Arrow Storage Products ELPHD84EU Owner's Manual & Assembly Manual

Nominal size 8' x 4'
Hide thumbs

Advertisement

Quick Links

Download this manual
719620917
Owner's Manual
& Assembly Guide
Gloves must be worn
at all times to reduce
risk of injury!
Customer Service:
1-800-851-1085
assist@arrowsheds.com
BUILDING DIMENSIONS
†
Approx.
Size
8' x 4'
31 Sq. Ft. 192 Cu. Ft.
2,4 m x 1,2 m
2,9 m
* See Inside for Detailed Safety Information.
Model No.
or
†
Size rounded off to the nearest foot
Exterior Dimensions
Storage
(Roof Edge to Roof Edge)
Area
Width
100"
2
5,4 m 3
254,0 cm
ELPHD84
Depth
Height
Width
51 3/8"
79"
94 3/4"
130,5 cm
200,7 cm
240,7 cm
www.arrowsheds.com
ELPHD84EU
ELPHD84SB
8' x 4'
Base
97 1/2" x 49 1/2"
Size
247,7 cm x 125,7 cm
For proper base construction see page 12
Interior Dimensions
(Wall to Wall)
Depth
Height
46 3/4"
77 13/16"
118,7 cm
197,6 cm
01DC
Nominal Size
Door
Opening
Width
Height
59 1/2"
69"
151,1 cm
175,3 cm

Advertisement

loading
Need help?

Need help?

Do you have a question about the ELPHD84EU and is the answer not in the manual?

