OWNERS
MANUAL
Model No.
45-0288
CAUTION:
Read Rules for
Safe Operation
and Instructions
WMV-
Digitally signed by WMV-Dresden
DN: cn=WMV-Dresden, c=DE,
o=WMV-Dresden,
Dresden
email=noreply@wmv-dresden.de
Date: 2017.01.26 13:00:37 +01'00'
Carefully
• Safety
• Assembly
• Operation
• Maintenance
• Parts
175 LB. POLY PRO
DROP SPREADER
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Agri-Fab POLY PRO 45-0288
Summary of Contents for Agri-Fab POLY PRO 45-0288
- Page 1 OWNERS MANUAL Model No. 45-0288 175 LB. POLY PRO DROP SPREADER CAUTION: Read Rules for Safe Operation and Instructions Carefully • Safety • Assembly • Operation • Maintenance • Parts WMV- Digitally signed by WMV-Dresden DN: cn=WMV-Dresden, c=DE, o=WMV-Dresden, Dresden email=noreply@wmv-dresden.de Date: 2017.01.26 13:00:37 +01'00'...
- Page 2 RULES FOR SAFE OPERATIONS Any power equipment can cause injury if operated improperly or if the user does not understand how to operate the equipment. Exercise caution at all times, when using power equipment. • Always begin with the transmission in first (low) gear •...
- Page 3 SHOWN FULL SIZE NOT SHOWN FULL SIZE HARDWARE CHART REF. QTY. DESCRIPTION REF. QTY. DESCRIPTION Nylon Washer Hex Bolt, 3/8" x 1" Hex Nut, 1/4" (SIMS) Hex Bolt, 1/4" x 1-1/4" Hex Lock Nut, 1/4" Hex Bolt, 1/4" x 5/8" Carriage Bolt, 1/4"...
- Page 4 ASSEMBLY 1/4" FLAT WASHER (ONE ONLY) TOOLS REQUIRED FOR ASSEMBLY (2) 7/16" Wrenches 1/4" HEX NUT HOPPER (2) 9/16" Wrenches BRACE 1/4" x 5/8" HEX BOLT 3/8" x 1" HEX BOLT HITCH 1. Remove the hardware pack and all individual parts BRACKET from the carton and lay out as shown on page 2 and 3/8"...
- Page 5 8. Assemble the plastic grip onto the end of the flow 12. Move the flow control arm forward, away from the control arm as shown in figure 4. hopper, opening the flow plates. If you can close the flow plates by pushing directly against them, you 9.
- Page 6 OPERATION FLOW RATE CHART Flow Rate Setting MATERIAL TYPE At 3 M.P.H. HOW TO USE YOUR SPREADER Light Heavy 1. Refer to the instruction label on the material pack- Fertilizer Granular / Pelleted age and to the Recommended Spreader Settings sheet included with your spreader for the proper Grass Seed Fine / Coarse...
- Page 7 REPAIR PARTS FOR 175 LB. DROP SPREADER MODEL 45-0288 REF. PART QTY. DESCRIPTION REF. PART QTY. DESCRIPTION 47451 Hopper 24534 Plate, Bearing 24536 Hopper Center Plate (Small) 44457 Wheel 24535 Hopper Center Plate (Large) 1509-69 Bolt, Hex 1/4-20 x 1-3/4" Lg. 43088 Washer, 1/4"...
- Page 8 REPAIR PARTS 303 West Raymond Sullivan, IL. 61951 217-728-8388 / www.agri-fab.com...
