Hikmicro HM-TD2C68E-25/Q User Manual

Hikmicro HM-TD2C68E-25/Q User Manual

Thermographic automation camera
Hide thumbs

Advertisement

Quick Links

Download this manual
Thermographic Automation Camera
User Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the HM-TD2C68E-25/Q and is the answer not in the manual?

Questions and answers

Related Manuals for Hikmicro HM-TD2C68E-25/Q

Summary of Contents for Hikmicro HM-TD2C68E-25/Q

  • Page 1 Thermographic Automation Camera User Manual...
  • Page 2 WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS FOR A PARTICULAR PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT WILL HIKMICRO BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT...
  • Page 3 AND REGULATIONS BEFORE PURCHASE OR USE OF THIS PRODUCT. PLEASE NOTE THAT YOU MAY HAVE TO APPLY FOR PERMITS, CERTIFICATES, AND/OR LICENSES BEFORE ANY PURCHASING, SELLING, MARKETING AND/OR USING OF THE PRODUCT. HIKMICRO SHALL NOT BE LIABLE FOR ANY SUCH ILLEGAL OR IMPROPER PURCHASING, SELLING, MARKETING, AND END USES AND ANY SPECIAL, CONSEQUENTIAL,INCIDENTAL, OR INDIRECT DAMAGES ARISING THEREOF.
  • Page 4 Thermographic Automation Camera User Manual Symbol Conventions The symbols that may be found in this document are defined as follows. Symbol Description Indicates a hazardous situation which, if not avoided, will or Danger could result in death or serious injury. Indicates a potentially hazardous situation which, if not avoided, Caution could result in equipment damage, data loss, performance...
  • Page 5 Thermographic Automation Camera User Manual Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. Laws and Regulations In the use of the product, you must be in strict compliance with the electrical safety ●...
  • Page 6 Thermographic Automation Camera User Manual Please purchase the charger by yourself. Input voltage should meet the Limited Power ● Source (12 VDC, or 24 VAC) according to the IEC62368 standard. Please refer to technical specifications for detailed information. Make sure the plug is properly connected to the power socket. ●...
  • Page 7 Thermographic Automation Camera User Manual Never place the equipment in an unstable location. The equipment may fall, causing ● serious personal injury or death. This equipment is for use only with corresponding brackets. Use with other (carts, ● stands, or carriers) may result in instability causing injury. The interface varies with the models.
  • Page 8 Thermographic Automation Camera User Manual For the device with ventilation openings, the ventilation openings should not be impeded ● by covering the ventilation openings with items, such as newspapers, table-cloths, and curtains. The openings shall never be blocked by placing the device on a bed, sofa, rug, or other similar surface.
  • Page 9 Thermographic Automation Camera User Manual Contents Chapter 1 Device Activation and Accessing ................1 1.1 Activate the Device via HIKMICRO Studio ..............1 1.2 Activate the Device via Browser ................... 1 1.3 Login ..........................2 1.3.1 Plug-in Installation ....................2 1.3.2 Illegal Login Lock ....................
  • Page 10 Thermographic Automation Camera User Manual 3.1.4 Bitrate Type and Max. Bitrate ................10 3.1.5 Video Quality ....................... 11 3.1.6 Frame Rate ......................11 3.1.7 Video Encoding ....................11 3.1.8 Smoothing ......................12 3.1.9 Display VCA Info ....................12 3.1.10 Set ROI ....................... 13 3.2 Display Settings ......................
  • Page 11 Thermographic Automation Camera User Manual 4.1.3 Set Disk ........................ 21 4.1.4 Set Cloud Storage ....................22 4.2 Video Recording ......................22 4.2.1 Record Automatically ..................22 4.2.2 Record Manually ....................24 4.2.3 Playback and Download Video ................24 4.3 Capture Configuration ....................25 4.3.1 Capture Automatically ..................
  • Page 12 Thermographic Automation Camera User Manual 6.7 Module Order ....................... 43 Chapter 7 Arming Schedule and Alarm Linkage ..............45 7.1 Set Arming Schedule ....................45 7.2 Linkage Method Settings .................... 45 7.2.1 Send Email ......................46 7.2.2 Notify Surveillance Center .................. 47 7.2.3 FTP/NAS Uploading ....................
