? solid objects. Mower blades are intended to cut Mower blades are made of high strength alloy spring grass, shrubs, woody vegetation, and small trees and steel.
Page 62 Contenido Reconocimiento ....... 2 Introducción ........2 Alertas de seguridad .
Page 63 Alertas de seguridad Símbolo Palabras indicativas Este símbolo de alerta de seguridad signifi ca: Las palabras indicativas son palabras distintivas que “¡ATENCIÓN! ¡MANTÉNGASE ALERTA! ¡SU típicamente se encontrarán en letreros de seguridad SEGURIDAD ESTÁ EN RIESGO!” de la cortadora de césped y otros equipos del sitio de trabajo.
Page 64 Cortadora de césped industrial/para agricultura Tipos de cortadora de césped industrial/para agricultura Las cortadoras de césped se usan para recortar pasturas, Triturador desmenuzar residuos de cultivos, cortar arbustos, realizar desbroce pesado, cortar la hierba en vías de agua, derechos de paso, costados de caminos o autopistas. Además, estas cortadoras se usan para cortar la hierba y otras plantas en zonas públicas como parques y cementerios.
Page 65 Cumplimiento del programa de seguridad Protéjase a sí mismo Use la ropa de protección personal y los equipos de protección personal (PPE) que se le proporcionen o que requieran las condiciones del trabajo. SIEMPRE debe usar gafas de seguridad con escudos laterales. Puede necesitar también: —...
Page 66 Cumplimiento del programa de seguridad Evite las lesiones provocadas por equipos elevados Si un ﬂ uido se inyecta en la piel, debe ser extraído dentro de pocas horas por personal médico Evite posibles lesiones de aplastamiento por caídas de la familiarizado con este tipo de lesión.
Page 67 Cumplimiento del programa de seguridad ¡Manténgase alerta! Para una operación segura Sepa dónde obtener asistencia. Sepa cómo usar un Usted debe ser un operador cualifi cado y autorizado equipo de primeros auxilios y un extintor de incendios/ para operar la máquina correctamente. Debe comprender sistema de supresión de fuego.
Page 68 Cumplimiento del programa de seguridad Algunas reglas que debe cumplir al trabajar (continuación) Mantenga — Únicamente personas cualifi cadas y autorizadas a los niños alejados pueden manejar estos equipos. de los equipos — Nunca permita que los niños jueguen en los equipos, viajen en ellos o los hagan funcionar.
Page 69 Preparación para una operación segura Revise los equipos de la cortadora de césped y el marcadas; incluya los pernos y sujetadores de las hojas. Nunca enderece o suelde en las hojas. tractor — Asegúrese de que el escudo para objetos que son Antes de comenzar la jornada de trabajo, inspeccione la arrojados se encuentre correctamente instalado y en buen máquina y asegúrese de que todos los sistemas estén en...
Page 70 Preparación para una operación segura Familiarícese con la zona de trabajo Corrija las condiciones no seguras. No opere en áreas con problemas donde no se puedan retirar o marcar los Antes de hacer funcionar la cortadora de césped, residuos y los obstáculos. inspeccione cuidadosamente la zona de trabajo.
Page 71 Preparación para una operación segura Prueba de seguridad de los controles del tractor y de la cortadora de césped Use el ROPS Arranque el tractor siguiendo los procedimientos y el cinturón de seguridad específi cos del manual del operador del fabricante. Estos procedimientos normalmente incluyen: —...
Page 72 Preparación para una operación segura Enganche de la cortadora de césped al tractor Lea y asegúrese Cortadoras montadas en enganche de tres puntos: de comprender los — Consulte los manuales de los fabricantes de la manuales antes de comenzar la cortadora y del tractor.
Page 73 Arranque con seguridad Cómo realizar un arranque correcto Corte la hierba únicamente con luz diurna o en condiciones de buena luz artifi cial. Hojas giratorias – Manténgase Evite lesiones graves o muerte producidas por objetos arrojados por la cortadora o por el contacto con las hojas: —...
