USP DURAMAX 2100L Multistore Owner's Manual

Vinyl garden shed size 6ft x 3.5ft / 1.9 m x 1.0 m approx.

Advertisement

Quick Links

A L L
P U R P O S E
V I N Y L
G A R D E N
EN
OWNER'S MANUAL /
Instructions for Assembly '2100L Multistore'
Size 6Ft x 3.5Ft / 1.9 m x 1.0 m
Ver: 0.0
FR
MANUEL D'INSTRUCTION/
Instructions pour l'Assemblage '2100L Multistore'
Dimension 6Pieds x 3.5Pieds / 1.9 Mètre x 1.0 Mètre
Ver: 0.0
DE
Benutzerhandbuch /
Montageanleitung'2100L Multistore'
Größe: 6Ft x 3.5Ft / 1.9 m x 1.0 m
Ver: 0.0
ES
MANUAL DEL PROPIETARIO /
Instrucciones de montaje '2100L Multistore'
Tamaño 6Pies x 3.5Pies / 1.9 Metros x 1.0 Metros
Ver: 0.0
PT
MANUAL DO PROPRIETARIO/
Intruções de montagem.'2100L Multistore'
Tamanho 6pés x 3.5pés / 1.9 Metro x 1.0 Metro
Ver: 0.0
NL
Gebruiksaanwijzing voor eigenaar/
Instructies voor bouw '2100L Multistore'
Maat 6 voet x 3.5 voet / 1.9 Meter x 1.0 Meter
Versie: 0.0
Příručka uživatele /
CS
Návod k montáži '2100L Multistore'
Velikost 6 Stopy x 3.5 Stopy / 1.9 Metr x 1.0 Metr
Verze : 0.0
NÁVOD PRE UŽÍVATELA /
SK
Návod na zloženie '2100L Multistore'
Velkosť 6Stopa x 3.5Stopa / 1.9 m x 1.0 m
Pozri: 0.0
PRIROČNIK ZA LASTNIKA /
SL
Navodila za montažo '2100L Multistore'
Velikost 6Čevljev x 3.5Čevljev / 1.9 Metrov x 1.0 Metrov
Razl: 0.0
Model # 90225
TM
A Product of
S H E D S
(Approx.)
(Approx.)
(Ca.)
(Aprox.)
(Aprox.)
(Ongeveer)
(Přibližně)
(približne)
(Približno)
VINYL GARDEN SHED
Gazdinski Priručnik /
HR
Instrukcije za skupštine '2100L Multistore'
Veličina 6 Stopalo x 3.5 Stopalo/ 1.9 Metar x 1.0 Metar
Ver: 0.0
FELHASZNÁLÓI KÉZIKÖNYV /
HU
Útmutató az összeszereléshez '2100L Multistore'
6Láb x 3.5Láb / 1.9 Méter x 1.0 Méter
Verzió: 0.0
SV
ÄGARENS MANUAL/
Monteringsinstruktioner för '2100L Multistore'
Storlek 6 fot x 3.5 fot / 1.9 m x 1.0 m
Version: 0.0
IT
MANUALE DEL PROPRIETARIO /
Istruzioni per l'assemblaggio '2100L Multistore'
Dimensione 6 Piedi x 3.5 Piedi / 1.9Metri x 1.0Metri
Versione 0.0
PODRĘCZNIK UŻYTKOWNIKA /
PL
nstrukcja montażu '2100L Multistore'
Wymiary 6Stopy x 3.5Stopy / 1.9 Metr x 1.0 Metr
Wersja: 0.0
MANUAL DE UTILIZARE /
RO
nstruc iuni de asamblare '2100L Multistore'
Mărime 6Picioare x 3.5Picioare / 1.9 Metri x 1.0 Metri
Ver: 0.0
РЪКОВОДСТВО ЗА ПРИТЕЖАТЕЛЯ /
BG
нструкции за сглобяване '2100L Multistore'
Размер 6 Фута x 3.5 Фута / 1.9 Метра x 1.0 Метра
Версия 0.0
KULLANIM KILAVUZU /
TR
ontaj Talimatlar '2100L Multistore'
(Yaklaşık olarak)
6Fit x 3.5Fit / 1.9 m x 1.0m
Sürüm: 0.0
(Približno)
(Hozzávetőlegesen)
(Ungefär)
(Circa)
(W przybliżeniu)
(Aprox.)
(приблизително)

Advertisement

loading
Need help?

Need help?

