Summary of Contents for Arrow Storage Products ELPHD104
Page 1
01AI 719710614 Owner’s Manual & Assembly Guide www.arrowsheds.com Model No. ELPHD104 10’ x 4’ Gloves must be worn at all times to reduce risk of injury! Nominal Size Customer Service: 1-800-851-1085 Base 121” x 49 1/2” assist@arrowsheds.com Size 307,3 cm x 125,7 cm...
Page 2
SAFETY PRECAUTIONS... Safety precautions MUST be followed at all times throughout the construction of your building! Practice caution with the tools being used in the Care must be taken when handling various pieces assembly of this building. Be especially familiar with of your building since many contain sharp edges.
Page 3
ASSEMBLY TIPS & TOOLS Watch the Weather Closely: Be sure the day you choose to install your building is dry and calm. Do NOT attempt to assemble your building on a windy day. Be careful on wet or muddy ground. Use Teamwork: Two or more people are required to assemble your building.
Page 4
FREQUENTLY ASKED QUESTIONS How long will it take to assemble the building? Assembly time depends on a variety of factors, including roof design, tools available, DIY skill and the pace at which you work. Guidelines for each shed assembly are approximate AFTER completion of the base, and assume two or more people working on the assembly.
Page 5
What kind of base do I use? You can: •Use an Arrow Base Kit •Pour a concrete slab •Build a wood deck/fl oor (use exterior-grade plywood) •Use patio blocks •Build on crushed gravel, dirt or grass Arrow provides a base kit accessory that is an option for most building sizes. If you are building a wood deck/fl oor, an Arrow fl...
Page 6
What if the rear wall angle and channels are too large to fi t inside of the rear wall panels? Check the dimensions of wall assemblies. They should be slightly smaller than the fl oor frames. Lay the assemblies on top of the rear fl oor frame and pull them up to the top of the wall panels causing the corner panels to stand erect and not lean inward.
Page 7
HARDWARE LIST... 07AI Part Part Qty. Description List Hardware Views by Key No. 65103 Hex Nut (#8-32) 65923-33 Small Bolt (Sand) (#8-32 x 3/8) (10 mm) 65923-32 Small Bolt (Meadow Green) (#8-32 x 3/8) (10 mm) 65004-33 #2 Phillips #2 Phillips Small Screw (Sand) (#8AB x 5/16) (8 mm) 11/32 Hex.
Page 8
PARTS LIST... 08AI Part Part Qty. Selected End Views by Key No. Description List 10703 Front/Rear Floor Frame 10850 Side Floor Frame 10702 Ramp 10701 Corner Panel 10699 Front Wall Panel 5210 Wall Panel 10836 Wall Panel 10716 Right Door Jamb 80057 Left Door Jamb 10709 Front Wall Channel 9917...
Page 11
ASSEMBLY OVERVIEW 11AI Install Corner Panels, Side Angles, Build the Floor Frame Rear Angles, and Door Jambs Attach Header, Gables, and Roof Beam Install Wall Panels and Wall Channels Install Roof Panel, Roof Trim, and Install Doors Corner Cap Shed is now complete.
Page 12
CONSTRUCTING A BASE... 12AI No matter which of the options below you choose for a base, an ARROW ANCHORING KIT is recommended as an effective method of properly securing your building after assembly is complete. OPTION 1: Directly on ground (earth) Assemble your building directly on level ground (grass, dirt, rock, sand, etc.).
Page 13
Step 1: Floor Frames 13AI You will need for this page: 10703 Washers are to be used on painted parts only. Washers are not necessary on unpainted Front/Rear parts and there are not enough to use on (QTY: 8) Floor Frame every screw and bolt.
Page 14
Step 2: Wall Frames You will need for this page: 5986 9917 Rear Wall Rear Wall (QTY: 2) Angle Channel 5986 Overlap two (2) Rear Wall Angles so that fi ve (5) 9917 holes align as shown. Insert one (1) Sand Bolt and Nut through the center hole.
Page 15
Step 3: Header You will need for this page: 10707 10708 Front Inner Front Outer (QTY:2) Header Header Connect the Front Inner Header to a Front Outer 10708 Header using one (1) Sand Screw as shown. Repeat this for the opposite end. Set aside for use in Step 10.
Page 16
Step 4: Roof Beams 16AI You will need for this page: 10874 10874 Roof Beam (QTY: 8) Overlap two (2) Roof Beams so that the bottom slots align as shown. Insert six (6) Sand Bolts and Nuts as shown below. Overlap parts so the bottom slots align.
