LUZON / LUZON DEEP
en
Instruction manual
en

Advertisement

loading
Need help?

Need help?

Do you have a question about the LUZON and is the answer not in the manual?

Questions and answers

Related Manuals for Igloo LUZON

Summary of Contents for Igloo LUZON

  • Page 1 LUZON / LUZON DEEP Instruction manual...
  • Page 2 Inox-Bázis Kft 9090 Pannonhalma, Arany János u. Központi major Hungary e-mail: info@inoxbazis.hu Tel.: +36 1 788-1828 www.inoxbazis.hu...
  • Page 3 2.1. Purpose LUZON is a universal cooling device used to store and display a wide assortment of grocery products in singular pac- kages, previously cooled to storage temperature. There is also a DEEP version of the case (ventilated, evaporator at the front, horizontal display shelves).
  • Page 4 LUZON LUZON FISH LUZON LUZON FISH User manual Luzon, Luzon Deep www.inoxbazis.hu...
  • Page 5 Unpack the device and remove the wooden platform from the basis (does not concern moving devices) Fig.2 Fig.2 Removing the wooden platform 1 – Unscrew the feet from the platform 2 – Remove the wooden platform 3 – Screw the feet in nuts welded to the frame of the device www.inoxbazis.hu User manual Luzon, Luzon Deep...
  • Page 6 Turn on the main switch Fig.10/1, which activates the temperature regulator, and then aggregate of the device NOTE: If the thermostat display (for „Igloo” thermostat) Fig.6/3 only shows two dots at the bot-tom instead of the temperature, this means that no unit is attached (cooling function disabled). In this case, switch the cooling on/off button on the thermostat panel - see Fig.11/1!
  • Page 7 2 – Top night shutter (long) – second to be installed 3 – „Blade” of the aluminum lamp (masks and protects the night shutters before falling out) 4 – Guide for night shutters (aluminum profile) www.inoxbazis.hu User manual Luzon, Luzon Deep...
  • Page 8 4 - Evaporator Fig.8 Control panel of the device 1 - Main switch (turns on/off the aggregate of the device) 2 – Lighting switch 3 - Thermostat (temperature regulator) panel User manual Luzon, Luzon Deep www.inoxbazis.hu...
  • Page 9 Avoid unnecessary opening of doors and leaving them open for a longer period of time. 4.1. Temperature regulation Service of “Igloo” and “Carel” thermostat (temperature regulators) is described in chapter 7 The basic aim of a thermostat is to control the cooling aggregate to obtain the set temperature within the device and maintain it within the determined temperature ranges.
  • Page 10 Clean condenser lamellas with help of soft brush or paint brush. If the condenser is extremely dirty (blocked lamellas) it is indicated to use vacuum cleaner or compressed nitrogen to suck / blow the dirt from be- tween lamellas. User manual Luzon, Luzon Deep www.inoxbazis.hu...
  • Page 11 During maintenance services it is necessary to pay attention not to damage the data place of the device Fig.11, which contains significant information for servicing organs and waste removal companies. www.inoxbazis.hu User manual Luzon, Luzon Deep...
  • Page 12 The main switch is on • Thermostat is on (This concerns the Igloo thermostat – If only two spots are visible on the display – turn on the thermostat) Water leakage from below the device or into the inside of the chamber: •...
  • Page 13 6.2. SERVICE If after checking points described in chapter 6.1 „Fault identification and repair” the device still does not work properly, please contact Technical Service of the Igloo company, stating the data from the data plate Fig.10: •Serial number (NS) •Production date...
  • Page 14 The user should switch on/ switch off the aggregate only by means of the main switch of the device, and not by means of the direct switch on thermostat control panel. Switching on the main switch shall automa- tically initiate the thermostat! User manual Luzon, Luzon Deep www.inoxbazis.hu...
  • Page 15 DED IN THIS MANUAL, THE PRODUCER SHALL RESERVE THE RIGHT TO RECEDE FROM OBLIGATIONS OF THE GUARANTOR!!! Information included in this document may be altered by “IGLOO” without noticing the user. Copying the present manual without the consent of the producer is forbidden.
  • Page 16 Inox-Bázis Kft 9090 Pannonhalma, Arany János u. Központi major Hungary e-mail: info@inoxbazis.hu Tel.: +36 1 788-1828 www.inoxbazis.hu User manual Luzon, Luzon Deep www.inoxbazis.hu...

This manual is also suitable for:

Luzon deep
