  • Page 2 This manual is not shipped with the product. If you need to obtain the electronic PDF file, you can log in to the official website of Buke (https: / / www.kinco. Cn /), "Service data download", search for keyword download.
  • Page 3 The K6S Series user manual safety instruction This chapter describes the safety precautions needed for the proper use of this product. Before using this product, please read the product manual and the associated manual introduced in the manual to correctly understand the relevant information of safety precautions.
  • Page 4 The K6S Series user manual When the power is powered  During the power supply, do not touch any terminal, terminal blocks, do not try to remove any unit. Especially during the power supply or just after the power supply is turned off, the capacitor discharge takes time, which may lead to electric shock or other personal and equipment hazards.
  • Page 5 The K6S Series user manual fire and other hazards;  When using connector and external equipment, pressing, compaction or proper welding shall be performed with the tools specified by the manufacturer. If the connection is bad, it may lead to short circuit, fire or other misoperation.
  • Page 6 The K6S Series user manual catalogue Version revision record ........................ I Manual acquisition ........................I Product programming software acquisition ................I safety instruction ........................II 1 General instructions .........................1 1.1 Product Introduction ....................1 1.2 Product naming and labeling ..................2 1.2.1 Product Naming Rules ..................2 1.2.2 Label information ....................
  • Page 7 The K6S Series user manual 4.1.5 K623S-16DT ......................44 4.1.6 K622S-16DTN ....................45 4.1.7 K633S-06IV .......................46 4.1.8 K631S-04TC ......................48 4.1.9 K631S-04RD ..................... 48 4.2 Wiring list ........................50 4.2.1 K615S-16DT ......................50 4.2.2 K621S-16DX ..................... 51 4.2.3 K622S-16DR ..................... 52 4.2.4 K622S-16DT ......................53 4.2.5 K623S-16DT ......................54...
  • Page 8 The K6S Series user manual 6.5.1 Compilation ..................... 77 6.5.2 Simulation ......................78 6.6 Connect and program on / download ................ 81 6.6.1 PC to communicate with K615S-16DT ............. 81 6.6.2 Program Upload / download ................85 6.7 Error information and processing ................88 6.7.1 KincoBuilder Error message ................88...
  • Page 9 1 General instructions 1.1 Product profile Kinco-K6S series PLC is a compact modular PLC launched by The Company. The modular connection design saves the horizontal installation space by more than 50%, and can avoid tool fastening wiring, making the installation and maintenance process more simple and efficient."Streamline"...
  • Page 10 The K6S Series user manual 1.2 Product naming and label 1.2.1 Product Naming Rules In order to facilitate users to clearly identify and order, the "product model" of K6S is consistent with the "order number". The naming rules of the product "order number / product model"...
  • Page 11 The K6S Series user manual 1.2.2 Label information Figure 1.2-2 Label interpretation Order number meaning ① EAC certification mark Model of the product ② Bits 1 to 6: Product code (unique for different models) 7~8: Production year: 20 [xx], the figure above shows the production in 2017;...
  • Page 12 The K6S Series user manual 1.3 Working and storage conditions The K6S series is designed to comply with the GB / T 15969.3-2007 (idt IEC61131-2:2007) standards and test specifications. Transportation and storage ambient -40℃～+70℃ temperature climatic relative conditions From 10% to 95%, with no condensation...
  • Page 13 The K6S Series user manual AC system, at 50Hz, voltage 0% for 1 wave, 40% for 10 wave, and 75% Voltage drop for 20 wave Performance level A levels of waterproof IP20 protection and dustproof...
  • Page 14 The K6S Series user manual 1.4 List of products model description CPU module DC 24V Power supply; DI 8 * DC 24V (source type / leakage type), DO 8 * DC 24V (PNP); Support 3-road 200 KHz high-speed count input, 1 single phase 20 KHz / double phase 10 KHz;...
  • Page 15 The K6S Series user manual 2. Product overview and hardware description 2.1 Introduction of K 6 S series Equipped with the new MCU platform, the execution speed is further improved. At  the same time, the program storage space of 8k instructions and 20k bytes (V + M) are provided, which provides a guarantee for the implementation of complex control program.
  • Page 16 The K6S Series user manual industrial bus protocol, TCP client / TCPserver free sending and receive, UDP peer free sending and receive, program upload download and firmware upgrade, suitable for multiple application requirements.