Do you have a question about the DURAMAX 2100L Multistore and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for USP DURAMAX 2100L Multistore

  • Page 1 VINYL GARDEN SHED A Product of A L L P U R P O S E V I N Y L G A R D E N S H E D S Gazdinski Priručnik / OWNER’S MANUAL / Instructions for Assembly ‘2100L Multistore’ Instrukcije za skupštine ‘2100L Multistore’...
  • Page 2 Building Dimensions : Storage Exterior Dimension Interior Dimension Approximate Door Opening Size Base Dimension Roof Edge to Edge Area Volume Wall to Wall inch inch inch inch 18 Sq. Ft 75 Cu.Ft 6 Ft x 3.5 Ft Width 75 3/4 192.3 74 5/8 189.6...
  • Page 3 Gebouw afmeting: Opslag Binnenkant afmeting Buitenkant afmeting Benadering Deur opening Maat Gebied Muur tot muur Volume Basis afmeting Dakrand tot rand inch inch inch inch 18 Vierkante 75 Kubieke 6 Voet x 8 Voet voet voet Wijdte 75 3/4 192.3 74 5/8 189.6 70 1/4...
  • Page 4 Zgrada dimenzija Približno određena Skladištenje Vanjski dimenzija Interijer dimenzija Vrata Open Područje Zidni to zidni Krov rub to rub mjera Svezak Temeljiti dimenzija inch inch inch inch 18 etvornih 75 Kubni 6 Stopalo x 8 Stopalo Stopalo Stopalo širina 75 3/4 192.3 74 5/8 189.6...
  • Page 5 Wymiary budowlane: Wymiary wewnętrzne Magazynowa Wymiary zewnętrzne Przybliżone Otwieranie drzwi Kubatura Wymiary fundamentów Dachu od krawędzi do krawędzi od ściany do ściany Powierzchnia wymiary inch inch inch 6 Stopy x 8 75 Stopy 18 Stopy sześcienny Szerokość Stopy kwadratowy 75 3/4 192.3 74 5/8 189.6...
  • Page 6 Tools You Will Need Alati, Trebat će Vam 1. Bežični Svrdlo Philips Voditelj 1. Cordless Drill - Philips Head 5. Tape Measure 5. Traka Divizor 2. Vijak Vozač Philips Voditelj . učni ukavice 2. Screwdriver - Philips Head 6. Hand Gloves 3.
  • Page 7 Seznam součásti Parts List Lista delle varie parti Zoznam častí Lista części Liste des pièces Teileliste Seznam delov Lista elementelor componente Списък на частите La Lista de Partes Dijelovi Lists Lista de Peças Alkatrészlista Parça Listesi Onderdelenlijst Komponentlista 1.Check all parts prior to installation. 2.Before starting installation, please refer to Safety &...
  • Page 8 VGA01 VGA30 VGA02 VGA31 VGA03 VGA32 VGA04 VGA37 VGA05 VGA39 VGA20 VGA40 VGA42 VGA21 VGA41 VGA43 VGA22 VGA44 VGA23 SGC1 VGA24 VGA25 VGA26 VGA27 VGA28 VGA29...
  • Page 9 VGA41 VGA23 VGA43 VGA44 VGA22 VGA44 VGA25 VGA30 VGA03 VGA32 VGA20 VGA01 VGA30 VGA27 VGA42 VGA25 VGA28 VGA04 VGA25 VGA25 VGA42 VGA21 VGA29 VGA05 VGA02 VGA27 VGA24 VGA40 VGA26 VGA31 VGA39 VGA37...
  • Page 10 # 10-26 # 27-29 # 30-33...
  • Page 11 Walls & Columns Zdi a kolumny Pareti & Colonne Steny a stĺpy ciany I Kolumny Murs et colonnes Pereţi şi st lpi Wände und Säulen Stene in stebri Стени Колони Columnas y paredes Zidovi i Kolumne Paredes e Colunas Falak és oszlopok Duvarlar &...
  • Page 12 1.Za omejitev vrtilnega momenta vijačnega vijaka nastavite 3 ali , da zagotovite, da vijaki ne ojačitijo kovinskih ojačitev. .Pomembno je, da sledite opisanim navodilom korak za korakom. 3.Montaže ne izvijajte, kadar piha močen veter. .Vsi deli so jasno označeni in pazite na pravilno uporabo. 5.Če se gradi skladišče proti steni, ga graditi ,5 ft.