Page 17
Step 5: Door Pre-Assembly 17AH You will need for this page: 10856 10718 10719 10720 67236 Horizontal Door Handle Diagonal Door Adhesive Pad Door Panel (QTY: 2) Door Brace Brace Brace (QTY: 24) Start assembly by sliding the Door Handle Place the ends of Diagonal Door Braces Brace into the middle of the Door and securing with small holes under Horizontal Door...
Page 18
Step 6: 18AH Right Door Assembly You will need for this page: 66609 66809 66054 Locking (QTY: 2) (QTY: 6) Hinge Handle Right Latch Attach Hinges to Door using six (6) Flat Head Bolts. Install Locking Handle using two (2) Long Bolts. Attach Latch to Locking Handle.
Page 19
Step 7: Left Door Assembly 19AH You will need for this page: 66609 66810 Left (QTY: 2) (QTY: 6) Hinge Handle Attach Hinges to Door using six (6) Flat Head Bolts. Install Locking Handle using two (2) Long Bolts. 66609 66810...
Page 20
Step 7: Continued 20AH You will need for this page: 66808 10721 66684 Bottom Top Latch Door Stop (QTY: 8) Latch Spring Spring Remove two (2) Screws from left side of Door Handle Brace and far left Screw from both top and bottom Horizontal Door Brace.
Page 21
Step 8: Floor Assembly 21AH You will need for this page: Assemblies from Step 1: 10850 • Front/Rear Floor Frame Assemblies (2) Side Floor (QTY: 8) Frame Do NOT fasten your Floor Frames to your Base at this time. You will anchor your building after it is erected.
Page 22
Step 9: Corner Panels 22AH Be cautious when maneuvering You will need for this page: and placing Panels. Once Panels 10701 begin to go up it is important to be able to fi nish in a timely manner to reduce the possibility of wind Corner (QTY: 8) Panel...
Page 23
Step 10: Wall Framing 23AI You will need for this page: Assemblies from Step 2 and Step 3: 10852 • Rear Wall Angle Assembly (1) • Header Assembly (1) Side (QTY: 8) Wall Angle Install Rear Wall Angle Assembly to Rear Corner Panels using two (2) Sand Screws as shown. Install the Header Assembly using two (2) Sand Screws.
Page 24
Step 11: Wall Panels 24AI You will need for this page: 10699 5210 10836 [ NO HARDWARE NEEDED FOR THIS STEP ] Front Wall Panel Wall Panel Wall Panel FASTEN TO WALL ANGLES Lay out all Panels in the positions shown below. Double check that you have the correct Panel in each location.
Page 25
Step 11: Continued 25AI You will need for this page: (QTY: 96) (QTY: 15) Use bolts to attach Wall Panels Working one side at a time, lift the Panels into where Wall Angles overlap. place and secure top and bottom of Panels with Sand Screws.
Page 26
Step 12: Door Jambs 26AI You will need for this page: 10716 80057 Right Door Left Door Jamb (QTY: 8) (QTY: 4) Jamb Secure Door Jambs with two (2) Meadow Green Screws in the top and bottom of each Door Jamb as shown.
Page 27
Step 13: Wall Channels 27AI You will need for this page: 10709 10854 Assemblies from Step 2: • Rear Wall Channel Assembly (1) (QTY: 2) (QTY: 44) Front Wall Side Wall Channel Channel Install Channels on inside of building. (QTY: 4) Rear Wall Channel Assembly Install Rear Wall Channel Assembly by placing Sand Screws through all remaining...
Page 28
Step 14: Gables 28AH You will need for this page: 7907 7906 7916 69836 (QTY: 4) Left Gable Right Gable Gable Brace Edge Trim Install Edge Trim. Edge Trim (Plastic) Edge Trim MUST cover Gable edge. Install Edge Trim to cover Gable Edge BEFORE doing ANY work with Gables.
Page 29
Step 14: Continued 29AI You will need for this page: (QTY: 12) Working one (1) Gable at a time, attach Gables to Side Wall Angles with six (6) Sand Screws per Gable as shown below. Gable must fi t UNDER Rear Wall Angle at corner.