Page 74 Operación con seguridad Objetos arrojados por la cortadora de césped Apague la TDF, espere que las hojas dejen de girar, eleve la cortadora y, después, retroceda. (continuación) Corte desplazándose en sentido de avance. Cortadoras de disco — Cuando se usa una cortadora de disco, es importante conocer la zona donde se va a cortar.
Page 75 Operación con seguridad Prácticas de seguridad para la cortadora de césped de montaje inferior Nunca se pare sobre la cortadora Cuando se traslada con una cortadora de césped de de césped – montaje inferior: Manténgase alejado — Mantenga la rampa de descarga extraíble en su lugar y por encima de la abertura de descarga.
Page 76 Operación con seguridad Prácticas de seguridad para cortadoras de 300 ft césped con laterales y montaje lateral (92 m) Mantenga a las personas ajenas Las posiciones elevadas de los laterales reducen la alejadas de la zona protección de los escudos y aumentan los riesgos de de corte objetos arrojados y contacto con las hojas.
Page 77 Operación con seguridad Prácticas de seguridad para trabajos de corte en terrenos desparejos (continuación) Mantenga — Use extremo cuidado para mantener el control de los el control, equipos cuando trabaja en estas condiciones. desplácese — Aumente la estabilidad del tractor agregando pesos o lastre en las ruedas y aumentando al máximo la separación entre las ruedas.
Page 78 Estacionamiento seguro Prácticas de seguridad para el estacionamiento — Use las zonas designadas o alejadas del tránsito. Aplique el freno de — Use lugares con suelo fi rme y nivelado. estacionamiento — Aplique el freno de estacionamiento. — Descienda el equipo de la cortadora de césped hasta el suelo.
Page 79 Apagado con seguridad Descenso correcto — Nunca descienda de equipos en movimiento. Espere hasta que las — Nunca baje de una máquina saltando. piezas móviles se detengan — Descienda con cuidado. — Verifi que que no haya peldaños resbaladizos. — Mantenga los pies y las manos lejos de los controles. —...
Page 80 Realización de mantenimiento con seguridad Preparación personal Use la ropa de protección personal y los equipos de protección personal (PPE) que se le proporcionen o que requieran las condiciones del trabajo. SIEMPRE debe usar gafas de seguridad con escudos laterales. Puede necesitar también: —...
Page 81 Realización de mantenimiento con seguridad Preparación de la máquina Deben controlarse o reducirse las fuentes de energía Prepare los sistemas de la almacenada (eléctricas, mecánicas, hidráulicas, máquina para neumáticas, químicas, térmicas, etc.) al mínimo realizarles servicios practicable antes de realizar cualquier procedimiento de mantenimiento, reparación o servicio.
Page 82 Realización de mantenimiento con seguridad Use ventilación adecuada Si es necesario hacer funcionar un motor en una zona Retire la llave y cerrada, elimine del área las emanaciones de escape lea el manual de con una extensión del caño de escape. Si no tiene esa mantenimiento extensión, asegúrese de abrir las puertas y dejar entrar aire del exterior.
Page 83 Realización de mantenimiento con seguridad Riesgos del sistema hidráulico Cuando ventila o llena el sistema hidráulico, afl oje la tapa de llenado con lentitud y retírela gradualmente. El sistema hidráulico se encuentra bajo presión siempre Nunca restablezca una válvula de alivio del sistema que el motor está...
Page 84 Realización de mantenimiento con seguridad Evite explosiones — Asegúrese de que las máquinas no se estén tocando. — Observe la polaridad de las baterías y conexiones. ¡ADVERTENCIA! Evite posibles lesiones graves por — Realice la conexión fi nal de cable al motor o al punto explosiones.
