Summary of Contents for Zanussi ZCK66350WA
- Page 1 User Manual GETTING STARTED? EASY. ZCK66350BA ZCK66350WA ZCK66350XA EN User Manual Cooker...
- Page 2 VISIT OUR WEBSITE TO: Get usage advice, brochures, trouble shooter, service and repair information: www.zanussi.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................5 3. INSTALLATION....................8 4. PRODUCT DESCRIPTION................11 5. BEFORE FIRST USE..................12 6. HOB - DAILY USE..................13 7.
- Page 3 be kept away from the appliance unless continuously supervised. • Children should be supervised to ensure that they do not play with the appliance. • Keep all packaging away from children and dispose of it appropriately. • WARNING: The appliance and its accessible parts become hot during use.
- Page 4 • Never use water to extinguish the cooking fire. Switch off the appliance and cover flames with e.g. a fire blanket or lid. • CAUTION: The cooking process has to be supervised. A short term cooking process has to be supervised continuously.
- Page 5 2. SAFETY INSTRUCTIONS electrical ratings of the mains power This appliance is suitable for the following supply. markets: GB • Always use a correctly installed shockproof socket. 2.1 Installation • Do not use multi-plug adapters and extension cables. • Do not let mains cables touch or come WARNING! near the appliance door or the niche below Only a qualified person must install this...
- Page 6 regulations. Follow the requirements for • Used oil, that can contain food remnants, adequate ventilation. can cause fire at a lower temperature than oil used for the first time. 2.4 Use • Do not put flammable products or items that are wet with flammable products in, near or on the appliance.
- Page 7 • Make sure the flame does not go out when • Before you close the lid turn all burners you quickly turn the knob from the off. maximum to the minimum position. • Do not close the lid until the hob and oven •...
- Page 8 • Remove the door catch to prevent children • Flat the external gas pipes. or pets from becoming trapped in the appliance. 3. INSTALLATION 3.3 Levelling of the appliance WARNING! Refer to Safety chapters. 3.1 Technical data Dimensions Height 894 - 912 mm Width 600 mm Depth...
- Page 9 3.5 Other technical data Gas category: WARNING! Gas supply: G20 (2H) 20 mbar These instructions are only valid in the Voltage: 220-240 V countries whose symbols appear on this booklet's cover. Frequency: 50 Hz 3.6 Gas burners BURNER NORMAL POWER Natural Gas INJECTOR MARK 1/100 mm Btu/h...
- Page 10 to the hob burners, when you turn the WARNING! knob on. The gas bayonet connector must be in 3.11 Electrical installation the marked area. WARNING! Dimension The manufacturer is not responsible if you do not follow the safety precautions from Safety chapters. This appliance is supplied without a main plug or a main cable.
- Page 11 before you fix the two screws into the top Make sure that the links are fitted as shown. edge of the mains terminal cover. • Make sure that the cover is securely fastened. To open the cover of terminal board obey the procedure in opposite sequence.
- Page 12 4.2 Hob overview Steam outlet - number and position depend on the model Semi-rapid burner Auxiliary burner Rapid burner Semi-rapid burner 4.3 Cooker control panel Knob for the top oven Knobs for the hob Display Knob for the main oven Temperature indicator for the main oven Temperature indicator for the top oven 4.4 Accessories...
- Page 13 After approximately five seconds, the flashing stops and the display shows the time of day you set. Preheat the two ovens. Heat up one oven at a time. 5.3 Changing the time 1. Set the maximum temperature. 2. Let the appliance operate for 1 hour. 3.
- Page 14 6.2 Burner overview A. Burner cap B. Burner crown C. Ignition candle D. Thermocouple 6.3 Replacing burner parts WARNING! 1. Put carefully the burner crown on the Always turn the flame down or switch it burner body. Let the crown fall freely onto off before you remove the pans from the the body.
- Page 15 WARNING! Do not put the same pan on two burners. WARNING! Do not put unstable or damaged pots on the burner to prevent spills and injuries. CAUTION! 7.2 Diameters of cookware Make sure that pot handles are not WARNING! above the front edge of the cooktop. Use cookware with diameters applicable CAUTION! to the size of burners.
- Page 16 8.4 Cleaning the spark plug these components well clean to prevent difficult lighting and check that the burner This feature is obtained through a ceramic crown holes are not obstructed. ignition candle with a metal electrode. Keep 9. OVEN - DAILY USE WARNING! Refer to Safety chapters.