Page 30
Step 15: Roof Framing 30AI You will need for this page: Assemblies from Step 4: • Roof Beam Assembly (1) (QTY: 4) Attach Roof Beam Assembly to Gable Brace using two (2) Sand Bolts and Nuts per end as shown. Attach Roof Beam to Gable Brace through top two (2) holes.
Page 31
Step 16: 31AI Window Assembly You will need for this page: 10869 10845 Window Window (QTY: 16) Header Lower Upright Outer Working one part at a time, insert Window Header Lower into slot of Gable aligning front hole with bottom hole in Gable. This is to ensure the hole alignment with the Front Header is correct.
Page 32
Step 16: Continued 32AI You will need for this page: 10845 10871 Window Window Support (QTY: 4) Upright Outer Angle Lower Attach Window Upright Outer and Window Support Angle Lower to Window Header Lower using four (4) Long Bolts and Nuts. DO NOT TIGHTEN BOLTS AT THIS TIME. 10845 10871 10871...
Page 33
Step 16: Continued 33AI You will need for this page: END VIEW 66838 66838 (QTY: 4) Window 10871 Remove protective fi lm from both sides of Window. 10869 Insert Windows inside Window Header Lower. Place between Window Header Lower and Window Support Angle Lower.
Page 34
Step 16: Continued 34AI You will need for this page: END VIEW 10870 10873 Window Window Support Header Upper (QTY: 4) Angle Upper (QTY: 4) 10870 Secure Window Support Angle Upper to Window Header Upper using two (2) 10873 Sand Bolts and Nuts as shown. DO NOT TIGHTEN BOLTS.
Page 35
Roof Install Prep Page 35AI Use the information on this page to complete step 17. If Roof Beam holes do not line up with Roof Panel holes, shift the building from left to right. If this does not help, your building may not be level. Shim the corners until holes line up.
Page 36
Step 17: Roof Assembly 36AI You will need for this page: 80083 10840 Left Roof Right Roof (QTY: 6) (QTY: 10) Panel Panel Working one (1) Panel at a time, secure Right Roof Panel to Header Assembly by placing one (1) Sand Screw in hole #1 (from the diagram below).
Page 37
Step 17: Continued 37AI You will need for this page: 10868 LEAVE HOLES OPEN Roof Panel (QTY: 48) (QTY: 5) Attach Panels #3, #4, #5, and #6 in order given in the diagram on page 35. Use the FASTEN TO HEADER WITH SCREWS diagram to the right while assembling the FASTEN TO ROOF BEAM WITH SCREWS roof.
Page 38
Step 18: Roof Trim 38AI You will need for this page: 80087 10872 66183R 66183L Right Roof Left Roof Left Roof Right Roof (QTY: 10) (QTY: 4) Trim Cap Trim Cap Trim Trim Position Left and Right Roof Trim and secure with ten (10) Meadow Green Screws.
Page 39
Step 19: Door Installment 39AI You will need for this page: 10702 Assemblies from step 6 and step 7: • Right Door Assembly (1) • Left Door Assembly (1) (QTY:4) (QTY:12) Ramp NEED AT LEAST TWO PEOPLE TO PERFORM THIS STEP! Using three (3) Flat Head Bolts and Nuts per Door Hinge, secure Doors to Door Jambs.
Page 40
Step 20: Seal Window 40AI You will need for this page: Reused Parts: [ NO HARDWARE NEEDED • Edge Trim (1) FOR THIS STEP ] Cut a strip of Edge Trim to 5 3/4” (14,6 cm) long. On the inside of the building, apply strip at middle of window where two (2) Window Upright Outers meet.
Page 41
ANCHORING OPTIONS... IMPORTANT: • If you have swing doors, they must hang and swing level before anchoring building. • Anchor your building at this time. See below for details on anchoring. • If you have purchased a Floor Frame Kit, you should install it at this time. •...
Page 42
CARE & MAINTENANCE... Exterior Care: For a long lasting fi nish, clean and wax the exterior surface. We recommend washing with a mild soap solution. DO NOT use power washing to clean your shed. Using a spray automotive type wax periodically on the exterior is highly recommended if you are in a high humidity or coastal climate region.
Page 43
ARROW ACCESSORIES... 39AB TOOL HANGING RACK ANCHOR KITS Model No. TH100 Model No. AK4 The perfect tool organizer. Twin Anchor Kit contains heavy-duty steel 25 1/2" (64,8 cm) steel channels augers, 60' (18 m) of steel cable and plus fi ve heavy-duty snap-in 4 cable clamps.