Page 85 Realización de mantenimiento con seguridad Mantenimiento de neumáticos y ruedas (continuación) Evite la explosión ¡ADVERTENCIA! Los tipos de ruedas y neumáticos de los neumáticos que generalmente se encuentran en estos equipos requieren cuidados especiales al realizar servicios para evitar lesiones graves o la muerte. No infl e los neumáticos por encima de la presión No infl e neumáticos con gases infl amables o con sistemas recomendada.
Page 86 Realización de mantenimiento con seguridad Mantenimiento de las hojas de la cortadora — Evite doblar las hojas. Contribuya a prevenir que las hojas de la cortadora se doblen o rajen evitando el (continuación) contacto con objetos sólidos. Las hojas de la cortadora —...
Page 87 INTRODUCTION SECTION Introduction Section 2-1 @ 2021 Alamo Group Inc.
Page 88 INTRODUCTION We are pleased to have you as a Alamo Industrial customer. Your Flail Cutter has been carefully designed with care and built with quality materials by skilled workers to give maximum service with minimum down time. This manual is provided to give you the necessary operating and maintenance instructions for keeping your flail cutter in top operation condition.
Page 89 INTRODUCTION You have acquired a Roadmaster 1902S flail mower. We wish you much success with this mower and thank you for your confidence in our organization. This manual is intended for end users and service engineers. Work that may only be done by service engineers is indicated as such in this book.
Page 90 INTRODUCTION ATTENTION OWNER/OPERATOR BEFORE OPERATING THIS MACHINE: 1. Carefully read the Operator’s Manual, completely understand the Safety Messages and instructions, and know how to operate correctly both the tractor and implement. 2. Fill out the Warranty Card in full. Be sure to answer all questions, including the Serial Number of the implement.
Page 91 ALAMO INDUSTRIAL LIMITED WARRANTY 1.LIMITED WARRANTIES 1.01. Alamo Industrial warrants for one year from the purchase date to the original non-commercial, governmental, or municipal purchaser (“Purchaser”) and warrants for six months to the original commercial or industrial purchaser (“Purchaser”) that the goods purchased are free from defects in material or workmanship.
Page 93 ASSEMBLY SECTION Assembly Section 3-1 @ 2021 Alamo Group Inc.
Page 94 ASSEMBLY GENERAL The Roadmaster 1902S will attach to most tractors with Cat II Hitch and 540 PTO RPM. Dealer Setup Instructions Assembly of this mower is the responsibility of the Alamo dealer. The mower should be delivered to the owner completely assembled, lubricated, and adjusted for normal cutting conditions.
Page 95 ASSEMBLY REMOVAL FROM TRACTOR Disconnecting should be carried out by one person. Never allow anyone to assist while dis- connecting the Roadmaster 1902S. This person would be in danger of being severely en- trapped. 1. Select a firm level site for parking the machine 2.
Page 97 OPERATION SECTION Operation Section 4-1 @ 2021 Alamo Group Inc.
Page 98 ALAMO INDUSTRIAL ROADMASTER 1902S OPERATION INSTRUCTIONS Alamo Industrial Roadmaster 1902S flail mowers are manufactured with quality material by skilled workers. These mowers are designed for cutting grass and small weeds up to 0.4” (1cm) in diameter. The mower is equipped with protective deflectors to prevent objects being thrown from the mower by the blades, however, no shielding is 100% effective.
Page 99 OPERATION 1. OPERATOR REQUIREMENTS Safe operation of the unit is the responsibility of a qualified operator. A qualified operator has read and understands the implement and tractor Operator’s Manuals and is experienced in implement and tractor operation and all associated safety practices. In addition to the safety messages contained in this manual, safety signs are affixed to the implement and tractor.
Page 100 OPERATION 2.TRACTOR REQUIREMENTS The tractor used to operate the mower must have the power capacity to lift, pull, and operate the Power Take Off (PTO) at the mower’s rated speed while traveling at a ground speed between 2 and 5 MPH. Operating the mower with a tractor that does not meet the following requirements may cause tractor or mower damage and be a potential danger to the operator and passersby.