  • Page 13 Thermographic Automation Camera User Manual 8.11.3 Modbus Error Code Description ..............59 8.12 Port Mapping ......................61 8.12.1 Set Auto Port Mapping ..................62 8.12.2 Set Manual Port Mapping ................62 8.13 Set OTAP ........................62 8.14 Set ISUP ........................63 8.15 Access Camera via Hik-Connect ................
  • Page 14 Thermographic Automation Camera User Manual 9.3.5 Search and Manage Log ..................72 9.3.6 Search Security Audit Logs ................72 9.3.7 SSH ........................73 9.3.8 Export Diagnose Information ................73 9.4 Security ......................... 73 9.4.1 Set IP Address Filter ................... 73 9.4.2 Set MAC Address Filter ..................
  • Page 15 7. Optional: Change the network parameters of the device in Modify Netinfo. Note For detailed operation, please refer to the user manual of HIKMICRO Studio . 1.2 Activate the Device via Browser You can access and activate the device via the browser.
  • Page 16 Thermographic Automation Camera User Manual Steps 1. Connect the device to the PC using the network cables. 2. Change the IP address of the PC and device to the same segment. Note The default IP address of the device is 192.168.1.64. You can set the IP address of the PC from 192.168.1.2 to 192.168.1.253 (except 192.168.1.64).
  • Page 17 Thermographic Automation Camera User Manual Operating System Web Browser Operation Windows 7/8/10/11 Google Chrome 91 and Click to download and ● higher install plug-in. Mozilla Firefox 88 and ● higher Microsoft Edge 91 and ● higher Mac OS 10.13 and higher Google Chrome 91 and Plug-in installation is not ●...
  • Page 18 Thermographic Automation Camera User Manual The device releases the lock after the setting duration.
  • Page 19 Thermographic Automation Camera User Manual Chapter 2 Live View It introduces the live view parameters, function icons and transmission parameters settings. 2.1 Live View Parameters The supported functions vary depending on the model. 2.1.1 Start and Stop Live View Click Live View. Click to start live view.
  • Page 20 Thermographic Automation Camera User Manual 2.1.6 Select the Third-Party Plug-in When the live view cannot display via certain browsers, you can change the plug-in for live view according to the browser. Steps 1. Click Live View. 2. Click to select the plug-in. - When you access the device via Internet Explorer, you can select Webcomponents or QuickTime.
  • Page 21 Thermographic Automation Camera User Manual Note Supported PTZ functions may vary according to different camera models. ● For the devices which support lens movements only, the direction buttons are invalid. ● Direction Control Click and hold the direction button to pan/tilt the device. Zoom Click , and the lens zooms in.
  • Page 22 Thermographic Automation Camera User Manual TCP ensures complete delivery of streaming data and better video quality, yet the real-time transmission will be affected. It is suitable for the stable network environment. UDP is suitable for the unstable network environment that does not demand high video fluency.
  • Page 23 Thermographic Automation Camera User Manual Rules Display rule info. in live view, such as the rule area of motion detection event and VCA resources. Display POS Info Display target ID and attributes in main stream recordings. The attribute type depends on the model and function of different device, and the actual device prevails.
  • Page 24 Thermographic Automation Camera User Manual Chapter 3 Video and Image Settings This part introduces the configuration of video/audio and image related parameters. 3.1 Video Settings This part introduces the settings of video parameters, such as, stream type, video encoding, and resolution. Go to setting page: Configuration >...
  • Page 25 Thermographic Automation Camera User Manual It means that the stream is compressed and transmitted at a comparatively fixed bitrate. The compression speed is fast, but mosaic may occur on the image. Variable Bitrate It means that the device automatically adjust the bitrate under the set Max. Bitrate. The compression speed is slower than that of the constant bitrate.