- Page 17 9.3 Activating and deactivating the top / main oven It depends on the model if your appliance has knob symbols, indicators or lamps: • The indicator comes on when the oven heats up. • The lamp comes on when the oven operates.
- Page 18 2. Put the deep pan into the oven on the necessary shelf position. 10. OVEN - CLOCK FUNCTIONS 10.1 Display A. Clock functions B. Timer The display works only with the main oven. 10.2 Buttons Button Function Description MINUS To set the time. CLOCK To set a clock function.
- Page 19 Clock function Application MINUTE MINDER To set a countdown. This function has no effect on the operation of the oven. You can set this function at any time, also when the oven is off. 10.4 Setting the DURATION 2. Press to set the necessary time.
- Page 20 Trays in the oven can distort during baking. When the trays are cold again, the distortions disappear. 11.4 Tips on baking Baking results Possible cause Remedy The bottom of the cake is not The shelf position is incorrect. Put the cake on a lower shelf. baked sufficiently.
- Page 21 Food Temperature (°C) Time (min) Shelf position Fruit Pies, Crumbles 190 - 200 30 - 50 Milk Puddings 150 - 170 90 - 120 Pasta Lasagne etc. 170 - 180 40 - 50 Pastry: Choux 180 - 190 30 - 40 Pastry: Eclairs, Profiteroles 180 - 190 30 - 40...
- Page 22 Food Temperature (°C) Time (min) Shelf posi‐ tion Cakes: Apple Pie 160 - 170 50 - 60 - Shortbread 130 - 150 45 - 60 1 – 3 Fish 160 - 180 30 - 40 Fruit Pies, Crumbles 170 - 180 30 - 50 Milk Puddings 140 - 160...
- Page 23 11.9 Grilling in general • Grill only flat pieces of meat or fish. WARNING! Always grill with the oven door closed. • Always grill with the maximum temperature setting. • Set the shelf into the shelf position as The grilling area is set in centre of the shelf. recommended in the grilling table.
- Page 24 Food Function Tempera‐ Time (min) Accesso‐ Shelf po‐ ture (°C) ries sition Small cakes (20 small Thermaflow® 25 - 35 Tray cakes per tray) Small cakes (20 small Thermaflow® 25 - 35 Tray 1 / 4 cakes per tray) Apple pie, 2 tins (ø 20 cm) Conventional Cooking 80 - 100 Grid...
- Page 25 12. OVEN - CARE AND CLEANING WARNING! Refer to Safety chapters. 12.1 Notes on cleaning Clean the front of the appliance only with a microfibre cloth with warm water and a mild de‐ tergent. Use a cleaning solution to clean metal surfaces. Clean stains with a mild detergent.
- Page 26 12.3 Cleaning the top oven 12.6 Removing and cleaning the door glasses - top oven 1. Clean the oven floor with warm water and washing-up liquid, then dry it. 2. Set the oven temperature to 250 °C and let the oven operate for 1 hour. The door glass in your product can be 3.
- Page 27 12.8 Replacing the lamp WARNING! Risk of electric shock. The lamp can be hot. 1. Turn off the oven. Wait until the oven is cold. 2. Disconnect the oven from the mains. 3. Put a cloth on the bottom of the cavity. The back lamp The lamp glass cover is at the back of the cavity.
- Page 28 ......... 14. ENERGY EFFICIENCY 14.1 Product Information according to EU and UK Ecodesign Regulations for hob Model identification ZCK66350BA ZCK66350WA ZCK66350XA Type of hob Hob inside Freestanding Cooker Number of gas burners Energy efficiency per gas burner (EE Left Front - Rapid 55.0 %...
- Page 29 14.3 Product Information and Product Information Sheet according to EU and UK Ecodesign and Energy Labelling Regulations for ovens Supplier's name Zanussi ZCK66350BA 948905169 Model identification ZCK66350WA 948905168 ZCK66350XA 948905170 Top oven: 105.6 Energy Efficiency Index Main oven: 95.4 Top oven: A...
- Page 30 14.4 Oven - Energy saving Cooking with fan When possible, use the cooking functions with fan to save energy. Residual heat The appliance has features which help When the cooking duration is longer than 30 you save energy during everyday min, reduce the appliance temperature to cooking.
- Page 32 WWW.ZANUSSI.COM/SHOP...