  • Page 17 The K6S Series user manual 2.2 CPU module components and specifications 2.2.1 Function Description of the components ① Dial switch ② RS485 * 2, the common site ③ label ④ The DIN guide rail card slot ⑤ CAN joggle ⑥ EtherN ET Interface ⑦...
  • Page 18 The K6S Series user manual DO terminal Output terminal connection, 8-way DO (PNP). ⑩ Status display area The CPU status is displayed, and the I / O terminal status is displayed. ⑪ lock catch For fastening assembly or disassembly between modules.
  • Page 19 The CAN interface supports the Kinco motion control protocol, which provides easy-to-use location control instructions and wizard configuration in the KincoBuilder. Users can easily connect to the Kinco's servo and step drive through the CAN bus. The Kinco motion control protocol supports connecting up to 16 nodes.
  • Page 20 The K6S Series user manual client / TCPserver free transceiver, UDP peer free transceiver, program upload download and firmware upgrade, suitable for the application needs of multiple occasions. pilot lamp pigment state explain Often bright A 100M communication connection Grey green (go...
  • Page 21 The K6S Series user manual CPU. The status of K6S is listed in the following below: pilot lamp pigment state explain Often bright The PLC is in a running state Grey (put out) / twinkle The PLC is in the firmware update mode...
  • Page 22 The K6S Series user manual all output points (DO, AO) immediately output the "stop output" value defined in the user project [Hardware Configuration] of the user.
  • Page 23 The K6S Series user manual  I/O pilot lamp Figure 2.2-5 I / O light indicator [I0.0~I0.7]: PLC body input status indicator light, gray (off) / green (bright), with external input, the light is on. [Q0.0~Q0.7]: PLC body output status indicator light, gray (out) / green (on), if the control output is on.
  • Page 24 The K6S Series user manual Figure 2.2-6, data hold settings Permanent storage refers to the opening of an area in the permanent memory (EEPROM) of the CPU for storing user data. Data outage in the area will not be lost and permanently saved, but the permanent memory has life and write speed limits, so it cannot be written frequently and quickly.
  • Page 25 The K6S Series user manual Compatible with Selection indicates that VB3648-4095 takes effect as a data backup area where the data is permanent storage automatically written into permanent memory. This K series PLC is supported, except for K3. settings (VB3648-VB4095)
  • Page 26 The K6S Series user manual The RTC clock battery  The K615S-16DT uses a lithium battery of specific specifications as a backup battery. When the power is cut off, the backup battery is used to power the real-time clock to maintain the clock running, and also to the SRAM to maintain data.
  • Page 27 The K6S Series user manual internal directional control reset Direction control bit: SM 47.3 Single-phase increment / subtraction counter clock direction with external directional control Bi-phase counter with increase / subtract clock Clock Clock (add) input (minus) Clock A Clock B...
  • Page 28 The K6S Series user manual Figure 2.2-10, High-speed counter instruction 2. Use HSC wizard setting: this way is simple and intuitive only need to check the content provided in the wizard setting, it is suitable for single segment PV setting mode and multiple segment PV setting mode, it is recommended to use the wizard setting, simple and convenient to save programming time.
  • Page 29 The K6S Series user manual Pulse position Q0.0 Q0.1 Q0.4 Q0.5 (Pulse + direction) Directional position Q0.2 Q0.3 Q0.6 Q0.7 outgoing channel Q0.0 Q0.1 Q0.4 Q0.5 2.2.1.12 Interrupt function The ontology input points I0.0 ~ I0.3 of K615S-16DT support the edge interrupt function, which can use the rising edge and descending edge of the input signal to generate the interruption.
  • Page 30 The K6S Series user manual The I / O terminal status display: DI / O: the digital quantity channel is up to indicate on, extinguished is Status display area ③ not connected; AI: The analog input channel is illuminated as the input / output overrun.
  • Page 31 The K6S Series user manual 8 channel Support for 4-channel high-speed pulse input Number of input channels Support the AB phase, P (pulse) / D (direction) mode The highest frequency of 3 input is 200 kHz, and the highest frequency...
  • Page 32 1 Road Supports CAN open, CAN free communication Support for the Kinco motion control function Ontology extension bus Support up to 16 K6S extension modules  Program storage and the RTC...
  • Page 33 The K6S Series user manual 3.2 Extended expansion module 3.2.1 K621S-16DX K621S-16DX module is a universal digital input module with 16 channels, including 2 groups (8 channels / group) universal transistor input and support source / leakage type.  Power specifications The module is connected by an extended interface and communicates through the dedicated bus protocol.