Page 101 OPERATION unit. Lights and a SMV emblem must be equipped directly on implements if the visibility of the tractor warning signals are obscured. Maintain all manufacturer equipped safety shields and guards. Always replace shields and guards that were removed for access to connect, service, or repair the tractor or implement. Never operate the tractor PTO with the PTO master shield missing or in the raised position.
Page 102 OPERATION 3. GETTING ON AND OFF THE TRACTOR Before getting onto the tractor, the operator must read and completely understand the implement and tractor operator manuals. If any part of either manual is not completely understood, consult an authorized dealer for a complete explanation.
Page 103 OPERATION 4. STARTING THE TRACTOR The operator must have a complete understanding of the placement, function, and operational use of all tractor controls before starting the tractor. Review the tractor operator’s manual and consult an authorized dealer for tractor operation instructions if needed. Essential Tractor Controls: •...
Page 104 OPERATION 5. CONNECTING THE MOWER TO THE TRACTOR Use extreme caution when connecting the mower to the tractor. The mower should be securely resting at ground level or setting on blocks. Keep hands and feet from under the mower and clear of pinch points between the tractor and mower pins.
Page 105 OPERATION 5.2 Connecting Mower Hydraulics 1. With the tractor shut down and secured in position, move the hydraulic remote valve lever back and forth several times or place the hydraulic lever in the float position to relieve all hydraulic pressure. When connecting the mower hydraulic lines to the tractor, keep the hose, quick couplers, and swivels free of dirt and other contaminants.
Page 106 OPERATION 6. SETTING THE MOWER After the mower is attached to the tractor’s 3-point hitch, but before the universal slip joint is installed, and with the mower on the ground, adjust the top link of the hitch to make the mower gearbox input shaft parallel to the tractor PTO shaft.
Page 107 OPERATION 6.3 Adjusting the Leaf Spring Safety Mechanism The leaf spring safety mechanism must be adjusted in such a way that, during mowing activities the mechanism cannot get loose. Tightening should be performed by tightening or loosening the M16 nut, which determines the position of the clamping plate and also determines the tension of the leaf spring.
Page 108 OPERATION 7.DRIVELINE ATTACHMENT The driveline yoke and tractor PTO shaft must be dirt free and greased for attachment. To connect the mower driveline to the tractor PTO output shaft, pull the driveline yoke collar back and align the grooves and splines of the yoke with those of the PTO shaft.
Page 109 OPERATION 7.1 Driveline Length Check Before operating the Implement, check to make sure the Implement input driveline will not bottom out or become disengaged. Bottoming out occurs when the inner shaft penetrates the outer housing until the assembly becomes solid-it can shorten no more. Bottoming out can cause serious damage to the Tractor PTO by pushing the PTO into the Tractor and through the support bearings or downward onto the PTO shaft, breaking it off.
Page 110 OPERATION • Disconnect the driveline from the tractor and separate the two driveline halves. • Measure the distance from the mark to the end of the inner profile. This length is the amount the driveline profiles were engaged. • If the engaged length is less than 12” the shaft is considered too short and should be replaced with a longer shaft. Consult an authorized dealer to purchase the required driveline length.
Page 111 OPERATION 8.1 Tractor Pre-Operation Inspection/Service Refer to the tractor operator’s manual to ensure complete pre-operation inspection scheduled service is performed according to the manufacturers recommendations. The following are some of the items that require daily service and inspection: • Tire condition/air pressure •...
Page 112 OPERATION The operator’s manual and safety signs affixed on the unit contain important instructions on the safe and proper use of the equipment. Maintain these important safety features on the implement in good condition to ensure the information is available to the operator at all times.
Page 113 OPERATION • Inspect the condition of the drive belts. • Ensure the drive belts shields are in place and in good repair. • Ensure the tractor PTO master shield is in place, lowered and in good condition. • Inspect oil level in gearbox and replenish if needed.