  • Page 26 Thermographic Automation Camera User Manual Profile This function means that under the same bitrate, the more complex the profile is, the higher the quality of the image is, and the requirement for network bandwidth is also higher. I-Frame Interval I-frame interval defines the number of frames between 2 I-frames. In H.264 and H.265, an I-frame, or intra frame, is a self-contained frame that can be independently decoded without any reference to other images.
  • Page 27 Thermographic Automation Camera User Manual Player means the VCA info can be displayed by the dedicated player provided by the manufacturer. Video Video means the VCA info can be displayed by any general video player. 3.1.10 Set ROI ROI (Region of Interest) encoding helps to assign more encoding resource to the region of interest, thus to increase the quality of the ROI whereas the background information is less focused.
  • Page 28 Thermographic Automation Camera User Manual 3.2.2 Image Adjustment (Thermal Channel) You can optimize the image display effect of thermal channel by setting background correction and manual correction. Background Correction Fully cover the lens with an object of uniform temperature in front of the lens, such as foam board or paperboard.
  • Page 29 Thermographic Automation Camera User Manual This mode is suitable for detecting small, high-temperature faults in a low- temperature background, e.g., electrical components such as wiring, contacts, etc., which can be used to highlight more fine details of the target. 3.2.3 DNR Digital Noise Reduction is used to reduce the image noise and improve the image quality.
  • Page 30 Thermographic Automation Camera User Manual Between When the target of an interval temperature needs to be colored, you can set the interval temperature color. Target between the minimum and the maximum temperatures will be displayed in setting color. Below When the target of low temperature needs to be colored, you can set the low temperature color.
  • Page 31 Thermographic Automation Camera User Manual 3.2.8 Mirror When the live view image is the reverse of the actual scene, this function helps to display the image normally. Select the mirror mode as needed. Note The video recording will be shortly interrupted when the function is enabled. 3.2.9 Digital Zoom You can zoom in the image.
  • Page 32 Thermographic Automation Camera User Manual Text Overlay Set customized overlay text on image. 3.4 Set Privacy Mask The function blocks certain areas in the live view to protect privacy. No matter how the device moves, the blocked scene will never be seen. Steps 1.
  • Page 33 Thermographic Automation Camera User Manual 3.7 Set Manual DPC (Defective Pixel Correction) If the amount of defective pixels in the image is comparatively small and accurate correction is needed, you can correct these pixels manually. Steps 1. Go to Configuration > Image > DPC . 2.
  • Page 34 Thermographic Automation Camera User Manual Chapter 4 Video Recording and Picture Capture This part introduces the operations of capturing video clips and snapshots, playback, and downloading captured files. 4.1 Storage Settings This part introduces the configuration of several common storage paths. 4.1.1 Set FTP You can configure the FTP server to save images which are captured by events or a timed snapshot task.
  • Page 35 Thermographic Automation Camera User Manual Steps 1. Go to NAS setting page: Configuration > Storage > Storage Management > Net HDD . 2. Click Add. 3. Set Mounting Type. Mounting Type Select file system protocol according to the operation system. Enter user name and password of the net HDD to guarantee the security if SMB/CIFS is selected.
  • Page 36 Thermographic Automation Camera User Manual 4.1.4 Set Cloud Storage It helps to upload the captured pictures and data to the cloud. The platform requests picture directly from the cloud for picture and analysis. The function is only supported by certain models. Steps Caution If the cloud storage is enabled, the pictures are stored in the cloud video manager firstly.
  • Page 37 Thermographic Automation Camera User Manual Before You Start Select Trigger Recording in event settings for each record type except Continuous. See Event and Alarm for details. Steps 1. Go to Configuration > Storage > Schedule Settings > Record Schedule . 2.
  • Page 38 Thermographic Automation Camera User Manual 5. Set the advanced recording parameters. Overwrite Enable Overwrite to overwrite the video records when the storage space is full. Otherwise the camera cannot record new videos. Pre-record The time period you set to record before the scheduled time. Record Delay The time period you set to stop recording after the scheduled time.
  • Page 39 Thermographic Automation Camera User Manual 4. Optional: Click to clip video files. Click again to stop clipping video files Note Go to Configuration > Local > Clip Saving Path , view and change the saving path of clipped video files. 5.