  • Page 34 The K6S Series user manual Allow load voltage DC 24V / AC 250V Allowable load current 2A / point, and 4A / group (resistance load) Allowable load current 1A / point, and 4A / group (inductive load) Output-on delay time 10ms (max.)
  • Page 35 The K6S Series user manual Output delay time · Connect delay Less than 30 μ s · Disconnect latency Less than 50 μ s defencive function: · Emotional load output protection have have · short-circuit protection Yes, allow to apply the reverse polarity signal at the output for no more ·...
  • Page 36 The K6S Series user manual State instructions With the input signal, the corresponding LED light is on DI image zone 1 Bytes  DO specifications Output type transistor PNP Number of output channels 8 (8-channel / group) Output current per channel...
  • Page 37 The K6S Series user manual Output current per channel Maximum of 300 mA @ 24 VDC Output leakage current Maximum of 10 μ A output impedence Maximum 0.3 Ω Output delay time · Connect delay Less than 30 μ s ·...
  • Page 38 The K6S Series user manual bits) Output signal accuracy 0.3% F.S. Conversion rate (per channel) About 15 times / s Current mode: 500 Ω external loading Voltage mode: Minimum of 10K Ω else The AI corresponding channel red LED indicates that the input...
  • Page 39 The K6S Series user manual The following table is the measurement range and measurement value representation format, where I represents the input current value and V represents the input voltage value. Measured values represent the Signal form measuring range format 4~20mA 3.92~20.4mA...
  • Page 40 The K6S Series user manual right sides of the temperature module will also affect the cold end value. When the left and right sides of the module are the temperature module (K631S-04RD / TC), the error of the cold end compensation is small, and when the left and right sides are non-temperature modules, the error of the cold end compensation is slightly larger.
  • Page 41 The K6S Series user manual K mould -270~1300℃ T×10（-2700~13000） E mould -270~1000℃ T×10（-2700~10000） S mould -50~1600℃ T×10（-500~16000） T mould -260~400℃ T×10（-2600~4000） 3.2.8 K631S-04RD The K631S-04RD module has four channels, which supports two and three-line thermal resistance temperature measurement of Pt 100, Pt1000, and Cu 50, and also supports direct measurement of resistance value.
  • Page 42 The K6S Series user manual format, where I represents the input current value and V represents the input voltage value. Signal form measuring range Measured values represent the format Pt100 -200~850℃ T ×10(-2000~8500) Cu50 -50~150℃ T ×10(-500~1500) Pt1000 -50~300℃ T ×10(-500~3000) resistance 0~2000Ω...
  • Page 43 The K6S Series user manual 4 Wiring and dimensions 4.1 Wiring instructions 4.1.1 K615S-16DT 4.1.1.1 Power supply wiring instructions Figure 4.1.1-1 Power supply terminal Silk printing meaning symbol 24 The VDC power supply main end 24 The VDC power supply reference place...
  • Page 44 The K6S Series user manual external wiring, and the dotted line is the leaky type input external wiring diagram. symbol meaning symbol meaning 24V DC power supply positive end (source type) I0.4 Universal / high-speed input 24V DC power supply reference ground (leakage type) I0.0...
  • Page 45 The K6S Series user manual 4.1.1.4 RS485 wiring instructions K615S-16DT module provides two serial communication interfaces, communication ports are named PORT 1, PORT 2, all RS485 ports provide complete isolation on the hardware, so as to ensure the stability and reliability of communication work. RS485 The...
  • Page 46 The K6S Series user manual Figure 4.1.1-5 RS485 extension...
  • Page 47 The K6S Series user manual 4.1.1.5 EtherNET wiring instructions EtherNET The communication cable adopts direct cable (through line) or cross cable (cross line). The Ethernet interface on the CPU module provides the "automatic negotiation" function. When the cable is inserted, it automatically negotiwith the communication party to determine the type of cable used.
  • Page 48 The K6S Series user manual Figure Figure 4.1.1-7 CAN RJ45 line number description signal description CAN_H CAN bus signal, high level CAN_L CAN bus signal, low level CAN_GND The CAN bus signal ground When use, the user needs to connect the CAN _ H and CAN _ L pins of all nodes in the network together.