Page 114 OPERATION HYDRAULIC LINE INSPECTION • Check for hydraulic leaks along hoses, cylinders and fittings. IMPORTANT: DO NOT use your hands to check for oil leaks. Use a piece of heavy paper or cardboard to check for hydraulic oil leaks. • Inspect the condition of the valve weldment.
Page 115 OPERATION • Inspect flails and shackles for looseness and excessive wear. • Replace damaged, worn, and missing flails and shackles as complete sets to maintain rotor shaft balance. If only the worst worn flails are replaced, the rotor shaft may get out of balance, resulting in vibration which could ruin the machine within a short time.
Page 116 OPERATION Flail Mower PRE-OPERATION Inspection Mower ID# ____________________ IMPORTANT: Scan this QR Code for an Date:________________________ electronic copy Make:________________________ this inspection sheet. Shift:________________________ Before conducting the inspection, make sure the tractor engine is off, all rotation has stopped and the tractor is in park with the parking brake engaged. Make sure the mower is resting on the ground or securely blocked up and all hydraulic pressure has been relieved.
Page 117 OPERATION Tractor PRE-OPERATION Inspection Tractor ID# ____________________ Make:_______________________ Date:________________________ Shaft: _______________________ Before conducting the inspection, make sure the tractor engine is off, all rotation has stopped and the tractor is in park with the parking brake engaged. Make sure the mower is resting on the ground or securely blocked up and all hydraulic pressure has been relieved.
Page 118 OPERATION 9.DRIVING THE TRACTOR AND IMPLEMENT Safe tractor transport requires the operator possess a thorough knowledge of the model being operated and precautions to take while driving with an attached implement. Ensure the tractor has the capacity to handle the weight of the implement and the tractor operating controls are set for safe transport.
Page 119 OPERATION 9.1 Starting the Tractor The procedure to start the tractor is model specific. Refer to the tractor operator’s manual for starting procedures for your particular tractor. Consult an authorized dealer if the starting procedure is unclear. Ensure the 3-point control lever is in the lowered position and the PTO is disengaged before starting the tractor.
Page 120 OPERATION 9.3 Operating the Mower Wing Transport Position With tractor engine running, turn off the tractor PTO Switch and wait for cuttershaft(s) to stop rotating. Using the tractor remote lever to fully raise mower wing unit. Then lift up transport link to pin attaching cylinder to actuator on A-frame.
Page 121 OPERATION Flail Mowers are capable under adverse conditions of throwing objects for great distances (300 feet or more) and causing serious injury or death. Follow safety messages carefully. STOP MOWING IF PASSERSBY ARE WITHIN 300 FEET UNLESS: - Front and Rear Deflectors, Chain Guards, or Bands are installed and in good, workable condition;...
Page 122 OPERATION 10.DRIVING THE TRACTOR AND MOWER Start off driving at a slow speed and gradually increase your speed while maintaining control of the tractor and mower. Moving slowly at first will also prevent the tractor from rearing up and loss of steering control.
Page 123 OPERATION 10.1 Crossing Ditches and Steep Inclines When crossing ditches with steep banks or going up sharp inclines, it is possible that the main driveline inner profile will penetrate into the outer housing to its maximum depth until the assembly becomes solid (driveline is at its extreme shortest length).
Page 124 OPERATION Inclines and ditches should be approached along a line which is at an angle as shown. This type of path will reduce the possibility of over-collapse of the driveline and resulting damage. If the gradient is so steep that such an approach increases the possibility of a tractor roll-over, select an alternate crossing path.
Page 125 OPERATION 11.1 Foreign Debris Hazards Before mowing, inspect the area to make sure there are no foreign objects that the mower blades could hit or become entangled with. Remove all foreign objects and debris. If objects are too big to remove, mark them clearly and be sure to prevent the mower blades from contacting them.
Page 126 OPERATION Flail Mowers are capable under adverse conditions of throwing objects for great distances (300 feet or more) and causing serious injury or death. Follow safety messages carefully. STOP MOWING IF PASSERSBY ARE WITHIN 300 FEET UNLESS: - Front and Rear Deflectors, Chain Guards, or Bands are installed and in good, workable condition;...
