- Page 1 User Manual GETTING STARTED? EASY. ZCK552J1WA EN User Manual Cooker...
-
Page 2: Safety Information
VISIT OUR WEBSITE TO: Get usage advice, brochures, trouble shooter, service and repair information: www.zanussi.com/support SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damage that are the result of incorrect installation or usage. - Page 3 accommodation where such use does not exceed (average) domestic usage levels. Only a qualified person must install this appliance and replace • the cable. This appliance is intended for use up to an altitude of 2000 m • above sea level. This appliance is not intended to be used on ships, boats or •...
-
Page 4: Safety Instructions
If the mains power supply cable is damaged, it must be • replaced by the manufacturer, its Authorised Service Centre or similarly qualified persons to avoid an electrical hazard. WARNING: Use only hob guards designed by the • manufacturer of the cooking appliance or indicated by the manufacturer of the appliance in the instructions for use as suitable or hob guards incorporated in the appliance. - Page 5 • Make sure that there is air circulation around the • Used oil, that can contain food remnants, can appliance. cause fire at a lower temperature than oil used • The information about the gas supply is on the for the first time. rating plate.
-
Page 6: Internal Lighting
CARE AND CLEANING are intended to withstand extreme physical conditions in household appliances, such as WARNING! Risk of injury, fire, or temperature, vibration, humidity, or are intended damage to the appliance. to signal information about the operational status of the appliance. They are not intended to •... - Page 7 Minimum distances Frequency 50 - 60 Hz Appliance class Dimension Dimension Height Width TECHNICAL DATA Depth Voltage 230 V OTHER TECHNICAL DATA Appliance category: II2HS3B/P Gas original: G20 (2H) 25 mbar Gas replacement: G25.1 (2HS) 25 mbar G30/G31 (3B/P) 30/30 mbar BYPASS DIAMETERS BURNER Ø...
- Page 8 GAS BURNERS FOR LPG G30 30 mbar NORMAL POWER REDUCED POW- INJECTOR MARK NOMINAL GAS FLOW BURNER ER kW 1/100 mm Rapid 0.72 Semi-rapid 0.43 Auxiliary 0.95 0.35 GAS BURNERS FOR LPG G31 30 mbar NORMAL POWER REDUCED POWER INJECTOR MARK NOMINAL GAS FLOW BURNER 1/100 mm...
- Page 9 5. Replace the rating plate (it is near the gas The appliance is set for natural gas, supply pipe) with the one for the new type of you can change it to liquid gas, with gas supply. the correct injectors. The gas rate is adjusted to suit.
-
Page 10: Levelling Of The Appliance
LEVELLING OF THE APPLIANCE 1. Install the anti-tilt protection 305 - 310 mm down from the top surface of the appliance and 80 - 85 mm from the side of the appliance into the circular hole on a bracket. Screw it into the solid material or use applicable reinforcement (wall). -
Page 11: Product Description
PRODUCT DESCRIPTION GENERAL OVERVIEW Knobs for the hob Knob for the Minute Minder Knob for the temperature Temperature indicator / symbol Knob for the oven functions Heating element Lamp Shelf positions COOKING SURFACE LAYOUT Auxiliary burner Steam outlet - number and position depend on the model Semi-rapid burner Semi-rapid burner... -
Page 12: Before First Use
For cakes and biscuits. BEFORE FIRST USE 1. Set the function . Set the maximum WARNING! Refer to Safety chapters. temperature. 2. Let the oven operate for 1 hour. 3. Set the function . Set the maximum INITIAL CLEANING temperature. The maximum temperature for this Remove all accessories from the oven. -
Page 13: Hob - Hints And Tips
BURNER OVERVIEW A. Burner cap B. Burner crown C. Ignition candle D. Thermocouple TURNING THE BURNER OFF To put the flame out, turn the knob to the off position WARNING! Always turn the flame down or switch it off before you remove the pans from the burner. -
