Summary of Contents for Gorenje TGR 50 MNGU

  • Page 1 TGR 50-80 MNGU...
  • Page 2 Uputstva za upotrebu Instructions for Use...
  • Page 3 UPOZORENJA Uređaj mogu da koriste deca starija od 8 godina i osobe sa smanjenim telesnim, osetnim ili mentalnim sposobnostima, odnosno nedovoljnim iskustvom ili znanjem samo ako su pod nadzorom ili podučeni o upotrebi aparata na bezbedan način i ako razumeju potencijalne opasnosti. Deca ne smeju da se igraju uređajem.
  • Page 4 Ako bojler isključite iz električne mreže, zbog opasnosti od zamrzavanja, morate da ispustite vodu iz njega. Molimo da eventualne kvarove ne popravljate sami nego da o njima obavestite najbližu servisnu službu. Naši proizvodi su opremljeni komponentama koje nisu štetne po zdravlje i životnu sredinu i napravljeni su tako da ih u njihovoj zadnjoj životnoj fazi možemo što jednostavnije rastaviti i reciklirati.
  • Page 5 TGR 50 N 405 160 180 TGR 80 N 605 165 180 Priključne i montažne mere bojlera [mm] PRIKLJUČIVANJE NA VODOVOD Dovod i odvod vode su označeni bojama na cevima bojlera. Dovod hladne vode je označen plavom, a odvod tople vode crvenom bojom. Kod priključivanja pri zatvorenom sistemu pod pritiskom potrebno je na mestima ispuštanja vode upotrebiti baterije za mešanje pod pritiskom.
  • Page 6 Legenda: 1 - Baterije za mešanje 2 - Ekspanzioni sud 3 - Sigurnosni ventil a - Ventil za testiranje b - Nepovratni ventil 4 - Cevak sa priključkom na odvod 5 - Ispitni nastavak 6 - Ventil za redukciju pritiska 7 - Ventil za zatvaranje H - Hladna voda T - Topla voda...
  • Page 7 Legenda: 1 - Priključne kleme 2 - Termostat i dvopolni toplotni osigurač 3 - Grejač 4 - Kontrolna svetiljka L - Faza N - Neutralni provodnik - Uzemljenje Šema povezivanja električnih provodnika UPOZORENJE: Pre svake intervencije u unutrašnjosti bojlera obavezno isključite bojler iz električne mreže! UPOTREBA I ODRŽAVANJE Posle priključivanja na vodovodnu i električnu mrežu bojler je spreman za upotrebu.
  • Page 8 Vreme zagrevanja od 10 °С do 65 °С 1:38 2:37 1) Uredba komisije EU 812/2013; EN 50440 2) EN 50440 ZADRŽAVAMO PRAVO NA PROMENE, KOJE NE UTIČU NA FUNKCIONALNOST APARATA. Uputstvo za upotrebu je na raspolaganju i na našoj internet strani http://www.gorenje.com.
  • Page 9 WARNINGS The appliance may be used by children older than 8 years old, elderly persons and persons with physical, sensory or mental disabilities or lacking experience and knowledge, if they are under supervision or taught about safe use of the appliance and if they are aware of the potential dangers.
  • Page 10 Please do not try to fix any defects of the water heater on your own. Call the nearest authorised service provider. Our products incorporate components that are both environmentally safe and harmless to health, so they can be disassembled as easily as possible and recycled once they reach their final life stage.
  • Page 11 TGR 50 N 405 160 180 TGR 80 N 605 165 180 Connection and installation dimensions of the water heater [mm] CONNECTION TO THE WATER SUPPLY The water heater connections for the inlet and outlet of water are colour-coded. The inlet of cold water is marked with blue colour, while the hot water outlet is marked with red colour.
  • Page 12 Legend: 1 - Pressure mixer taps 2 - Expansion tank 3 - Safety valve a - Test valve b - Non-return valve 4 - Funnel with outlet connection 5 - Checking fitting 6 - Pressure reduction valve 7 - Closing valve H - Cold water T - Hot water Closed (pressure) system...
  • Page 13 Legend: 1 - Connection terminal 2 - Thermostat and bipolar thermal cut-out 3 - Electric heating element 4 - Pilot lamp L - Live conductor N - Neutral conductor - Earthing conductor Electric installation CAUTION: Before any intervention into the interior of the water heater, disconnect it from the power supply network! OPERATION AND MAINTENANCE After connecting to the water and power supply, the heater is ready for use.
  • Page 14 Heating time from 10 °С to 65 °С 1:38 2:37 1) EU Regulation 812/2013; EN 50440 2) EN 50440 WE RESERVE THE RIGHT TO MAKE CHANGES THAT DO NOT IMPAIR THE FUNCTIONALITY OF THE DEVICE. The user manual can also be found at our website http://www.gorenje.com.
  • Page 16 09/2022 517742...

This manual is also suitable for:

Tgr 80 mngu