  • Page 49 The K6S Series user manual 4.1.2 K621S-16DX Power wiring instructions  The module is connected by an extended interface and communicates through the dedicated bus protocol. The module power supply has been integrated in the dedicated bus without external wiring.
  • Page 50 The K6S Series user manual 4.1.3 K622S-16DR Power wiring instructions  The module is connected by an extended interface and communicates through the dedicated bus protocol. The module power supply has been integrated in the dedicated bus without external wiring.
  • Page 51 The K6S Series user manual 4.1.4 K622S-16DT Power wiring instructions  The module is connected by an extended interface and communicates through the dedicated bus protocol. The module power supply has been integrated in the dedicated bus without external wiring.
  • Page 52 The K6S Series user manual 4.1.5 K623S-16DT Power wiring instructions  The module is connected by an extended interface and communicates through the dedicated bus protocol. The module power supply has been integrated in the dedicated bus without external wiring.
  • Page 53 The K6S Series user manual 4.1.6 K622S-16DTN Power wiring instructions  The module is connected by an extended interface and communicates through the dedicated bus protocol. The module power supply has been integrated in the dedicated bus without external wiring.
  • Page 54 The K6S Series user manual 4.1.7 K633S-06IV Power wiring instructions  The module is connected by an extended interface and communicates through the dedicated bus protocol. The module power supply has been integrated in the dedicated bus without external wiring.
  • Page 55 The K6S Series user manual Figure 4.1.7-2:, og quantity input short signal  AI wiring instructions Figure 4.1.7-3: Example of analog output K633S-06IV provides 2 analog output channels, both supporting both current and voltage output modes. I, V, and M identification correspond to current output, voltage output and common end respectively.
  • Page 56 The K6S Series user manual 4.1.8 K631S-04TC Power wiring instructions  The module adopts the extended bus connection, and the module power supply has been integrated in the expansion bus.  TC wiring instructions Figure 4.1.8-1 TC wiring description K631S-04TC module provides 4 channels, "* +", "* -" (* channel group name: A / B / C / D group) corresponding to the positive and negative electrode of the thermocouple.
  • Page 57 The K6S Series user manual terminals: "* 1", "* 2", "* 3", "* 3" and "* 4" (* corresponding channel name: A / B / C / D group). As shown in the figure above, when connecting the second line thermal resistance, please connect the "1"...
  • Page 58 The K6S Series user manual 4.2 Wiring list 4.2.1 K615S-16DT Figure 4.2.1 Wiring diagram of K 615 S-16DT...
  • Page 59 The K6S Series user manual 4.2.2 K621S-16DX Figure 4.2.2 K621S-16DX wiring diagram...
  • Page 60 The K6S Series user manual 4.2.3 K622S-16DR Figure 4.2.3 K622S-16DR wiring diagram...
  • Page 61 The K6S Series user manual 4.2.4 K622S-16DT Figure 4.2.4 K622S-16DT wiring diagram...
  • Page 62 The K6S Series user manual 4.2.5 K623S-16DT Figure 4.2.5 K623S-16DT wiring diagram...
  • Page 63 The K6S Series user manual 4.2.6 K622S-16DTN Figure 4.2.6 K 622 DTN S-16...
  • Page 64 The K6S Series user manual 4.2.7 K633S-06IV Figure 4.2.7 K633S-06IV wiring diagram...
  • Page 65 The K6S Series user manual 4.2.8 K631S-04TC Figure 4.2.8 K631S-04TC wiring diagram...
  • Page 66 The K6S Series user manual 4.2.9 K631S-04RD Figure 4.2.9 K631S-04RD wiring...
  • Page 67 The K6S Series user manual 4.3 Dimension description 4.3.1 The CPU module Figure 4.2.2 K621S-16DX wiring diagram The above figure applies to the K6S series CPU K615S-16DT.
  • Page 68 The K6S Series user manual 4.3.2 Extended expansion module Figure 4.3.2 Expansion module dimension drawing The figure above applies to all the extended modules of the K6S series.
  • Page 69 5. Installation criteria 5.1 CPU module connection extension mode The K6S series adopts the physical connection mode of the expanded port needle row and socket, and the extended connection can be completed without external wiring. In the actual connection, with the CPU module as the starting point, the extension bus...
  • Page 70 The K6S Series user manual should not be pushed by brute force, otherwise the pin of the expansion port may be bent or broken, and the module cannot be normally connected to or even used normally; (2) When taking off the extension, pay attention to first pull the lock above the module and then remove, not brute force leverage or other ways to pull.