Page 127 OPERATION 11.4 PTO RPM and Ground Speed Ground speed for mowing will depend upon the height, type, and density of vegetation to be cut. Recommended speed for efficient mower performance is between 2 and 5 mph(3-8 kph). Operate the mower at its full rated PTO speed to maintain blade speed for a clean cut.
Page 128 OPERATION Do not mow with two machines in the same area except with Cab tractors with the windows closed. (SGM-11)str Mow only in conditions where you have clear visibility in daylight or with adequate artificial lighting. Never mow in darkness or foggy conditions where you cannot clearly see at least 300 feet (90 m) in front and to the sides of the tractor and mower.
Page 129 OPERATION 11.6 Shutting Down the Implement To shut down the implement, first bring the tractor to a complete stop. Then slow down the implement by reducing the engine speed before disengaging the PTO. Push the stop button to disengage the wings and wait for all motion to stop before proceeding to drive or shut down the tractor.
Page 130 OPERATION After disconnecting the 3 lift points, remove the mower driveline from the tractor PTO shaft. Lay the driveline down carefully to avoid damaging the driveline or its shield. Do not let the driveline fall into mud or dirt, which can contaminate the bearing and shorten the life of the driveline.
Page 131 OPERATION It is critical that driveline clutches slip when an obstacle or heavy load is encountered to avoid mower and/or tractor damage. If the mower sits outside for an extended period of time or is exposed to rain and/or humid air, the clutch lining plates must be inspected to ensure they are not frozen together from rust or corrosion.
Page 132 OPERATION Before transporting the tractor on a public roadway or boarding a trailer for transport, the tractor brake pedals should be locked together. Locking the pedals ensures that both wheels brake simultaneously while stopping, especially when making an emergency stop. Use extreme caution and avoid hard applications of the tractor brakes when towing heavy loads at road speeds.
Page 133 OPERATION The SMV (Slow-Moving Vehicle) and the “Speed Identification Sign (SIS)” emblems are universal symbols used to alert drivers of the presence of equipment traveling on roadways at a slow speed. SMV signs are a triangular bright orange with reflective red trim for both easy day and night visibility.
Page 134 14.2 Hauling the Tractor and Implement Before transporting a loaded tractor and mower, measure the height and width dimensions and gross weight of the complete loaded unit. Ensure that the load will be in compliance with the legal limits set for the areas that will be traveled through.
Page 135 OPERATION 15. TROUBLESHOOTING GUIDE Problem Possible Cause Remedy Excessive Blades missing. Replace blades. Vibration Not Cutting Blades dull. Sharpen or replace blades. Clean Cuttershaft RPM too low. Use correct PTO speed and check for correct speed changer ratio. (See specifications) Cutter not level.
Page 138 MAINTENANCE HAZARDS WITH MAINTENANCE OF IMPLEMENT AVOID DEATH OR SERIOUS INJURY FROM COMPONENT FAILURE BY KEEPING IMPLEMENT IN GOOD OPERATING CONDITION IN PERFORMING PROPER SERVICE, REPAIRS AND MAINTENANCE. BEFORE PERFORMING SERVICE, REPAIRS AND MAINTENANCE ON THE IMPLEMENT: SECURE EQUIPMENT FOR SERVICE BLOCK OUT POTENTIAL ENERGY HAZARDS;...
Page 139 Non-genuine "will fit" parts do not consistently meet these specifications. The use of “will fit” parts may reduce mower performance, void mower warranties, and present a safety hazard. Use genuine Alamo Industrial mower parts for economy and safety. (SPAM-1str) See Your Alamo Dealer Maintenance Instructions •...
Page 140 MAINTENANCE LUBRICATION Figure 5.1. shows the greasing points to be lubricated with a multipurpose lithium grease. To be lubricated daily: A. End bearing of rotor shaft B. Ball bearings of the roller C. Hinge bushes of the arms between 3-point linkage and main frame D.
