MATRIX
ROUND POOL
*Model 202
HAVE ANY QUESTIONS?
We have the solutions! Conctat-us via our new Help
Center. Our teams will get back to you as soon as
possible.
help.trevi.ca
ASSEMBLY INSTRUCTIONS
MADE IN QUEBEC
*Reference name in the document.
Advertisement
Related Manuals for Trevi MATRIX 202
Summary of Contents for Trevi MATRIX 202
- Page 1 MATRIX ROUND POOL *Model 202 ASSEMBLY INSTRUCTIONS MADE IN QUEBEC HAVE ANY QUESTIONS? We have the solutions! Conctat-us via our new Help Center. Our teams will get back to you as soon as possible. help.trevi.ca *Reference name in the document.
- Page 2 ASSEMBLY INSTRUCTIONS ROUND POOL 40320K_V9_2024-04-29 ROUND POOL MODEL 202 DO NOT DIVE OR JUMP, SHALLOW WATER! WARNING : THIS POOL IS NOT DESIGNED FOR DIVING AND/OR JUMPING. WARNING : The pool owner is responsible to ensure everyone who accesses the yard, follows all safety instructions.
- Page 3 1/13...
- Page 4 SAFETY LABELS If you require additional labels, you can order more free of charge by calling 1-888-777-0447 SAFETY INFORMATION WARNING : All pool components, such as the filtration system, pump and heater should not be positioned in such a way that someone could use them to gain access to the pool. Be sure that filter, pump, all toys, chairs, tables, buildings or similar objects are at least at a minimum of 4’...
- Page 5 ctions and applicable regulations. 2/13...
- Page 6 PARTS LIST PARTS DESCRIPTION POOL WALL BOLT - NUT FOR WALL LEDGE BOTTOM & TOP CONNECTOR UPRIGHT TOP CAP BOTTOM & TOP TRACK COPING STRIPS (optional) SILVER SCREW 1'' LONG SCREW 1 1/2'' 3/13...
- Page 7 SITE PREPARATION When selecting a site for your pool, take into account your Illustration 1.1 local regulations regarding fences and utility laws pertaining to electrical cables, as well as the landscaping which you are planning once the pool is installed. Drive a stake into the ground at the center of the site.
- Page 8 SITE PREPARATION (continued) removal Pool POOL 21' ROUND POOL 24' ROUND POOL 27' ROUND POOL 5/13...
- Page 9 SITE PREPARATION (continued) removal Pool POOL 6/13...
- Page 10 SITE LEVELLING DO NOT ALLOW WATER TO ACCUMULATE AROUND POOL. Stone dust option : Add the necessary stone dust* to cover Make the 12" (30 cm) wide section between the dashed lines (sod sure to provide good drainage away from the pool. removal area).
- Page 11 18' (5.48 m) 21' (6.40 m) SITE LEVELLING 24' (7.31 m) 27' (8.22 m) 30' (9.14 m) 8/13...
- Page 12 WALL INSTALLATION When installing the steel wall, it is important to do so in a location protected from the wind or on a day without any wind. Before uncoiling the wall, add sand for the pool bottom and cove. Make sure the pre-punched holes for the skimmer and water return are at the top and facing the planned location of your filter.
- Page 13 lty installation will cause the wall joint to split open which could result in serious and/or fatal injuries! WALL INSTALLATION 8/13...
- Page 14 WALL INSTALLATION (continued) Chart 1.3 POOL SIZE ACTUAL WALL LENGTH 28' 9 3/8" (8.77 m) 9' (2.74 m) 12' (3.66 m) 37' 9 3/8 " (11.52 m) 15' (4.57 m) 47' 2 1/2" (14.39 m) 18' (5.48 m) 56' 7 1/2" (17.26 m) 21' (6.40 m) 66' 5/8"...
- Page 15 VINYL LINER INSTALLATION See the liner manufacturer's instruction TOP TRACK INSTALLATION (3 OPTIONS) This is to complement liner manufacturer’s instructions. If you TOP TRACK have any questions, please refer to the liner manufacturer’s instructions, first. COPING STRIPS* 1- Overlap liner: Once the liner is draped in the pool, install the coping strips* around the perimeter of the pool.
- Page 16 LEDGE INSTALLATION Verify that each upright is completely plumb. Secure the ledges in place with a first "ZL" type screw in the oblong hole. Evenly distribute ledges all around the pool before securing them. Then, secure the ledges in place with 3 "ZL" type screws. Center the ends of the seat equally on the upright.
- Page 17 Before filling the pool with water, make sure to install all safety labels. Refer to the following pages. LEDGE INSTALLATION 12/13...
- Page 18 SAFETY INFORMATION DO NOT DIVE OR JUMP, SHALLOW WATER! WARNING : THIS POOL IS NOT DESIGNED FOR DIVING AND/OR JUMPING. WARNING : The pool owner is responsible to ensure everyone who accesses the yard, follows all safety instructions. WARNING : Be sure you have read and understand the 'Safety Information' sheets before you begin your pool installation.
- Page 19 SAFETY LABELS If you require additional labels, you can order more free of charge by calling 1-888-777-0447 SAFETY INFORMATION WARNING : All pool components, such as the filtration system, pump and heater should not be positioned in such a way that someone could use them to gain access to the pool. Be sure that filter, pump, all toys, chairs, tables, buildings or similar objects are at least at a minimum of 4’...