  • Page 71 The K6S Series user manual Figure 5.2-2 Physical drawing of the DIN guide rail 5.2.2 Installation / removal steps of the guide rail The installation steps are performed as follows: 1. Install the standard 35mm wide DIN guide rail first. If installed horizontally, have at least 60mm above and below the rail, and at least 60mm on the left and right of the rail.
  • Page 72 The K6S Series user manual Figure 5.2-4 Rail slide lock (left) / release (right) Figure 5.2-5 Effect diagram of DIN guide rail pay attention to: （1） To ensure good ventilation, leave at least 60mm of space on and below the module during installation, and have a depth of at least 100mm.
  • Page 73 5.3 Installation space requirements The K6S series is designed for natural convection cooling. To ensure adequate cooling, a minimum clearance of 60mm must be cleared above and below the equipment. In addition, a depth of at least 40mm shall be allowed between the front end of the module and the...
  • Page 74 The K6S Series user manual Figure 5.3-1, Installation space requirements...
  • Page 75 The K6S Series user manual 6 Use entry KincoBuilder Is the upper programming software of K series PLC of Step Company. The programming environment meets IEC61131-3 standard and helps users with efficient program development. The installation process and installation configuration requirements are omitted here, and only a brief introduction is made with the user introduction.
  • Page 76 The K6S Series user manual area All components of the project, including program, hardware configuration, variable status table, global variable table, etc. Users can manage, operate, and maintain the currently open project in this window. Each tree node of the Project Manager supports right-click.
  • Page 77 The K6S Series user manual by directly clicking the [New Project] button on the toolbar, as shown in the following figure. Figure 6.2-2, new construction path Then select the project save location in the [New Project] dialog box, modify the project name, and click "Save"...
  • Page 78 The K6S Series user manual configuration model of the new project can also be opened through the menu bar [tool] [software Settings], in the [default CPU model] in the drop-down menu, click [application] to save. Take the K615S-16DT as an example, the CPU configuration method is introduced here.
  • Page 79 The K6S Series user manual Figure 6.3-3 Configuration K615S-16DT Select the model in the [Hardware Configuration] interface, and the corresponding configuration interface can be opened. The following figure shows the configuration interface opened when K615S-16DT is selected. I / O configuration, communication configuration, data retention configuration, CANopen master station configuration and so on can be performed in this interface.
  • Page 80 KincoBuilder software before it can be really used. The specific steps to enable the expansion module on the software: [hardware configuration] [PLC module list] [K6S series], select K615S-16DT and double click to add.
  • Page 81 The K6S Series user manual Figure 6.3-1 Extension module configuration operation instructions If you need to set the expanded input and output, select the corresponding module model to open the relevant setting interface. Figure 6.3-2 The extended module parameter configuration...
  • Page 82 The K6S Series user manual Note: In the hardware configuration of KincoBuilder, the order of the expansion module should be added in accordance with the actual hardware connection order (from left to right), otherwise the PLC error will be caused.
  • Page 83 The K6S Series user manual Figure 6.4-2, with the online help interface 6.4.2 KincoBuilder Programming language KincoBuilder Support for IL language and LD language, in the software can be converted through the toolbar [engineering]. Figure 6.4-3, Programming language setting...
  • Page 84 The K6S Series user manual 6.4.3 Programming instructions The usage of specific programming instructions is not introduced here, but only introduces how to quickly obtain the usage of programming instructions: 1. Click the corresponding instruction and press F1. KincoBuilder will open the online help and automatically jump to the description page of the instruction.
  • Page 85 The K6S Series user manual Figure 6.4-5 Software Manual in Help ② Through the software manual to find the corresponding instruction usage, please download from the official website of the step manual, the product update may lead to the software and software manual has a certain lag, please download the new version of the software and the corresponding manual from the official website in time.
  • Page 86 The K6S Series user manual 6.5.2 Simulation The offline emulator of KPLC is provided in the KincoBuilder software, which can simulate real PLC runs in KincoBuilder and debug user programs. The offline emulator of KPLC provides advanced debugging functions such as breakpoint, single-step execution, single-network execution, pause / continue operation, and serial communication emulator.
  • Page 87 The K6S Series user manual Figure 6.5-3 Simulation interface Item Icon/Description Toggles Monitoring ① :Click to enter or exit monitoring mode. Mode ② :Click to enter offline simulation mode. Enter/Exit Simulation Mode :Click to exit offline simulation mode. ③ :Restart the simulation.