Page 141 MAINTENANCE GEARBOX The oil content required for the gearbox is 2 quarts (64 ounces) of Gear Oil SAE 90 API GL4. The gearbox oil is to be changed for the first time after 20 running hours and subsequently once every a season. In addition, it is necessary to check the gearbox regularly for any leaks.
Page 142 MAINTENANCE DRIVELINE The Driveline should be inspected each morning before the mower is started. Cross & bearings are located at each end of driveline. Telescoping tube sitting is accessible by rotating driveline shield tubes until hole in shield exposes grease fitting.
Page 143 MAINTENANCE DRIVELINE SHIELD The Driveline Integral Shields should not become dented or otherwise damaged. The Integral Shield Assembly has a Nylon Bearing at each end and should turn freely. This nylon bearing should require lubrication every 8 hours. To remove the Integral Shields for replacement or repair, turn the three Nylon Nuts 1/4 turn in the Shield Slots of the Cone and Tube and remove them.
Page 144 MAINTENANCE V-BELT TRANSMISSION Removing the V-belt guard and V-belts: (see Figures 5.3) - Place the cutting head in horizontal position on the floor. - Remove the bolts on the V-belt guard. - Place the cutting head in vertical position and lock it into position. - Remove the V-belt guard.
Page 145 MAINTENANCE Checking V-Belt Tension - Remove bolts on the V-belt guard, - Remove the V-belt guard, - Exert a force of 22 lbs upon one of the belts, using for instance a spring balance. The depression is then not to exceed 23/64” (9mm). (see Figure 5.4), - Tension the belt, if necessary.
Page 146 MAINTENANCE REMOVING THE ROTOR SHAFT The rotor shaft may only be removed using a tackle having a lifting capacity of at least 660 lbs. - Place the cutting head in a vertical position and lock it, - Disassemble the rotor shaft bearing cover by removing the four M16 lock nuts. ATTENTION;...
Page 147 MAINTENANCE ASSEMBLING THE ROTOR SHAFT The rotor shaft may only be mounted using a tackle having a lifting capacity of at least 660 lbs! - Always fit new sealing rings and labyrinth seals. - Place the cutting head in a vertical position and lock it, - Attach the lifting tackle onto the flail shackle at a distance of approx.
Page 148 MAINTENANCE FLAILS Worn flails will diminish the of quality of mowing. In this case replace all flails and, if necessary the shackles and bolts. If only the worst worn flails are replaced, the rotor shaft may get out of balance, resulting in vibration which could ruin the machine within a short time.
Page 149 Flail rotor. Always replace blades as complete sets. Use only genuine Alamo Industrial replacement blades and fasteners. Other blades and fasteners may not meet the Alamo Industrial requirements and could fail during operation resulting in part being thrown out from under the mower.
Page 150 MAINTENANCE BLADE PINS AND D-RING INSPECTION Inspect Blade Pins and D-Rings daily for wear or damage as follows: Inspect the Blade pins and D-Rings daily for abnormal wear. Make sure the cotter pins are in place and properly spread. REPLACE BLADE Pins and D-Rings IMMEDIATELY if they have: •...
Page 151 MAINTENANCE GENERAL INFORMATION ON FLAIL MOWER VIBRATION FLAIL MOWERS INFORMATION BULLETIN NO. 5 EXCESSIVE VIBRATION Vibration is a MONSTER and if allowed to continue unchecked, can cause the complete break-up of a machine in a very short time. A properly operated Flail Mower will produce very little vibration. If vibration does occur, the mower should be stopped and the trouble corrected, as warranty does not cover failures resulting from continued operation after something happens to cause the mower to vibrate excessively.
Page 152 MAINTENANCE PROPER TORQUE FOR FASTENERS The chart lists the correct tightening torque for fasteners. When bolts are to be tightened or replaced, refer to this chart to determine the grade of bolts and the proper torque except when specific torque values are assigned in manual text.