  • Page 40 Thermographic Automation Camera User Manual Note The resolution of the captured picture is the same as the resolution of the captured picture stream. You can select Stream Type in Advanced. 5. Click Save. 4.3.2 Capture Manually Steps 1. Go to Configuration > Local . 2.
  • Page 41 Thermographic Automation Camera User Manual Chapter 5 Temperature Measurement When you enable this function, the device measures the actual temperature of the scene. It alarms when temperature exceeds the temperature threshold value. Note The function varies according to different camera models. 5.1 Set Thermography Parameters Configure the parameters of temperature measurement.
  • Page 42 Thermographic Automation Camera User Manual Display Temperature Info. on Stream Check to display temperature information on the stream. Display Max./Min./Average Temperature Check to display maximum/minimum/average temperature information on liveview when the temperature measurement rule is line or area. Display Position Select the position of temperature information showed on the live view.
  • Page 43 Thermographic Automation Camera User Manual Note The settings vary according to different camera models. 4. Click Save. 5.2 Automatic Thermography Configure the temperature measurement parameters and temperature measurement rules. The device can measure the actual temperature and output alarms when temperature exceeds the alarm threshold value.
  • Page 44 Thermographic Automation Camera User Manual Set Temperature Measurement Alarm in Normal Mode In temperature measurement alarm mode, the device outputs alarm if the detected temperature is higher than the threshold value. Before You Start Select Alarm Mode as Temperature Measurement Alarm first in Basic Parameter. Steps 1.
  • Page 45 Thermographic Automation Camera User Manual Note In normal mode, the device measures temperature of the full screen. In expert mode, the device measures the temperature of thermography rules. 3. Check Alarm Area Rule, and click Set to configure the alarm rule parameters. 4.
  • Page 46 Thermographic Automation Camera User Manual Note Go to Configuration > Image > VCA Rules Display to adjust the font size and the temperature color of normal, alarm and pre-alarm. Set Thermography Rule Steps 1. Customize the rule name. 2. Select the rule type to Point, Line, or Area. Then draw a point, line, or area on the interface where the position to be measured.
  • Page 47 Thermographic Automation Camera User Manual Point Thermography Configure the temperature measurement rule and click any point in live view to monitor the temperature. Steps 1. Click in the live view and a cross cursor shows on the interface. 2. Drag the cross cursor to desired position. Go to Live View interface to view the temperature and rule of the point in thermal channel.
  • Page 48 Thermographic Automation Camera User Manual Steps 1. Set the parameters. Alarm Temperature and Pre-Alarm Temperature Set the alarm temperature and pre-alarm temperature. E.g., select Alarm Rule as Above (Average Temperature), set the Pre-Alarm Temperature to 50 °C, and set the Alarm Temperature to 55 °C.
  • Page 49 Thermographic Automation Camera User Manual 2. Select an Alarm Type. Note In normal mode, the device measures temperature of the full screen. In expert mode, the device measures the temperature of thermography rules. 3. Check Alarm Area Rule, and click Set to configure the alarm rule parameters. 4.
  • Page 50 Thermographic Automation Camera User Manual 5.4.1 Pixel-to-Pixel Thermometry Users can configure general thermometry and data upload parameters to obtain pixel-to- pixel thermometry data, thermometry rule information, and pictures. This function can be used for secondary integration. Steps 1. Go to Event Center > Temperature Measurement > Integration > Pixel-to-Pixel Thermometry .
  • Page 51 Thermographic Automation Camera User Manual Note The parameters above such as Emissivity, Distance, Reflective Temperature, etc. are only applied in integration, which will not affect the configuration in thermometry parameters and rules. 3. Click Save. 5.4.2 Integration Calibration Integration calibration can improve temperature measurement accuracy. You can configure integration calibration via external optical calibration and temperature rise calibration, depending on whether the integrated device has germanium window.
  • Page 52 Thermographic Automation Camera User Manual Calibration Type Calibration Method 3. Click Import and Enable. 4. Optional. Click Export to export the calibration file of the current device mode to apply it to devices used in the same scenarios. 5. Click Save to save the settings. Note Temperature rise calibration is supported only during the first 30 minutes after the device is powered on.