  • Page 88 The K6S Series user manual :Disable all breakpoints. :Enable all breakpoints. The [Debug program] window includes features such as: ④ ·Current status display ·Execution of scan cycles(executed) Debug Program ·Program network display(current) ·Jump to the next network ·Execute the specified scan cycles I/O channels Input or output signals can be simulated by checking the corresponding IO channel option.
  • Page 89 The K6S Series user manual 6.6 Connect and program on / download 6.6.1 PC to communicate with K615S-16DT  The K615S-16DT communicates with the PC via the Ethernet port: Use the standard network cable to correctly connect the PLC and the PC, for 1、...
  • Page 90 The K6S Series user manual Figure 6.6-2 Modify the IP of the PLC If you cannot scan to the connected PLC, you can right-click the [Ethernet 3、 double-click Scan Ethernet] or the [PC communication settings] drop-down box of the left device tree to select the network card connected to the PLC. And then a rescan.
  • Page 91 The K6S Series user manual Regardless of the path in the above point, the corresponding PLC information 4、 will appear after a successful scan:  [After double-click Scan Ethernet], all the PLs connected in the network appear under the device tree on the left, as shown in the left in Figure 6.6-6 below.
  • Page 92 The K6S Series user manual Figure 6.6-6 PLC scan and connection Figure 6.6-7 connection device error The K615S-16DT communicates with the PC via the RS485:  1、The RS485-USB programming cable is required to connect the PC and the PLC. The K615S-16DT has two RS485 interfaces, both of which support the programming protocol to power the PLC.
  • Page 93 The K6S Series user manual Figure 6.6-8 Serport setting of COM identification and upper computer 3、Click [Automatic detection] to wait for the successful recognition prompt. After successful identification, the left [PC serial communication parameter] will automatically correspond to the COM parameter of the current PLC, and finally click OK to complete the connection.
  • Page 94 The K6S Series user manual breakpoint continuation means that in the process of file transfer, the transmission can be restarted from the interrupted place without retransferring the entire file. This approach allows efficient file transfer even in case of network instability or interrupted transmission process.
  • Page 95 The K6S Series user manual Figure 6.6-11 Upload process As with the program upload, KincoBuilder also offers two ways to download  programs: [download] and [download (breakpoint continuation)]. Generally, users can use [download]. When the program is frequently interrupted by [download], the network is busy, long distance transmission, and the project volume is large, it is recommended to download the program by [download (breakpoint transmission)].
  • Page 96 The K6S Series user manual Figure 6.6-12 Download window open path Figure 6.6-13 Auto-compiled when opened project description Currently downloaded user When this option is enabled, all PLC stored user programs are encrypted and currently currently currently user stored in ciphertext, and the upload operation is not supported. Please check it upload (U) carefully and pay attention to the program backup.
  • Page 97 The K6S Series user manual communication state. If the current communication is not normal, it should be made first according to the PC communication connection method. Figure 6.7-1 PLC error information query path 6.7.2 Common Error Information Error information consists of two parts: error code and error information description.
  • Page 98 The K6S Series user manual of Buke. Please contact Kinco customer support department or local service center. If you need more detailed error code information, open the online help or download the page on the official website (<ϟ 1>kinco.cn/download/plc25.html) Download [Kinco-K series software manual] query solution.
  • Page 99 The user can operate according to the instructions of the corresponding model. Here is the applicable firmware update method for K6S series. The update steps are as 1. Use the communication cable to connect the PLC to the computer, and then power up the PLC.
  • Page 100 The K6S Series user manual follows: Update failed resolution: If the user encounters an error prompt that the update failed during the update, and the PLC running indicator [RUN] is constantly flashing, the user can try to start repeatedly [start update the system program].
  • Page 101 The K6S Series user manual 7. Product and service support 7.1 Product Support  Technical service hotline If you have any questions about the product selection or use process, you can call our technical service hotline for technical support service: 400-700-5281.
  • Page 102 The K6S Series user manual 8 Appendix 8.1 Quick selection list model description CPU module DC 24V Power supply; DI 8*DC 24V(PNP/NPN), DO 8*DC 24V(PNP)； Support 3-road 200 KHz high-speed count input, 1 single phase 20 KHz / double phase 10 KHz;...