Page 14: Oven - Daily Use
• Scratches or dark stains on the surface have no PAN SUPPORTS effect on how the hob operates. The pan supports are not resistant to • Use a special cleaner suitable for the surface of washing in a dishwasher. They must the hob. -
Page 15: Oven - Clock Functions
Symbol Oven function Application Grilling To grill flat food and to toast bread The maximum temperature for this function is 210 °C. Bottom Heat To bake cakes with crispy bottom and to preserve food. Fan Cooking To roast or roast and bake food with the same cooking temperature on more than one shelf position, without fla- vour transference. -
Page 16: Oven - Hints And Tips
Tray: Put the tray or deep pan on the shelf position. Make sure it does not touch the back wall of the oven. Do not push the baking tray all the way to the back wall of the cavity. This prevents the heat from circulating around the tray. -
Page 17: Conventional Cooking
CONVENTIONAL COOKING Shelf posi- Food Quantity (g) Temperature (°C) Time (min) Accessories tion 1000 160 - 170 30 - 35 baking tray Flat cake Yeast cake with 2000 170 - 190 40 - 50 baking tray apples Drip pan cake 1500 160 - 170 baking tray... -
Page 18: Fan Cooking
Shelf posi- Food Quantity (g) Temperature (°C) Time (min) Accessories tion 1500 180 - 190 25 - 35 baking tray Crumble cake 180 - 200 20 - 25 baking tray Buttered cake 1) Preheat the oven for 10 minutes. 2) After you switch off the appliance, leave the cake in the oven for 7 minutes. 3) Preheat the oven for 20 minutes. - Page 19 Temperature Shelf posi- Food Quantity (g) Time (min) Accessories (°C) tion 750 + 750 160 - 170 40 - 50 baking tray Peasant bread Romanian 600 + 600 155 - 165 40 - 50 2 light trays (length: 25 sponge cake cm) on the same shelf position...
-
Page 20: Information For Test Institutes
Tempera- Shelf posi- Food Time (min) Accessories ture (°C) tion Brownie 35 - 45 baking tray or grill- / roasting pan Cakes in tin Soufflé 35 - 45 six ceramic ramekins on wire shelf Sponge flan base 25 - 35 flan base tin on wire shelf Sponge cake 35 - 45... -
Page 21: Pizza Setting
Temperature Shelf posi- Food Function Accessories Time (min) (°C) tion Small cakes (16 per Fan Cooking baking tray 20 - 30 tray) Apple pie (2 tins Ø20 Conventional wire shelf 65 - 75 cm, diagonally off Cooking set) Apple pie (2 tins Ø20 Fan Cooking wire shelf 70 - 80... -
Page 22: Replacing The Lamp
STAINLESS STEEL OR ALUMINIUM OVENS Clean the oven door with a damp cloth or sponge only. Dry it with a soft cloth. Do not use steel wool, acids or abrasive materials as they can damage the oven surface. Clean the oven control panel with the same precautions. -
Page 23: Service Data
WHAT TO DO IF... Problem Possible cause Remedy There is no spark when you try The hob is not connected to an Check if the hob is correctly to activate the spark generator. electrical supply or it is con- connected to the electrical nected incorrectly. -
Page 24: Energy Efficiency
Before you use the burners and pan support make sure they are assembled correctly. PRODUCT INFORMATION FOR OVENS AND PRODUCT INFORMATION SHEET Supplier's name Zanussi Model identification ZCK552J1WA 943005453 Energy Efficiency Index 94.9 Energy efficiency class Energy consumption with a standard load, conventional 0.84 kWh/cycle... -
Page 25: Environmental Concerns
Heat source Electricity Volume 54 l Type of oven Oven inside Freestanding Cooker Mass 42.0 kg IEC/EN 60350-1 - Household electric cooking appliances - Part 1: Ranges, ovens, steam ovens and grills - Methods for measuring performance. Residual heat OVEN - ENERGY SAVING When the cooking duration is longer than 30 min, The oven has features which help you reduce the oven temperature to minimum 3 - 10... - Page 28 WWW.ZANUSSI.COM/SHOP...