  • Page 53 Thermographic Automation Camera User Manual Note Add Original Data on Capture and Display Radiometric Info. on Capture cannot be ● enabled simultaneously. When both the two functions are enabled, only the function enabled later takes effect. You can go to Event Center > Temperature Measurement > Temperature Measurement ●...
  • Page 54 Thermographic Automation Camera User Manual Chapter 6 Event and Alarm This part introduces the configuration of events. The device takes certain response to triggered alarm. Certain events may not be supported by certain device models. 6.1 Set Motion Detection It helps to detect the moving objects in the detection region and trigger the linkage actions. Steps 1.
  • Page 55 Thermographic Automation Camera User Manual 2. Check Enable. 3. Set the Sensitivity. The higher the value is, the easier to detect the area covering. 4. Click and drag the mouse in the live view to draw the area. Figure 6-1 Set Video Tampering Area 5.
  • Page 56 Thermographic Automation Camera User Manual Before You Start Note This function is only supported by certain models. Quick Start Guide for cable Make sure the external alarm device is connected. See connection. Steps 1. Go to Event Center > Basic Event > Alarm Input . 2.
  • Page 57 Thermographic Automation Camera User Manual Steps 1. Go to Event Center > Basic Event > Burning-Prevention . 2. Check Enable. 3. Select burning-prevention mode. Auto The shutter will be closed automatically when detecting high temperature target. You can set the protection duration. The shutter is closed in the duration. Manual You can set the shutter status to open or closed as desired.
  • Page 58 Thermographic Automation Camera User Manual You can select configured HTTP orders as the linkage method of smart events including Alarm Input, Perimeter Protection, and Temperature Measurement. The alarm or pre- alarm information will upload to the selected HTTP server. Note HTTP order linkage is only supported when you check Enable.
  • Page 59 Thermographic Automation Camera User Manual Chapter 7 Arming Schedule and Alarm Linkage Arming schedule is a customized time period in which the device performs certain tasks. Alarm linkage is the response to the detected certain incident or target during the scheduled time.
  • Page 60 Thermographic Automation Camera User Manual 7.2.1 Send Email Check Send Email, and the device sends an email to the designated addresses with alarm information when an alarm event is detected. Set Email . For email settings, refer to Set Email When the email is configured and Send Email is enabled as a linkage method, the device sends an email notification to all designated recipients if an alarm event is detected.
  • Page 61 Thermographic Automation Camera User Manual 7.2.2 Notify Surveillance Center Check Notify Surveillance Center, the alarm information is uploaded to the surveillance center when an alarm event is detected. 7.2.3 FTP/NAS Uploading If you have enabled and configured the FTP/NAS uploading, the device sends the alarm information to the FTP server, network attached storage when an alarm is triggered.
  • Page 62 Thermographic Automation Camera User Manual Automatic Alarm Set the automatic alarm parameters, then the device triggers an alarm output automatically in the set arming schedule. Before You Start Make sure the alarm output device is connected to the device. Steps 1.
  • Page 63 Thermographic Automation Camera User Manual 7.2.6 Alarm Server The device can send alarms to destination IP address or host name through HTTP, HTTPS, or ISUP protocol. The destination IP address or host name should support HTTP, HTTP, or ISUP data transmission. Set Alarm Server Steps 1.
  • Page 64 Thermographic Automation Camera User Manual 5. Optional: Select the added device, click Modify to edit the device information, or click Delete to delete it from the list. 6. Click to add alarm input and output rules.
  • Page 65 Thermographic Automation Camera User Manual Chapter 8 Network Settings 8.1 TCP/IP TCP/IP settings must be properly configured before you operate the device over network. IPv4 and IPv6 are both supported. Both versions can be configured simultaneously without conflicting to each other. Go to Configuration >...
  • Page 66 Thermographic Automation Camera User Manual Input IPv6 Address, IPv6 Subnet, IPv6 Default Gateway. Consult the network administrator for required information. It stands for maximum transmission unit. It is the size of the largest protocol data unit that can be communicated in a single network layer transaction. The valid value range of MTU is 1280 to 1500.