Questions and answers

Related Manuals for Arrow Storage Products ELPHD84EU

Summary of Contents for Arrow Storage Products ELPHD84EU

  • Page 1 01DC 719620917 Owner’s Manual & Assembly Guide www.arrowsheds.com ELPHD84 ELPHD84EU Model No. Gloves must be worn ELPHD84SB at all times to reduce risk of injury! 8’ x 4’ Nominal Size Customer Service: 1-800-851-1085 Base 97 1/2” x 49 1/2” assist@arrowsheds.com...
  • Page 2 GB: Assembly manual in additional languages available online. Scan QR code below to access. FR: Manuel de montage disponible en ligne dans d’autres langues. Pour y accéder, scannez le code QR ci-dessous. SP: Manual de montaje en idiomas adicionales disponible online. Escanee el código QR a continuación para acceder.
  • Page 3 SAFETY PRECAUTIONS... Safety precautions MUST be followed at all times throughout the construction of your building! Practice caution with the tools being used in the Care must be taken when handling various pieces assembly of this building. Be especially familiar with of your building since many contain sharp edges.
  • Page 4 ASSEMBLY TIPS & TOOLS Watch the Weather Closely: Be sure the day you choose to install your building is dry and calm. Do NOT attempt to assemble your building on a windy day. Be careful on wet or muddy ground. Use Teamwork: Two or more people are required to assemble your building.
  • Page 5 FREQUENTLY ASKED QUESTIONS How long will it take to assemble the building? Assembly time depends on a variety of factors, including roof design, tools available, DIY skill and the pace at which you work. Guidelines for each shed assembly are approximate AFTER completion of the base, and assume two or more people working on the assembly.
  • Page 6 What kind of base do I use? You can: •Use an Arrow Base Kit •Pour a concrete slab •Build a wood deck/fl oor (use exterior-grade plywood) •Use patio blocks •Build on crushed gravel, dirt or grass Arrow provides a base kit accessory that is an option for most building sizes. If you are building a wood deck/fl oor, an Arrow fl...
  • Page 7 What if the rear wall angle and channels are too large to fi t inside of the rear wall panels? Check the dimensions of wall assemblies. They should be slightly smaller than the fl oor frames. Lay the assemblies on top of the rear fl oor frame and pull them up to the top of the wall panels causing the corner panels to stand erect and not lean inward.
  • Page 8 HARDWARE LIST... 07AH Part Part Qty. Description List Hardware Views by Key No. 65103 Hex Nut (#8-32) 65923-33 Small Bolt (Sand) (#8-32 x 3/8) (10 mm) 65923-32 Small Bolt (Meadow Green) (#8-32 x 3/8) (10 mm) 65004-33 #2 Phillips #2 Phillips Small Screw (Sand) (#8AB x 5/16) (8 mm) 11/32 Hex.
  • Page 9 PARTS LIST... 08AH Part Part Qty. Selected End Views by Key No. Description List 10866 Front/Rear Floor Frame 10850 Side Floor Frame 10702 Ramp 10701 Corner Panel 10858 Front Wall Panel 10725 Wall Panel 10836 Wall Panel 6155 Wall Panel 10716 Right Door Jamb 80057 Left Door Jamb 10864 Front Wall Channel...
  • Page 10 ASSEMBLY BY KEY NO. 09AH Walls Floor...
  • Page 11 ASSEMBLY BY KEY NO. 10AH Roof Doors...
  • Page 12 ASSEMBLY OVERVIEW 11AH Install Corner Panels, Side Angles, Build the Floor Frame Rear Angles, and Door Jambs Attach Header, Gables, and Roof Beam Install Wall Panels and Wall Channels Install Roof Panel, Roof Trim, and Install Doors Corner Cap Shed is now complete.
  • Page 13 CONSTRUCTING A BASE... 12AH No matter which of the options below you choose for a base, an ARROW ANCHORING KIT is recommended as an effective method of properly securing your building after assembly is complete. OPTION 1: Directly on ground (earth) Assemble your building directly on level ground (grass, dirt, rock, sand, etc.).
  • Page 14 Step 1: Floor Frames 13AH You will need for this page: 10866 Washers are to be used on painted parts only. Washers are not necessary on unpainted Front/Rear parts and there are not enough to use on (QTY: 8) Floor Frame every screw and bolt.
  • Page 15 Step 2: Wall Frames 14AH You will need for this page: 6615 9924 Rear Wall Rear Wall (QTY: 2) Angle Channel 6615 Overlap two (2) Rear Wall Angles so that fi ve (5) 9924 holes align as shown. Insert one (1) Sand Bolt and Nut through the center hole.