  • Page 13 DuraMax sheds are best installed on a raised level ground or a concrete foundation. If the shed is installed at ground level, ensure that there is proper water drainage sloping away from the shed so rain water does not pool and get inside the shed. For heavy rain areas, place the shed on a raised foundation which will have minimum outside dimensions of 79 1/2”...
  • Page 14 Szopy DuraMax najlepiej instalować na podwyższonym poziomym gruncie lub na betonowym fundamencie. Jeśli szopa jest zainstalowana na poziomie gruntu, upewnij się, że jest odpowiedni odpływ wody, który spływa z dala od szopy, aby woda deszczowa nie gromadziła się i nie dostawała się do szopy.
  • Page 15 VGA37 (x1) BPS (x14) Insert the Sleeves (BPS) into all holes of the Base Pallet as shown in fig. Insérez les manchons (BPS) dans tous les trous de la palette de base comme indi ué sur la fig. Setzen Sie die Hülsen (BPS) in alle L cher der Basispalette ein, wie in Abb. Inserte las mangas (BPS) en todos los orificios de la plataforma base como se muestra en la fig.
  • Page 16 Column & Panel Assembly method Colonne et méthode de montage panneau Montageverfahren für Säulen und Paneele Columna y el método de montaje de Panel Método de montagem de colunas e painéis Kolom en paneelmontage methode Metoda sestavení sloupc a panel Metóda zhromaž...
  • Page 17 CLICK! 3&4 CLICK! 1&2 CLICK! CLICK!
  • Page 18 S5 (x4) VGA26 (x1) VGA26 VGA37 VGA26 VGA26 VGA26 VGA37 VGA37 2&3 VGA31 (x1) 1&2 VGA31 VGA26 VGA26 VGA31 VGA37 CLICK! VGA31 VGA26...
  • Page 19 VGA27 (x1) (x2) VGA27 VGA31 1&3 VGA37 VGA27 VGA27 VGA31 CLICK! VGA31 VGA37 VGA27 VGA27 VGA37 2&4 VGA30 (x1) VGA31 1&2 VGA30 VGA27 VGA31 VGA30 CLICK! VGA31 VGA30 VGA27...
  • Page 20 VGA28 (x1) (x2) 1&3 VGA28 VGA28 VGA28 VGA30 VGA30 CLICK! VGA37 VGA37 VGA30 VGA28 VGA30 VGA28 VGA30 2&4 VGA37 VGA30 (x1) VGA30 1&2 VGA28 VGA30 VGA28 VGA30 CLICK! VGA30 VGA30 VGA28 VGA30...
  • Page 21 VGA27 (x1) (x2) VGA30 VGA30 VGA27 1&3 VGA27 VGA37 CLICK! VGA30 VGA27 VGA30 VGA30 VGA27 VGA27 VGA37 VGA37 2&4 VGA32 (x1) CLICK! VGA30 VGA32 VGA37 VGA27 VGA32...
  • Page 22 S5 (x4) VGA29 (x1) VGA29 1&3 VGA29 VGA32 CLICK! VGA32 VGA29 VGA37 VGA32 VGA29 VGA29 VGA32 VGA37 2&4 SGC1 (x8) VGA04 (x1) VGA05 (x1) VGA04 VGA04 VGA04 VGA05 VGA05 VGA05 VGA04 SGC1...
  • Page 23 SGC1 (x4) VGA04 & VGA05(x1) VGA04 VGA31 SGC1 VGA26 VGA04 VGA04 1&2 SGC1 VGA31 VGA26 SGC1 (x2) VGA02 (x1) VGA02 VGA04 VGA04 VGA02 VGA26 1&2 SGC1 VGA04 VGA02 SGC1...
  • Page 24 SGC1 (x2) VGA03 (x1) VGA03 VGA04 VGA03 VGA04 VGA29 1&2 SGC1 VGA04 VGA03 SGC1 SGC1 (x4) VGA01 (x1) VGA03 VGA02 VGA01 VGA27 SGC1 VGA02 SGC1 VGA01 VGA01 VGA28 SGC1 VGA28...
  • Page 25 SGC1 (x8) VGA25 (x2) VGA25 1&2 VGA25 VGA03 VGA04 VGA29 VGA04 VGA25 SGC1 VGA03 VGA04 VGA25 VGA02 SGC1 VGA29 SGC1 (x4) VGA25 (x2) VGA25 1&2 VGA03 VGA03 VGA25 VGA01 VGA03 VGA01 VGA27 VGA25 SGC1 VGA02 VGA03 VGA01 VGA25 SGC1 VGA27...
  • Page 26 SGC1 (x5) VGA20 (x1) VGA20 VGA01 VGA20 1&2 VGA25 VGA01 VGA03 VGA03 SGC1 VGA01 VGA25 VGA20 VGA03 SGC1 SGC1 (x5) VGA21 (x1) VGA21 VGA01 VGA21 1&2 VGA25 VGA01 VGA02 VGA02 VGA01 VGA25 VGA02 VGA21 SGC1...
  • Page 27 Make sure that the wall s top corners are diagonally e ual. Assurez vous ue les coins supérieurs du mur sont égaux en diagonale. Stellen Sie sicher, dass die oberen Ecken der Wand diagonal gleich sind. Asegúrate de que las esquinas superiores de la pared sean diagonalmente iguales. Certifique-se de que os cantos superiores da parede sejam diagonalmente iguais.