  • Page 67 Thermographic Automation Camera User Manual Steps TCP/IP to set DNS parameters. 1. Refer to 2. Go to the DDNS settings page: Configuration > Network > Network Settings > DDNS . 3. Check Enable and select DDNS Type. DynDNS Dynamic DNS server is used for domain name resolution. NO-IP NO-IP server is used for domain name resolution.
  • Page 68 Thermographic Automation Camera User Manual By Client Add the WAN dynamic IP address to the client software. Refer to Software the client manual for details. Note The obtained IP address is dynamically assigned via PPPoE, so the IP address always changes after rebooting the camera.
  • Page 69 Thermographic Automation Camera User Manual 8.6 Set QoS QoS (Quality of Service) can help improve the network delay and network congestion by setting the priority of data sending. Note QoS needs support from network device such as router and switch. Steps 1.
  • Page 70 Thermographic Automation Camera User Manual Digest and digest/basic are supported, which means authentication information is needed when WEB request is sent to the device. If you select digest/basic, it means the device supports digest or basic authentication. If you select digest, the device only supports digest authentication.
  • Page 71 Thermographic Automation Camera User Manual Go to Configuration > Network > Network Service > Bonjour to enable the function, and click Save. After enabling the function, the device spread and receive service information in local area network. 8.10 WebSocket(s) WebSocket or WebSockets protocol should be enabled if you use Google Chrome 57 and its above version or Mozilla Firefox 52 and its above version to visit the device.
  • Page 72 Thermographic Automation Camera User Manual Subordinate Name Customized subordinate for distinguishing between different subordinates. Connection type Note Only when Configuration > System > System Settings > RS-485 is selected as main mode, the RS-485 connection type can be supported. When connecting the device and the subordinate via the RJ45 interface, the TCP connection type can be selected.
  • Page 73 Thermographic Automation Camera User Manual Note In a single subordinate configuration, all register addresses cannot be duplicated or conflicted. 5)Click OK. 7. Click Save. 8.11.2 Set Modbus Subordinate Mode Configure the device as the subordinate server, the main can read the temperature measurement data of the device or write the temperature measurement parameters of the device.
  • Page 74 Thermographic Automation Camera User Manual Table 8-1 Modbus Error Code Description Error Name Description Code Illegal Function The function code received in the query is not an allowable action for the server. This may be because the function code is only applicable to newer devices, and was not implemented in the unit selected.
  • Page 75 Thermographic Automation Camera User Manual Error Name Description Code Acknowledge Specialized use in conjunction with programming commands. The server has accepted the request and is processing it, but a long duration of time will be required to do so. This response is returned to prevent a timeout error from occurring in the client.
  • Page 76 Thermographic Automation Camera User Manual Set Auto Port Mapping for detailed information. Auto Port Mapping Refer to Set Manual Port Mapping for detailed information. Manual Port Mapping Refer to 3. Click Save. 8.12.1 Set Auto Port Mapping Steps 1. Check Enable UPnP™, and choose a friendly name for the camera, or you can use the default name.
  • Page 77 Thermographic Automation Camera User Manual 8.14 Set ISUP When the device is registered on ISUP platform (formerly called Ehome), you can visit and manage the device, transmit data, and forward alarm information over public network. Steps 1. Go to Configuration > Network > Platform Access > ISUP . 2.
  • Page 78 The verification code is required when you add the camera to Hik-Connect service. 6. Save the settings. Enable Hik-Connect Service via HIKMICRO Studio Software This part introduce how to enable Hik-Connect service via HIKMICRO Studio software of an activated camera. Steps 1.
  • Page 79 Thermographic Automation Camera User Manual 8.15.3 Add Camera to Hik-Connect Steps 1. Connect your mobile device to a Wi-Fi. 2. Log into the Hik-Connect app. 3. In the home page, tap "+" on the upper-right corner to add a camera. Quick Start Guide cover.