  • Page 16 Step 3: Header 15AH You will need for this page: 10826 10795 Front Inner Front Outer (QTY:2) Header Header 10795 Connect the Front Inner Header to a Front Outer Header using one (1) Sand Screw as shown. Repeat this for the opposite end. Set aside for use in Step 10.
  • Page 17 Step 4: Roof Beams 16AH You will need for this page: 10865 10865 Roof Beam (QTY: 8) Overlap two (2) Roof Beams so that the bottom slots align as shown. Insert six (6) Sand Bolts and Nuts as shown below. Overlap parts so the bottom slots align.
  • Page 18 Step 5: Door Pre-Assembly 17AH You will need for this page: 10856 10718 10719 10720 67236 Horizontal Door Handle Diagonal Door Adhesive Pad Door Panel (QTY: 2) Door Brace Brace Brace (QTY: 24) Start assembly by sliding the Door Handle Place the ends of Diagonal Door Braces Brace into the middle of the Door and securing with small holes under Horizontal Door...
  • Page 19 Step 6: 18AH Right Door Assembly You will need for this page: 66609 66809 66054 Locking (QTY: 2) (QTY: 6) Hinge Handle Right Latch Attach Hinges to Door using six (6) Flat Head Bolts. Install Locking Handle using two (2) Long Bolts. Attach Latch to Locking Handle.
  • Page 20 Step 7: Left Door Assembly 19AH You will need for this page: 66609 66810 Left (QTY: 2) (QTY: 6) Hinge Handle Attach Hinges to Door using six (6) Flat Head Bolts. Install Locking Handle using two (2) Long Bolts. 66609 66810...
  • Page 21 Step 7: Continued 20AH You will need for this page: 66808 10721 66684 Bottom Top Latch Door Stop (QTY: 8) Latch Spring Spring Remove two (2) Screws from left side of Door Handle Brace and far left Screw from both top and bottom Horizontal Door Brace.
  • Page 22 Step 8: Floor Assembly 21AH You will need for this page: Assemblies from Step 1: 10850 • Front/Rear Floor Frame Assemblies (2) Side Floor (QTY: 8) Frame Do NOT fasten your Floor Frames to your Base at this time. You will anchor your building after it is erected.
  • Page 23 Step 9: Corner Panels 22AH Be cautious when maneuvering You will need for this page: and placing Panels. Once Panels 10701 begin to go up it is important to be able to fi nish in a timely manner to reduce the possibility of wind Corner (QTY: 8) Panel...
  • Page 24 Step 10: Wall Framing 23AH You will need for this page: Assemblies from Step 2 and Step 3: 10852 • Rear Wall Angle Assembly (1) • Header Assembly (1) Side (QTY: 8) Wall Angle Install Rear Wall Angle Assembly to Rear Corner Panels using two (2) Sand Screws as shown. Install the Header Assembly using two (2) Sand Screws.
  • Page 25 Step 11: Wall Panels 24AH You will need for this page: 10858 6155 10725 10836 [ NO HARDWARE NEEDED FOR THIS STEP ] Front Wall Panel Wall Panel Wall Panel Wall Panel FASTEN TO WALL ANGLES Lay out all Panels in the positions shown below. Double check that you have the correct Panel in each location.
  • Page 26 Step 11: Continued 25AH You will need for this page: (QTY: 90) (QTY: 13) Working one side at a time, lift the Panels into Corner Panels lay over Wall Panels. place and secure top and bottom of Panels with Sand Screws. Corner Panel Place one (1) Sand Bolt and Nut through the center hole of the Panel where Panels overlap,...
  • Page 27 Step 12: Door Jambs 26AH You will need for this page: 10716 80057 Right Door Left Door (QTY: 8) (QTY: 4) Jamb Jamb Secure Door Jambs with two (2) Meadow Green Screws in the top and bottom of each Door Jamb as shown.
  • Page 28 Step 13: Wall Channels 27AH You will need for this page: 10864 10854 Assemblies from Step 2: • Rear Wall Channel Assembly (1) (QTY: 2) (QTY: 40) Front Wall Side Wall Channel Channel Install Channels on inside of building. (QTY: 4) Rear Wall Channel Assembly Install Rear Wall Channel Assembly by placing Sand Screws through all remaining...
  • Page 29 Step 14: Gables 28AH You will need for this page: 7907 7906 7916 69836 (QTY: 4) Left Gable Right Gable Gable Brace Edge Trim Install Edge Trim. Edge Trim (Plastic) Edge Trim MUST cover Gable edge. Install Edge Trim to cover Gable Edge BEFORE doing ANY work with Gables.
  • Page 30 Step 14: Continued 29AH You will need for this page: (QTY: 12) Working one (1) Gable at a time, attach Gables to Side Wall Angles with six (6) Sand Screws per Gable as shown below. Gable must fi t UNDER Rear Wall Angle at corner.
