USER MANUAL
60cm Cultivator
C/W Honda GX160
Product Code:
Serial Number Range:
From:
To:
Year Of Manufacture:
*Please note, when ordering online via our website if the part number is not recognised,
please Email spares@hscgroupuk.co.uk or Telephone 0115 946 1988
KEEP THIS BOOKLET FOR FUTURE REFERENCE
Nottingham: 0115 946 1988 • London: 0208 830 3333
The Hire Supply Company Terms & Conditions Apply At All Time E&OE
BL360H
Nottingham: sales@hscgroupuk.co.uk • London: sean@hscgroupuk.co.uk
www.hscgroupuk.co.uk
Advertisement
Related Manuals for Benassi BL360H
Summary of Contents for Benassi BL360H
- Page 1 USER MANUAL 60cm Cultivator C/W Honda GX160 Product Code: BL360H Serial Number Range: From: Year Of Manufacture: *Please note, when ordering online via our website if the part number is not recognised, please Email spares@hscgroupuk.co.uk or Telephone 0115 946 1988 KEEP THIS BOOKLET FOR FUTURE REFERENCE Nottingham: 0115 946 1988 •...
- Page 2 BL355 BL360 MOTOZAPPATRICE TILLER MOTOBINEUSE (IT) MANUALE DI USO E MANUTEZIONE (EN) OPERATORS MANUAL (FR) MANUEL D’UTILISATION...
- Page 3 BL355 BL360 Index (EN) Introduction Presentation ............................Warranty ............................20 General Information on the Safety Description of the machines Identification and description of the machines, operating way technical characteristics ....Technical data ............................Transport ............................... Storage ..............................Instructions for Placement of Machine in Service Assembly of the machine ........................
- Page 4 Thank you for your choice. 8.2 Warranty BENASSI srl guarantees all machinery, against defects of manufacture for a period of 1 year starting the date of the invoice (sale) of equipment. The warranty is annulled automatically in case of modification of the machine or when the repair is done for a non-authorized dealer and without previous consent for BENASSI srl The warranty just includes the replacement of deficient recognized pieces.
- Page 5 BL355 BL360 9 General Information on the Safety To guarantee the operator’s security, this machine must be used in accordance with the instructions of this manual. The machine must not be used without parts of origin and all systems of security must be in place ...
- Page 6 BL355 BL360 10 Description of the machines 10.1 Identification and description of the machines, operating way technical characteristics The Tiller is a farm machine. This material is essentially composed by a handlebar, a chassis, a pair of rotors and an engine. The thermal engine manipulates the rotors system;...
- Page 7 BL355 BL360 10.2 Technical data Model BL 360 - BL355 Engine Type Single cylinder, 4 stroke, air-cooled Engine Speed (rpm) 3600 Fuel Automative unleaded gasoline Fuel Tank Capacity 3,2 L Lube Capacity 0,6 L Starting System Recoil Starter Transmission By belt and chain Nr.
- Page 8 BL355 BL360 10.3 Transport The tiller is conditioned in packing in cardboard, which protects all components. Once the open packing, it is necessary to conduct the installation of the handlebar and the rotors, as the illustrations show it (Point 4.1 of this manual). After this installation, the manipulation of the machine is easier because it rests on front wheel, not ...
- Page 9 BL355 BL360 11 Instructions for Placement of Machine in Service 11.1 Assembly of the machine Adjust the height of the handlebar to obtain a comfortable working position. Picture 1 – Adjustable arm in height and lateral 11.2 Description of the machine and of his normal operation 4.2.1 Regulation of rotors depth: •...
- Page 10 BL355 BL360 4.2.2 Start / Command Operation of the engine Picture 2 • Put the oil in the crankcase of engine to arrive at suitable medium level in the plug of level of the level. The lube is of the type used for the thermal engines (15w-40).
- Page 11 BL355 BL360 If you must change area of work, it is counselled to loosen the lever of clutch to allow the rotors stop, in order to do the displacement in all security. Ever the operator will have to walk backwards, must have double caution to not stumble or fall.
- Page 12 BL355 BL360 4.2.4 Prevention of the risks The prevention of the risks is done by following elements: • Plastic Cover: is assembled on the top of the frame, behind the engine and it have function to protect the operator of rotative parts. His width alow also to avoid any projection of land and stones. •...
- Page 13 BL355 BL360 12 Risks and Procedures of Safety Factors that determine the dangerous Risks Description situation Rotors Movement Presence of cutting elements. Presence of security stickers recalling these Parts in rotation to the level of the risks on the machine lower members, capable to drag Read the point 2 of the instructions manual serious injuries...
- Page 14 BL355 BL360 13 Cleaning and Periodic Maintenance Conduct regularly the operation of revision and maintenance of the machine, be especially careful to maintain a correct oil level in the engine; it guarantees to have a machine all ready to be used in all security. All cleaning and maintenance operation must make itself engine extinguishes, and disconnect spark plug thread to avoid all inopportune starting.
- Page 15 BL355 BL360 13.3 Oil recommendations Please report to the instructions manual of the engine, joined to the machine, to know the recommendations of lubricant made by engine constructor. However, we inform you that the recommend lubricant is the one of type fluently used for the thermal engines.
- Page 16 BL355 BL360 14 Safety Instructions Pay particular attention to the following: Warning: This sign is a reminder of the precautions to be taken during certain procedures. It signals a significant danger of serious injury or death, should you not follow the instructions. The machine was designed to guarantee safe and reliable service when used according to instructions.
- Page 17 BL355 BL360 Always be aware that the owner or the user is responsible for the accidents or risks taken befalling third parties or their property. Ensure that the clamping devices are correctly tightened. Check the machine’s conditions before use, thus avoiding accidents or damage to the machine. ATTENTION DANGER! Petrol is flammable.
- Page 18 BL355 BL360 When it comes to putting the rotation tools in gear, please check that no-one is in front or in the vicinity of the machine. Firmly hold the handlebar of the machine; it has a tendency to lift during this procedure.
- Page 19 BL355 BL360 See maintenance advice in the user manual of the engine. Before starting the machine, always read the instructions manual and the assembly manual. The machine’s moving rate must be comparable to walking pace, not running. When backing up, please be very careful.
- Page 20 (Direttiva 2006/42/CE, Allegato II, Capitolo A) Directive 2006/42/EC, Annex II, Sub A / Directive 2006/42/CE, Annexe II, Chapitre A / Seguín la directiva 2006/42/EC, Anexo II, Sub A FABBRICANTE: BENASSI srl Manufacter / Fabricant / Fabricante INDIRIZZO: Via Lampedusa,1 40017 S.Matteo Decima (BO) IT Adress / Adresse / Dirección...
- Page 21 BL355 BL360 BENASSI srl Via Lampedusa, 1 40017 S.M. Decima Fraz. S.G. PErsiceto (BO) It Tel. +39 051 820 511 Fax +39 051 6826164 www.benassi.eu benassi@benassispa.it...
- Page 22 Recycling ENVIRONMENTAL PROTECTION: Please recycle any unwanted materials as opposed to disposing them as general waste. It is recommended the original is retained and used to store the product when not in use for prolonged periods of time. If this is not applicable ensure the materials are sorted and recycled in accordance with local regulations.