  • Page 80 Thermographic Automation Camera User Manual - If you select Digest&ws-username token, the device supports digest authentication or ws-username token authentication. 4. Click Add to configure the Open Network Video Interface user. 5. Click Save. 6. Optional: Repeat the steps above to add more Open Network Video Interface users. 7.
  • Page 81 Thermographic Automation Camera User Manual Chapter 9 System and Security It introduces system maintenance, system settings and security management, and explains how to configure relevant parameters. 9.1 System Settings 9.1.1 View Device Information You can view device information, such as Device No., Model, Serial No. and Firmware Version.
  • Page 82 Thermographic Automation Camera User Manual Steps 1. Go to Configuration > System > System Settings > Time Settings . 2. Select Time Zone. 3. Click NTP. 4. Set Server Address, NTP Port and Interval. Note Server Address is NTP server IP address. 5.
  • Page 83 Thermographic Automation Camera User Manual Before You Start Connect the device and computer or terminal with RS-485 cable. Steps 1. Go to Configuration > System > System Settings > RS-485 . 2. Set the RS-485 parameters. Device Mode The main mode allows the device to actively upload data to subordinate. In subordinate mode, device responses the request from the main.
  • Page 84 Thermographic Automation Camera User Manual Caution To increase security of using the device on the network, please change the password of your account regularly. Changing the password every 3 months is recommended. If the device is used in high-risk environment, it is recommended that the password should be changed every month or week.
  • Page 85 Thermographic Automation Camera User Manual 9.3 Maintenance 9.3.1 Restart You can restart the device via browser. Go to Maintenance and Security > Maintenance > Restart , and click Restart. 9.3.2 Upgrade Before You Start You need to obtain the correct upgrade package. Caution DO NOT disconnect power during the process, and the device restarts automatically after upgrade.
  • Page 86 Thermographic Automation Camera User Manual 9.3.4 Import and Export Configuration File It helps speed up batch configuration on other devices with the same parameters. Steps 1. Export configuration file. 1)Go to Maintenance and Security > Maintenance > Backup and Restore > Backup . 2)Click Export and input the encryption password to export the current configuration file.
  • Page 87 Thermographic Automation Camera User Manual 9.3.7 SSH Secure Shell (SSH) is a cryptographic network protocol for operating network services over an unsecured network. Go to Maintenance and Security > Maintenance > Device Debugging , and click Settings of SSH. You can edit the number of the port. Click Save. Caution Use the function with caution.
  • Page 88 Thermographic Automation Camera User Manual 5. Click Save. 9.4.2 Set MAC Address Filter MAC address filter is a tool for access control. You can enable the MAC address filter to allow or forbid the visits from the certain MAC addresses. Steps 1.
  • Page 89 Thermographic Automation Camera User Manual Server Certificate/Client Certificate Note The device has default self-signed server/client certificate installed. The certificate ID is default . Create and Install Self-signed Certificate Steps 1. Go to Maintenance and Security > Security > Certificate Management . 2.
  • Page 90 Thermographic Automation Camera User Manual 2)Input Certificate ID. Note The input certificate ID cannot be the same as the existed ones. 3)Click to select the certificate file. 4)Select Self-signed Request Certificate. 5)Click Save. The imported certificate is displayed in the Server/Client Certificate list. If the certificate is used by certain function, the function name is shown in the column Functions.
  • Page 91 Thermographic Automation Camera User Manual Steps 1. Go to Maintenance and Security > Security > Certificate Management . 2. Click Import in the CA Certificate list. 3. Input Certificate ID. Note The input certificate ID cannot be the same as the existing ones. 4.
  • Page 92 Thermographic Automation Camera User Manual Caution Use the function with caution. The security risk of device internal information leakage exists when the function is enabled.
  • Page 93 Thermographic Automation Camera User Manual Chapter 10 Appendix 10.1 Common Material Emissivity Reference Material Emissivity Human Skin 0.98 Printed Circuit Board 0.91 Concrete 0.95 Ceramic 0.92 Rubber 0.95 Paint 0.93 Wood 0.85 Pitch 0.96 Brick 0.95 Sand 0.90 Soil 0.92 Cloth 0.98 Hard Paperboard...
  • Page 94 UD39953B...