  • Page 31 Step 15: Roof Framing 30AH You will need for this page: Assemblies from Step 4: • Roof Beam Assembly (1) (QTY: 4) Attach Roof Beam Assembly to Gable Brace using two (2) Sand Bolts and Nuts per end as shown. Attach Roof Beam to Gable Brace through top two (2) holes.
  • Page 32 Step 16: 31AH Window Assembly You will need for this page: 10859 10845 Window Window (QTY: 14) Header Lower Upright Outer Working one part at a time, insert Window Header Lower into slot of Gable aligning front hole with bottom hole in Gable. This is to ensure the hole alignment with the Front Header is correct.
  • Page 33 Step 16: Continued 32AH You will need for this page: 10845 10862 Window Window Support (QTY: 4) Upright Outer Angle Lower Attach Window Upright Outer and Window Support Angle Lower to Window Header Lower using four (4) Long Bolts and Nuts. DO NOT TIGHTEN BOLTS AT THIS TIME. 10845 10862 10862...
  • Page 34 Step 16: Continued 33AH You will need for this page: END VIEW 66836 66836 (QTY: 4) Window 10862 Remove protective fi lm from both sides of Window. 10859 Insert Windows inside Window Header Lower. Place between Window Header Lower and Window Support Angle Lower.
  • Page 35 Step 16: Continued 34AH You will need for this page: END VIEW 10861 10863 Window Window Support Header Upper Angle Upper (QTY: 4) (QTY: 4) 10861 Secure Window Support Angle Upper to Window Header Upper using two (2) 10863 Sand Bolts and Nuts as shown. DO NOT TIGHTEN BOLTS.
  • Page 36 Roof Install Prep Page 35AH Use the information on this page to complete step 17. If Roof Beam holes do not line up with Roof Panel holes, shift the building from left to right. If this does not help, your building may not be level. Shim the corners until holes line up.
  • Page 37 Step 17: Roof Assembly 36AH You will need for this page: 80083 10840 Left Roof Right Roof (QTY: 6) (QTY: 10) Panel Panel Working one (1) Panel at a time, secure Right Roof Panel to Header Assembly by placing one (1) Sand Screw in hole #1 (from the diagram below).
  • Page 38 Step 17: Continued 37AH You will need for this page: 10837 LEAVE HOLES OPEN Roof Panel (QTY: 18) (QTY: 2) Attach Panels #3 and #4 in order given in the diagram on page 35. Use the diagram to FASTEN TO HEADER WITH SCREWS the right while assembling the roof.
  • Page 39 Step 17: Continued 38AH You will need for this page: 10838 LEAVE HOLES OPEN Roof Panel (QTY: 24) (QTY: 3) Attach Panels #5 and #6 in order given in the diagram on page 35. Use the diagram to FASTEN TO HEADER WITH SCREWS the right while assembling the roof.
  • Page 40 Step 18: Roof Trim 39AH You will need for this page: 80085 10860 66183R 66183L Right Roof Left Roof Left Roof Right Roof (QTY: 10) (QTY: 4) Trim Cap Trim Cap Trim Trim Position Left and Right Roof Trim and secure with ten (10) Meadow Green Screws.
  • Page 41 Step 19: Door Installment 40AH You will need for this page: Assemblies from step 6 and step 7: 10702 • Right Door Assembly (1) • Left Door Assembly (1) (QTY:4) (QTY:12) Ramp NEED AT LEAST TWO PEOPLE TO PERFORM THIS STEP! Using three (3) Flat Head Bolts and Nuts per Door Hinge, secure Doors to Door Jambs.
  • Page 42 Step 20: Seal Window 41AH You will need for this page: Reused Parts: [ NO HARDWARE NEEDED • Edge Trim (1) FOR THIS STEP ] Cut a strip of Edge Trim to 5 3/4” (14,6 cm) long. On the inside of the building, apply strip at middle of window where two (2) Window Upright Outers meet.
  • Page 43 ANCHORING OPTIONS... IMPORTANT: • If you have swing doors, they must hang and swing level before anchoring building. • Anchor your building at this time. See below for details on anchoring. • If you have purchased a Floor Frame Kit, you should install it at this time. •...
  • Page 44 CARE & MAINTENANCE... Exterior Care: For a long lasting fi nish, clean and wax the exterior surface. We recommend washing with a mild soap solution. DO NOT use power washing to clean your shed. Using a spray automotive type wax periodically on the exterior is highly recommended if you are in a high humidity or coastal climate region.
  • Page 45 ARROW ACCESSORIES... 39AB TOOL HANGING RACK ANCHOR KITS Model No. TH100 Model No. AK4 The perfect tool organizer. Twin Anchor Kit contains heavy-duty steel 25 1/2" (64,8 cm) steel channels augers, 60' (18 m) of steel cable and plus fi ve heavy-duty snap-in 4 cable clamps.
  • Page 46 ASSEMBLY NOTES...
  • Page 47 ASSEMBLY NOTES...