  • Page 28 Top Door Assembly Sklop Gornjih Vrata Assemblage De Porte Supérieur Felső Ajtó Szerelés Spitzentür zusammenbau Övre D rren F rsamling Asamblea De Puerta Superior Montaggio Sportello Superiore Reuni o De Porta Superior Zespół Górnych Drzwi Bovenste Deur Vergaderingz Top Usa Montaj Horní...
  • Page 29 SGC1 (x10) VGA41 (x1) VGA22 &VGA42 (x1) VGA23 & VGA42 (x1) VGA22 SGC1 3&4 VGA22 VGA41 VGA41 SGC1 VGA41 VGA23 VGA23 SGC1 VGA22 1&2 VGA41 VGA41 S2 (x4) VGA44 (x2) VGA43 (x1) VGA44 VGA41 VGA44 1&2 VGA41 VGA41 VGA41 1&2 VGA43 VGA43 VGA41...
  • Page 30 SGC1 (x8) VGA20 VGA20 1&2 VGA42 VGA41 SGC1 VGA21 SGC1...
  • Page 31 Přední dveře Front Door Porta d'ingresso Predné dvere Frontowe drzwi Porte d'entrée Haustür Sprednja vrata U a din fa ă Puerta frontal Prednja vrata Входна врата Porta frontal Bejárati ajtó Ön kapı Voor Deur Framdörr Potřebné součástí Parts needed Parti occorrenti Potrebné...
  • Page 32 SGC1 (x4) (x4) (x2) VGA40 (x1) 1&2 Left Door Porte gauche Linke Tür SGC1 Puerta iz uierda VGA40 Porta es uerda Linker deur Levé dveře VGA40 avé dvere Leva vrata Lijeva vrata Bal ajtó Vänster dörr Porta Sinistra VGA40 Lewe drzwi Usa stanga Лява...
  • Page 33 L (x1) (x1) SGC1 (x4) (x4) SGC1 SGC1 VGA40 VGA39 VGA24 (x2) SGC1 (x4) VGA24 1&2 VGA40 VGA40 VGA39 SGC1 VGA39...
  • Page 34 VGA44 (x2)
  • Page 35 Assembly on Concrete Platform Montáž na betonové plošině Montaggio su piattaforma in calcestruzzo Assemblage sur plate forme en béton Montáž na betónovú plošinu Montaż na betonowej platformie Montage auf Betonplattform Montaža na betonsko ploščad Adunarea pe platforma de beton Montaje en plataforma de hormigón Montaža na betonskoj platformi Монта...
  • Page 36 Om ervoor te zorgen dat uw schuur bestand is tegen hoge winden, raden wij u aan deze vloeroptie te gebruiken. Een concrete pad of een groot formaat concrete patio stenen pleinen wordt aanbevolen voor geschikt woord basis. Zorg ervoor dat het is stevig en niveau en drainage zal toestaan weg van de site.
  • Page 37 Pentru a vă asigura că vaporul dvs. rezistă unor v nturi puternice, am recomandat să folosi i această op iune pentru podea. Un tampon de beton sau o p trat de piatr din beton de dimensiuni mari este recomandat pentru o baz adecvat pentru podea. Asigura i v c este ferm i la nivel i va permite scurgerea departe de site.
  • Page 38 Important Warranty Information Važne informacije o jamstvu Informations Importantes Concernant La Garantie Fontos jótállási információk Wichtige Informationen zur Gew hrleistung Viktig garantiinformation Información importante sobre la garantía Informazioni importanti sulla garanzia ImportantesInformaç es de Garantia Ważne informacje gwarancyjne Belangrijke Informatie over de garantie Informa ii importante privind garan ia D ležité...
  • Page 39 zopa D zosta a przetesto ana i przesz a duże obciążenia wiatrem w kontrolowanym środowisku laboratoryjnym, gdy zainstalowano ją zgodnie z wytycznymi dotyczącymi instalacji wiatrowej. Naturalne obszary o dużym natężeniu wiatru wytwarzają wiatr o nieprzewidywalnych prędkościach, które są bardzo trudne do uch ycenia dok adnie ed ug lokalizacji.
  • Page 40 U.S. Polymers, Inc. 1057 S. Vail Ave Montebello, CA 90640, w w w . d u r a m a x b p . c o m United States of America 9022 RD-0.0 20-03-2024...
