- Page 1 Courtesy of: DiscountCarStereo.com Serving the internet community since 1995 BTH-BKRCD HANDS FREE, MUSIC STREAMING INSTALLATION GUIDE FOR BECKER RADIOS AND SEPARATE CD CHANGER...
- Page 2 Introduction Safety comes first when you’re on the road, so having an intuitive and easy to use Bluetooth kit is essential to reducing driver distraction. The BTH-BKRCD (formerly A2DIY-BKRCD) works with virtually all Bluetooth enabled phones and sounds great whether using for mobile conversations, streaming music and retaining use of required CD changer.
- Page 3 5. Connect BLUE plug from install harness (See Fig. 4) to radio (C-3) chamber vacated in step 3. 6. Disconnect 8-pin black plug (A) from radio (See Fig. 5) and connect to install harness matting 8-pin connector (See Fig. 6) Fig.
- Page 4 BMW and Mercedes solid 16-pin plug Warning: BMW and Mercedes have a solid (molded) 16-pin speaker/power (A/B) plug. For these applications harness seen in Fig. 6a is included. Disconnect factory 16-pin (solid plug) from radio (See Fig. 5) and connect to matting 16-pin connector on harness (See Fig. 6a) 2.
- Page 5 Optional USB extension cable installation Please note: Optional USB dash mount extension cable is not required for operation; however, it extends USB charging port (See Fig. 11) to dashboard, USB port supports software updated and charging only glovebox etc. and Drill a ¾”...
- Page 6 Wireless remote control Bluetooth pairing Use included wireless remote control to track up/down, answer/reject calls, Pairing varies among devices but basic steps are the same. This process is done adjust device volume all while keeping eyes on the road. upon initial install and will not have to be repeated. Installation: Turn ignition and radio “ON”...
- Page 7 Congratulations, you’ve just updated your vehicle to support new technology while preserving the original radio and dash components. Enjoy! The BTH-BKRCD works in vehicles with analog radios/CD changers. Newer vehicles with fiber optic digital systems (e.g., CR23/24, PCM2+) as seen in Fig. 16 are NOT supported.
- Page 8 Frequent ask questions & Troubleshooting Do I require a working CD changer for the BTH-BKRCD to work? YES; CD changer is required and remain fully functional. At least one disc must remain in changer magazine. 2. Does the BTH-BKRCD work on all Becker radios? Works on Becker analog radios with analog radios/CD changers.
