Schwinn AirDyne AD Pro Troubleshooting Manual

3/11/24, 3:27 PM
Schwinn AirDyne AD Pro: Why is there no power to my machine?
Follow this troubleshooting guide to help resolve power issues on the Schwinn AirDyne AD Pro.
Some common complaints may include:
Console will not turn on
Machine will not turn on
Console turns on partially
Console turns off or goes to sleep during use
Using Power Cord to Power Bike
Tools you may need:
Phillips head screwdriver
6mm hex/Allen wrench, or the wrench that came from the
hardware card included with your machine
Voltmeter
1.
If you are using batteries to power your console, please
my battery powered
2.
Test the wall power outlet with another device, such as a lamp, to ensure it is working. If the outlet is not working
properly, test your bike again using another outlet [13136.A].
3.
If the issue persists, unplug the power cord from your bike and the wall. Inspect the power adapter for damage. Check
the cord for damage, such as crimps, cuts, or exposed wires. Check the adapter end for bends or breaks in the tip/pin.
If undamaged, plug the cord into your machine and the wall, making sure both ends are securely connected. Test to
see if the issue persists [13136.B]. If damage is present,
4.
If the issue persists, test the voltage of your power adapter using a voltmeter. Set voltmeter to 20 VDC. Insert the red
lead into the tip of the power adapter and touch the outside of the metal barrel with the black lead (reference 1). The
voltage reading should be between 9V and 14V. If the voltage is outside of this range,
Adapter [13136.D].
about:blank
Schwinn AirDyne AD Pro:  Why is there no power to my machine?
console? to troubleshoot power issues.
visit AirDyne AD7, AD8, AD Pro: Why is there no power to
order a Power Adapter [13136.C].
(Reference 1)
ID: 13136.1
order a Power
